TABLE OF PART NUMBERS
PART No.
RJX8FA3VB
RJX8FB3VB
TRANSMISSION
CLASS
CLASS D
CLASS D
CAT5e
CAT5e
CAT6
CAT6
1
F
19.80
[.780]
2.7
[.106]
18.3
[.720]
3.3
[.130]
24.9
[.980]
F
FRONT SHELL MATERIAL
PLASTIC BLACK
METAL NICKEL PLATED
PLASTIC BLACK
METAL NICKEL PLATED
PLASTIC BLACK
METAL NICKEL PLATED
19.80
[.780]
28.5
[1.122]
RJX8FA5VB
RJX8FB5VB
RJX8FA6VB
RJX8FB6VB
E
E
11.60
[.457]
2.2
[.086]
4 x
1.70
[.067]
3.6
[.142]
0.5
[.020]
19.80
[.780]
8 x
0.80
[.031]
23.0
[.906]
MIN
D
D
2.54
[.100]
19.80
[.780]
22.0
11.50
[.453]
15.00
[.591]
3
R 2 . 90 ]
[.0
[.866]
MIN
2
X
2.70
[.106]
C
CENTER OF
CUT OUT
HOLE
22.0
ON PANEL
5.61
[.221]
1.27
[.050]
2.54 (TYP)
[.100]
4.44
[.175]
16.85
[.663]
2:1
PANEL CUT OUT
(CONNECTOR FRONT VIEW)
3:2
MIN MOUNTING PITCH
1:1
3D VIEW
1:1
C
6.60
[.260]
7.05
[.278]
1.2
[.047]
PCB LAYOUT
RJ45 CONTACTS
RJ45 SHELL GROUND CONTACT
CONNECTOR LOCATION PINS
B
(CONNECTOR REAR VIEW)
PSE PINOUT ALTERNATIVES
o
l
A
us
en
i
pl
CONDUCTOR
1
2
3
4
5
6
7
8
Alternative-A
(MDI-X)
Negative V
PSE
Negative V
PSE
Positive V
PSE
Alternative-A
(MDI)
Positive V
PSE
Positive V
PSE
Negative V
PSE
Alternative-A
(AII)
SPECIFICATIONS:
1. MATERIALS:
- PLASTIC INSERT & HOUSING: HIGH TEMPERATURE THERMOPLASTIC FLAMMABILITY RATING UL94V-0
DSM STANYL, 30%
BLACK
- FRONT SHELL: METAL: ZINC ALLOY ZAMAK 3, NICKEL PLATE (B TYPE) OR PLACTIC (A TYPE).
- CONTACTS: PHOSPHORE BRONZE, 1.27 um GOLD PLATE ON MATING SURFACES, 1.27 um NICKEL MIN UNDERPLATE. 3.81 um MIN
MATTE TIN ON CONTACT TAILS.
- LATCH LOCK AND SPRING: SPRING STEEL, NICKEL PLATE.
2. ELECTRICAL CHARACTERISTICS:
- RATED VOLTAGE: 125 VAC
- TYPICAL CONTACT RESISTANCE: 20 mOhm
- INSULATION RESISTANCE: >500 MOhm
- DIELECTRIC STRENGTH: 1000 VAC, 60 SECONDS
- TRANSMISSION SPECIFICATION/CLASS: COMPLIES WITH CLASS D PER TIA/EIA 568B OR CAT5e & CAT 6 PER TIA/EIA-568-C.2
- PoE+ COMPLIES WITH 802.3at Type 2 ( SEE PSE PINOUT ALTERNATIVE TABLE)
B
S
o
H
ant
R
1
1/
6
A
mp
h
t
r
a
l
i
a
UNLESS OTHERWISE SPECIFIED
TOLERANCE TO BE
A
2
0
U
5
/
E
Positive V
PSE
Negative V
PSE
Positive V
PSE
Positive V
PSE
Negative V
PSE
Negative V
PSE
LINEAR
ANGULAR
X
±
0.5
X
±
1
X.X ±
0.1
X.X' ±
30'
X.X ±
0.05
X.X'X " ± 15'
BREAK ALL SHARP EDGES
AND REMOVE ALL BURRS
C
o
m
THIS DOCUMENT IS THE PROPERTY OF AMPHENOL AUSTRALIA PTY. LTD.
. NO PART THEREOF MAY BE REPRODUCED AND USED
WITHOUT THE PRIOR WRITTEN CONSENT OF THE OWNER
.
Amphenol
TITLE:
Amphenol Australia Pty.Ltd,
22 Industry Blvd, Carrum Downs
VIC 3201 Australia
PART No:
MATERIAL:
REFER SPECIFICATION
DRN:
CKD:
APP'D:
T.N
P.M
P.M
DATE:
10/02/14
DATE:
10/02/14
DATE:
10/02/14
SIZE:
DO NOT SCALE
FINISH:
XLRnet CONNECTOR
RJ45 VERTICAL
REFER TO TABLE OF
PART NUMBERS
REV
1
SHEET
A
DRAWING No.
6
5
4
DIMENSIONS IN MILIMETRES
3
THIRD ANGLE
PROJECTION
SCALE:
3:2
A3
WITHOUT LED & EMI SHIELD
2
55010955-000
1
5
/
7
Embedded System
