MLX91216
IMC-HALL
®
HIGH-SPEED
CURRENT SENSOR
BOOSTING ACCURACY AND DIAGNOSTICS FOR
INVERTER AND CONVERTER APPLICATIONS
MLX91216
The MLX91216 is the IMC-Hall
®
variant of the Melexis Gen 2.5 high-speed current sensor portfolio. It introduces three
main changes over the Gen 2 MLX91208. To serve the ever more demanding automotive application requirements, our
open-loop Hall-effect sensors are now increasing the accuracy of sensitivity and offset over temperature resulting in
market-leading sensor accuracy. Next to this improvement, the diagnostic coverage was increased with the introduction of
clamping and broken wire detection, in order to address applications with higher ASILs and/or connectors from e.g. sensor
module to control board with ECU. Finally, on-chip filtering allows for an accurate trade-off between bandwidth/response
time and higher resolution. The MLX91216 with the proprietary IMC-Hall
®
technology comes in the surface mount SOIC8
package and allows for a very compact and easy assembly with a shield. This IMC-Hall
®
technology provides the ultimate
equilibrium in the mechanical, electrical and magnetic requirement matching for a seamless SMT manufacturing process.
KEY FEATURES
k
Higher accuracy
• Sensitivity Thermal Drift < 1% (33% improvement)
• Offset Thermal Drift < 5 mV (50% improvement)
k
Custom factory trim options available
k
High Field and Very High Field variants for full-scale
current ranges spanning 100 to > 1200 A
k
Increased diagnostic capability
• Programmable Output Clamping
• Broken Wire Detection
k
Extended On-chip filtering options
k
Automotive AEC-Q100 Grade 0
k
High Speed
• 250 kHz bandwith
• 2.5 μs response time
v1/05-11-2018
The above information is “as is” and believed to be correct and accurate. Melexis disclaims any and all liability in connection with or arising out of the furnishing, application or use of the information or products; any and all liability, including without limitation, special, consequential or incidental
damages; and any and all warranties, express, statutory, implied, or by description, including warranties of fitness for particular purpose, non-infringement and merchantability. Melexis reserves the right to change it at any time and without notice. Users should obtain the latest version of the
information to verify it is current. Users must further determine the suitability of a product for its application, including the level of reliability required and determine whether it is fit for a particular purpose. Export control regulations may apply and export might require a prior authorization from
competent authorities. Melexis’ products are intended for use in normal commercial applications. Unless otherwise agreed upon in writing, the products are not designed, authorized or warranted to be suitable in applications requiring extended temperature range and/or unusual environmental
requirements. High reliability applications, such as medical life-support or life-sustaining equipment are specifically not recommended by Melexis. Melexis’ products are sold under the Melexis’ Terms of Sale, which can be found at https://www.melexis.com/en/legal/terms-and-conditions.
FOR MORE INFORMATION: WWW.MELEXIS.COM/MLX91216
The snout of the platypus is a sensory
organ with electroreceptors in the skin
of the bill, which allow him to detect the
electrical field that gets generated when
his prey contracts its muscles. With his
40,000 sensitive electronic sensors, this
unique semi aquatic egg-laying mammal
represents our current sensors.
