BT459KG135 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Microcontrollers and processors> BT459KG135

BT459KG135: DescriptionPalette DAC, 256 X 24 Pixels, CMOS, CPGA132, CERAMIC, PGA-132; CategoryMicrocontrollers and processors; File Size3MB，56 Pages; ManufacturerCONEXANT; Websitehttp://www.conexant.com/

Download Datasheet Parametric Compare View All

BT459KG135 Overview

Palette DAC, 256 X 24 Pixels, CMOS, CPGA132, CERAMIC, PGA-132

BT459KG135 Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	incompatible
Maker	CONEXANT
Parts packaging code	PGA
package instruction	PGA,
Contacts	132
Reach Compliance Code	unknown
ECCN code	3A001.A.2.C
Is Samacsys	N
maximum clock frequency	135 MHz
show configuration	256 X 24 PIXELS
External data bus width	8
JESD-30 code	S-CPGA-P132
JESD-609 code	e0
Number of terminals	132
Maximum operating temperature	70 °C
Minimum operating temperature
Package body material	CERAMIC, METAL-SEALED COFIRED
encapsulated code	PGA
Package shape	SQUARE
Package form	GRID ARRAY
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Certification status	Not Qualified
Maximum supply voltage	5.25 V
Minimum supply voltage	4.75 V
Nominal supply voltage	5 V
surface mount	NO
technology	CMOS
Temperature level	COMMERCIAL
Terminal surface	Tin/Lead (Sn/Pb)
Terminal form	PIN/PEG
Terminal location	PERPENDICULAR
Maximum time at peak reflow temperature	NOT SPECIFIED
uPs/uCs/peripheral integrated circuit type	DISPLAY CONTROLLER, PALETTE DAC
Base Number Matches	1

Preview

Download Datasheet

View All

BT459KG135 Related Products

	BT459KG135	BT459KPF110	BT459KPF150	BT459KG150	BT459KG80	BT459KPF80	BT459KG110
Description	Palette DAC, 256 X 24 Pixels, CMOS, CPGA132, CERAMIC, PGA-132	Palette DAC, CMOS, PQFP132, PLASTIC, QFP-132	Palette DAC, CMOS, PQFP132	Palette DAC, CMOS, CPGA132, CERAMIC, PGA-132	Palette DAC, CMOS, CPGA132, CERAMIC, PGA-132	Palette DAC, CMOS, PQFP132	Palette DAC, CMOS, CPGA132, CERAMIC, PGA-132
Is it lead-free?	Contains lead	Contains lead	Contains lead	Contains lead	Contains lead	Contains lead	Contains lead
Is it Rohs certified?	incompatible	incompatible	incompatible	incompatible	incompatible	incompatible	incompatible
Maker	CONEXANT	CONEXANT	CONEXANT	CONEXANT	CONEXANT	CONEXANT	CONEXANT
Parts packaging code	PGA	QFP	QFP	PGA	PGA	QFP	PGA
package instruction	PGA,	BQFP,	,	PGA,	PGA,	,	PGA,
Contacts	132	132	132	132	132	132	132
Reach Compliance Code	unknown	compliant	unknown	compliant	compliant	unknown	compliant
ECCN code	3A001.A.2.C	3A001.A.3	3A001.A.2.C	3A001.A.3	3A001.A.3	3A001.A.2.C	3A001.A.3
JESD-30 code	S-CPGA-P132	S-PQFP-G132	S-PQFP-G132	S-CPGA-P132	S-CPGA-P132	S-PQFP-G132	S-CPGA-P132
JESD-609 code	e0	e0	e0	e0	e0	e0	e0
Number of terminals	132	132	132	132	132	132	132
Maximum operating temperature	70 °C	70 °C	125 °C	70 °C	70 °C	125 °C	70 °C
Package body material	CERAMIC, METAL-SEALED COFIRED	PLASTIC/EPOXY	PLASTIC/EPOXY	CERAMIC, METAL-SEALED COFIRED	CERAMIC, METAL-SEALED COFIRED	PLASTIC/EPOXY	CERAMIC, METAL-SEALED COFIRED
Package shape	SQUARE	SQUARE	SQUARE	SQUARE	SQUARE	SQUARE	SQUARE
Package form	GRID ARRAY	FLATPACK, BUMPER	FLATPACK	GRID ARRAY	GRID ARRAY	FLATPACK	GRID ARRAY
Peak Reflow Temperature (Celsius)	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED
Certification status	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified
Nominal supply voltage	5 V	5 V	5 V	5 V	5 V	5 V	5 V
surface mount	NO	YES	YES	NO	NO	YES	NO
technology	CMOS	CMOS	CMOS	CMOS	CMOS	CMOS	CMOS
Temperature level	COMMERCIAL	COMMERCIAL	MILITARY	COMMERCIAL	COMMERCIAL	MILITARY	COMMERCIAL
Terminal surface	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)
Terminal form	PIN/PEG	GULL WING	GULL WING	PIN/PEG	PIN/PEG	GULL WING	PIN/PEG
Terminal location	PERPENDICULAR	QUAD	QUAD	PERPENDICULAR	PERPENDICULAR	QUAD	PERPENDICULAR
Maximum time at peak reflow temperature	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED
uPs/uCs/peripheral integrated circuit type	DISPLAY CONTROLLER, PALETTE DAC	DISPLAY CONTROLLER, PALETTE DAC	DISPLAY CONTROLLER, PALETTE DAC	DISPLAY CONTROLLER, PALETTE DAC	DISPLAY CONTROLLER, PALETTE DAC	DISPLAY CONTROLLER, PALETTE DAC	DISPLAY CONTROLLER, PALETTE DAC
maximum clock frequency	135 MHz	110 MHz	-	150 MHz	80 MHz	-	110 MHz
External data bus width	8	8	-	8	8	-	8
encapsulated code	PGA	BQFP	-	PGA	PGA	-	PGA
Maximum supply voltage	5.25 V	5.25 V	-	5.25 V	5.25 V	-	5.25 V
Minimum supply voltage	4.75 V	4.75 V	-	4.75 V	4.75 V	-	4.75 V
Base Number Matches	1	1	1	1	-	-	-
Address bus width	-	2	-	2	2	-	2
length	-	24.13 mm	-	35.56 mm	35.56 mm	-	35.56 mm
Maximum seat height	-	4.572 mm	-	3.683 mm	3.683 mm	-	3.683 mm
Terminal pitch	-	0.635 mm	-	2.54 mm	2.54 mm	-	2.54 mm
width	-	24.13 mm	-	35.56 mm	35.56 mm	-	35.56 mm
