Shielded Cat.5e RJ45 PCB Jack
accepts both Solid and Stranded
AWG 24 to 26 Wires
1
D
26.50
`
0.05
D
Cover Gasket
Protective Cover
(Plastic, Color Black
Bayonet Locking Type)
Panel Flange
n
28.00
`
0.05
Recommended Panel Cutout
93
`
3
b
Panel Gasket
Panel Nut
(M28 x 1.5)
Receptacle Housing
(Plastic in different Colors,
Bayonet Locking Type)
Bayonet Channel x 3
37.75
Key Protrusion x 3
C
Tether
Sealed with Sealing Compound,
provides IP67 even when uncovered
(For potted version only)
C
n
30
3.5
2.0
n
34
Notes:
0.50
19.4
29.7
34.5
b
B
1. Electrical Specifications:
- Meets EIA/TIA-568-B.2 Cat.5e Specification
- Contact Resistance: 20mOhm max.
- Insulation Resistance: 500MOhm min. @ 100 VDC
- Current Rating: 1.2A max. at 25
~
C
- Working Voltage: 100 VDC
- DWV: 1000 VDC/60s Contact to Contact, 1500 VDC/60s Contact to Metal Shell
- Operating Temperature: -40
~
C to +85
~
C
2. Material and Finish:
- Receptacle Housing: Polyester (Color: See Part Number Table); UL94 V-0
- Cover Coupling Ring: Polyester (Black); UL94 V-0
- Panel Nut: Brass, Finish: Nickel Plated
- Panel Gasket: Silicon, Color: White
- Cover Gasket: Silicon, Color: White
- Tether: Polycarbonate, Color: Black
- Cat.5e RJ45 PCB Jack Metal Shell: Copper Alloy, Nickel Plated
- Cat.5e RJ45 PCB Jack Plastic Housing: Glass filled PBT UL94 V-0, Color: Black
- Cat.5e RJ45 PCB Jack Contacts: Phosphor Bronze, Finish: 50u" Gold min. over Nickel
3. Connector can be front or rear mounted to a maximum panel thickness of 3.2mm.
4. IP67 rated when covered or fully mated with the appropriate mating connector
Directive 2002/95/EC RoHS Compliant
5. RoHS compliant
Description
Plastic Receptacle
Housing Color
Part Number
THIS DRAWING MAY NOT BE COPIED OR REPRODUCED
IN ANY WAY, AND MAY NOT BE PASSED ON TO A THIRD
PARTY WITHOUT WRITTEN PERMISSION.
OWNERSHIP AND COPYRIGHT OF CONEC CORPORATION
32
B
Potted Colored Plastic Receptacle Housing with Shielded Cat.5e RJ45 PCB Jack + Black Cover
Black
17-10039
Blue
17-102814
Tolerance
0 PLC
1 PLC
2 PLC
3 PLC
ANGLES
Green
17-102824
`
0.50
`
0.38
`
0.25
`
0.10
`
3
~
Yellow
17-102834
Red
17-102844
White
17-102854
DOT NOT ALTER CAD DRAWING BY HAND
Customer:
Name
Title
Approval Date
Unless otherwise specified
Scale: 1.2:1
Autodesk
Inventor
Name
Vincent Ke
J. Chaudry
Dim. in mm
Material: See Notes
Title:
2011
Draw.
Appd.
Norm
D-old
Date
Jan. 28
Jan. 28
Potted Receptacle & Cover Kit
Colored Plastic Recaptacle Housing
with Shielded Cat. 5e RJ45 PCB Jack
A
A
b
a
Rev.
Mar/08/2011 Vincent ke
original
Changes
Date
Name
R
Drawing No.: 17K1A199
Part No.: SEE PART NUMBER TABLE
DIN
A3
Sheet
1/1
6
5
4
3
2
1
