CP0402A1930FNTR

Description
Signal Conditioning 1930MHz 50 Ohm 0402
CategoryPassive components    Signal conditioning
File Size252KB,6 Pages
ManufacturerAVX
Environmental Compliance
Download Datasheet Parametric Compare View All

CP0402A1930FNTR Online Shopping

Suppliers Part Number Price MOQ In stock
CP0402A1930FNTR - - View Buy Now

CP0402A1930FNTR Overview

Signal Conditioning 1930MHz 50 Ohm 0402

CP0402A1930FNTR Parametric

Parameter NameAttribute value
MakerAVX
Product Categorysignal conditioning
Shipping restrictionsMouser does not currently sell this product.
productDirectional Couplers
frequency1930 MHz
impedance50 Ohms
Termination typeSMD/SMT
Package/box0402 (1005 metric)
Minimum operating temperature- 40 C
Maximum operating temperature+ 85 C
seriesCP0402
EncapsulationReel
InstallSMD/SMT
range of working temperature- 40 C to + 85 C
typeThin Film High Directivity LGA Termination
Factory packaging quantity5000
unit weight0.650 mg
Thin-Film Directional Couplers
CP0402 High Directivity LGA Termination
GENERAL DESCRIPTION
ITF (Integrated Thin-Film) TECHNOLOGY
The ITF High Directivity LGA Coupler is based on thin-film multilayer
technology. The technology provides a miniature part with excellent high
frequency performance and rugged construction for reliable automatic
assembly.
The ITF Coupler is offered in a variety of frequency bands compatible
with various types of high frequency wireless systems.
DIMENSIONS:
(Bottom View)
B
A
millimeters (inches)
S
L
APPLICATIONS
Mobile Communications
Satellite TV Receivers
GPS
Vehicle Location Systems
Wireless LAN’s
FEATURES
Inherent Low Profile
Self Alignment during Reflow
Excellent Solderability
Low Parasitics
Better Heat Dissipation
Operating/Storage Temp
-40°C to +85°C
• Power Rating 3W RF Cont
T
W
L
W
T
1.00±0.05
(0.040±0.002)
0.58±0.04
(0.023±0.002)
0.35±0.05
(0.014±0.002)
A
B
S
0.20±0.05
(0.008±0.002)
0.18±0.05
(0.007±0.002)
0.05±0.05
(0.002±0.002)
3
HOW TO ORDER
CP
Style
Directional Coupler
0402
Size
0402
X
Type
****
Frequency
(MHz)
X
Sub Type
N
LGA
Termination
L = LGA Sn90, Pb10
**N
= LGA Sn100
TR
Packaging Code
TR = Tape and Reel
**RoHS compliant
QUALITY INSPECTION
Finished parts are 100% tested for electrical parameters and
visual characteristics. Each production lot is evaluated on a
sample basis for:
• Static Humidity: 85°C, 85% RH, 160 hours
• Endurance: 125°C, I
R
, 4 hours
TERMINALS (Top View)
OUT
50 OHM
Not RoHS Compliant
LEAD-FREE COMPATIBLE
COMPONENT
TERMINATION
Sn90Pb10 or Lead-Free Sn100 Nickel/Solder coating
compatible with automatic soldering technologies: reflow,
wave soldering, vapor phase and manual.
IN
COUPLING
For RoHS compliant products,
please select correct termination style.
ORIENTATION IN TAPE
Recommended Pad Layout Dimensions
0.31
(0.012)
0.20
(0.008)
mm (inches)
OUT
50
OHM
OUT
50
OHM
0.15
(0.006)
IN
CP
IN
CP
0.53
(0.021)
*The recommended distance to the PCB Ground Plane is 0.254mm (0.010")
49
