TOLERANCE
UNLESS OTHERWISE
SPECIFIED
THIS IS A C.A.D. GENERATED DRAWING
DO NOT MAKE MANUAL REVISIONS TO MASTER.
ISSUE NUMBER
ORIGINAL
1
.X
.XX
.XXX
±0.25
±0.15
±0.10
80.370
25.555
1.663
4.940
1.900
A"
52.915
PIN 2
5.320
6.650
23.560
0.760TYP.
81.130
78.280
3.800
INSULATOR
OUTLINE
1.425
PIN 200
Ø
.0
07
-0
1.2
08
+0 . 5
C
L
PITCH 0.760 TYP.
23.560
2.565
PIN 1
C
L
3.800
78.280
83.410
A
3.021 TYP.
NOTE: STENCIL TO BE 0.15 THICK.
SCALE 1:1
PIN 199
C
0.855
1.900
2.879
3.420
7.410
7.600
5.653
C
L
3.876
SEC. A-A"
R
1.425
0.
19
R
EF
.
81.130
26.885
NOTES:
MATERIAL:
HOUSING:
CONTACT:
INSULATOR THERMOPLASTIC, UL-94V-0
COPPER ALLOY
GOLD FLASH PLATING ON CONTACT AREA
MATTE TIN PLATING ON SOLDER TAIL OVER
NICKEL UNDER PLATING
CRITICAL DIMENSION
DIMENSIONS NEED TO BE MEASURED IN CPK
1.425
0.760 TYP.
.0
Ø1
C
L
64
1.43 REF.
80.228
78.280
25.460
23.560
0.760
3.800
A- C
L
1.492±0.157
0.637
30.0
°
1.43 REF.
MARKED
MARKED
C
*
0.979
PIN 2
PIN 200
C
L
3.420
2.470
5.890
2.280
SCALE 1:1
ACAD REFERENCE NO.:
370-200-229-002
DATE:
DATE:
JUNE.28 /2018
CARD EDGE, FEMALE, SMT, 200 CONTACTS
WITH KEY
EDAC INC
TORONTO, ONTARIO
CANADA
YOUR CONNECTION TO QUALITY & SERVICE
THESE DRAWINGS AND SPECIFICATIONS
ARE THE PROPERTY OF EDAC INC.,AND
SHALL NOT BE REPRODUCED,OR COPIED
OR USED AS THE BASIS FOR THE
MANUFACTURE OR SALE OF APPARATUS
WITHOUT WRITTEN PERMISSION.
DRAWN:
CHECKED:
SCALE:
W.T
THIS SERIES FULLY CONFORMS TO
THE EUROPEAN UNION DIRECTIVES
COMPLIANT
2011/65/EU FOR RoHS COMPLIANCY.
N.T.S
SHEET
1
OF
DRAWING NUMBER:
PART NUMBER:
370-200-229-002
370-200-229-002
1.140
4.370
KEEP OUT REWORK AREA
1.140 TYP.
0.475 TYP.
1
ISSUE
1
