MAX17526AEVKIT# datasheet, PDF

Datasheet> All Categories > Embedded solution> Engineering tools> Power management IC development tools> MAX17526AEVKIT#

Preview

MAX17526AEVKIT#: DescriptionPower management IC development tool Evkit for MAX17526A 5.5V to 60V, 6A Current-Limiter with OV, UV, Reverse Protection, and Power Limit; CategoryEmbedded solution Engineering tools Power management IC development tools; File Size909KB，13 Pages; ManufacturerMaxim; Websitehttps://www.maximintegrated.com/en.html; Environmental Compliance

Download Datasheet Parametric View All

MAX17526AEVKIT# Overview

Power management IC development tool Evkit for MAX17526A 5.5V to 60V, 6A Current-Limiter with OV, UV, Reverse Protection, and Power Limit

MAX17526AEVKIT# Parametric

Parameter Name	Attribute value
Maker	Maxim
Product Category	Power Management IC Development Tools
product	Evaluation Kits
type	Current Monitors & Regulators
Tools for assessment	MAX17526A
Input voltage	5.5 V to 60 V
series	MAX17526
Factory packaging quantity	1

Preview

Download Datasheet

View All

Click

here

for production status of specific part numbers.

MAX17526A Evaluation Kit

Evaluates: MAX17526A – 5.5V to 60V, 6A

Current Limiter with OV, UV, Reverse

Protection, and Power Limit

Quick Start

Recommended Equipment

●

MAX17526A EV kit

●

Multimeters

●

Adjustable load (0A to 10A)

●

5V DC power supply

●

60V DC power supply

General Description

The MAX17526A evaluation kit (EV kit) is a fully assem-

bled and tested circuit board that demonstrates the

MAX17526A high accuracy adjustable power limiter in a

20-pin TQFN-EP package. The EV kit can be configured

to demonstrate adjustable overvoltage, undervoltage,

overcurrent, different current-limit types, and power limit

features.

Features

●

5.5V to 60V Wide Input Voltage Range

●

Features a TVS Diode across the Input and Schottky

Diode across the Output Terminals

●

External NMOSFET Installed

●

Evaluates UVLO, OVLO, Three Current-Limit Types,

and Current-Limit Threshold

●

Programmable Input Overvoltage Setting up to 40V

●

Demonstrates Internal UVLO programmed to 12.8V

●

Demonstrates Internal OVLO programmed to 36.2V

●

Active Power Limit to Protect Supply or Load

●

Proven PCB Layout

●

Fully Assembled and Tested

Equipment Setup and Test Procedure

The EV kit is fully assembled and tested. Follow the steps

below to verify board operation.

Caution: Do not turn on

the power supply until all connections are completed.

1) Verify that all jumpers are in their default positions.

2) Connect a 5V DC power supply to V

(TP21).

3) Set the 40V DC power supply to 10V and connect it

between V

(TP1/TP2) and GND (TP3/TP4). Verify

that LED1 is on and

FLAG

(TP15) is 0V.

4) Increase the DC power-supply voltage and verify that

LED2 turns on when voltage reaches approximately

12.8V. Also check that voltage on V

OUT

(TP5/TP6) is

12.8V and

FLAG

is 5V.

5) Gradually increase the DC power-supply voltage

and verify that LED2 turns off when voltage reaches

approximately 36.2V. Also check that voltage on V

OUT

goes down and

FLAG

is 0V.

6) Gradually decrease the DC power-supply voltage

and verify that LED2 turns on when voltage reaches

approximately 34.1V. Also check that voltage on V

OUT

is 34.1V and

FLAG

is 5V.

7) Set the DC power-supply voltage to 24V and connect

the adjustable load between V

OUT

and GND terminals

and a multimeter in series to measure the current.

Gradually increase the load current and verify that the

OUT

goes down and

FLAG

goes low when the load

current increases above 6A.

8) The jumpers JU7-JU10 can be configured to change

the current-limit as in

Table 7.

Verify various current-

limit operations by repeating step 7.

Ordering Information

appears at end of data sheet.

319-100211; Rev 0; 6/18
