Data Sheet
Between Series Adaptor
33_SK-MMPX-50-1/199_N
Description
Adaptor plug/jack
SK plug (male) / MMPX jack (female)
Precision adaptor
For Test & Measurement applications
Interface standards
Series SK - MIL-STD-348A/323
Series MMPX - HUBER+SUHNER MMPX STD (Patent US 7.294.023)
Technical Data
Electrical Data
Impedance
Interface frequency max.
Frequency range
Return loss
Electrical length
50 Ω
40 GHz
DC to 15 GHz
≥ 26 dB
16.1 mm
15 to 30 GHz
≥ 23 dB
30 to 40 GHz
≥ 20 dB
Mechanical Data
Number of matings
Weight
100
0.0039 kg
Environmental Data
Operating temperature
2011/65/EU (RoHS)
-40 °C to 125 °C
compliant
Material Data
Interface - SK plug (male)
Piece Parts
Centre contact
Outer contact
Body
Insulator
Coupling nut
Material
Copper Beryllium Alloy
Stainless Steel
Stainless Steel
PPE (Polyphenylene ether, PPO)
Stainless Steel
Surface Plating
SUCOPRO Plating
Interface - MMPX jack (female)
Piece Parts
Centre contact
Outer contact
Body
Insulator
Material
Copper Beryllium Alloy
Copper Beryllium Alloy
Stainless Steel
PPE (Polyphenylene ether, PPO)
Surface Plating
SUCOPRO Plating
Related Documents
Outline drawing
DOU-00128127
Ordering Information
Single package
33_SK-MMPX-50-1/199_NE
HUBER+SUHNER is certified according to ISO 9001, ISO 14001, ISO/TS 16949 and IRIS
www.hubersuhner.com
Waiver: It is exclusively in written agreements that we provide our customers with warrants and representations as to the technical specifications and/or the fitness for any
particular purpose. The facts and figures contained herein are carefully compiled to the best of our knowledge, but they are intended for general information purposes only.
Document: DOC-0000288298 R / PDO J / date of publication: 17.11.2015 17:14:49 / uncontrolled copy
Page 1/1
