53_BNC-75-0-1/133_NE datasheet, PDF

Datasheet> All Categories > The connector> The connector> 53_BNC-75-0-1/133_NE

53_BNC-75-0-1/133_NE: DescriptionRF Adapters - Within Series; CategoryThe connector The connector; File Size109KB，1 Pages; ManufacturerHUBER+SUHNER

Download Datasheet Parametric View All

53_BNC-75-0-1/133_NE Overview

RF Adapters - Within Series

53_BNC-75-0-1/133_NE Parametric

Parameter Name	Attribute value
Maker	HUBER+SUHNER
package instruction	ROHS COMPLIANT
Reach Compliance Code	compliant
Adapter type	BNC-BNC
Other features	STANDARDS: IEC 60169-8; MIL-STD-348A/301
Body/casing type	PLUG-JACK
Characteristic impedance	75 Ω
Connector type	RF CONNECTOR ADAPTER
Contact to complete cooperation	NOT SPECIFIED
Contact point gender	MALE-FEMALE
Contact material	NOT SPECIFIED
Coupling type	BAYONET
DIN compliance	NO
Filter function	NO
IEC compliance	YES
insulator material	PFA/PTFE
MIL compliance	YES
Maximum operating frequency	1 GHz
Options	GENERAL PURPOSE
Panel mounting	NO

Preview

Download Datasheet

View All

Data Sheet

Within Series Adaptor

53_BNC-75-0-1/133_N

Description

L-adaptor plug/jack

BNC plug (male) / BNC jack (female)

Interface standard

Series BNC - Compatible with IEC 61169-8_MIL-STD-348A/301_CECC 22120

Technical Data

Electrical Data

Impedance

Interface frequency max.

75 Ω

1 GHz

Mechanical Data

Number of matings

Weight

500

0.0154 kg

Environmental Data

Operating temperature

2011/65/EC (RoHS)

-65 °C to 165 °C

compliant

Material Data

Interface - BNC plug (male)

Piece Parts

Centre contact

Outer contact

Body

Insulator

Coupling nut

Gasket

Material

Copper Beryllium / Brass

Brass

PFA / PTFE

Brass

VMQ (Silicone rubber)

SUCOPLATE (R) Plating

Surface Plating

Gold Plating (Nickel underplated)

SUCOPLATE (R) Plating

Interface - BNC jack (female)

Piece Parts

Centre contact

Outer contact

Body

Insulator

Material

Copper Beryllium / Brass

Brass

PFA / PTFE

Surface Plating

Gold Plating (Nickel underplated)

SUCOPLATE (R) Plating
