DSA70C200HB

Description
Rectifier Diode, Schottky, 1 Phase, 1 Element, 35A, 200V V(RRM), Silicon, TO-247AD, ROHS COMPLIANT, PLASTIC PACKAGE-3
CategoryDiscrete semiconductor    diode
File Size110KB,5 Pages
ManufacturerLittelfuse
Websitehttp://www.littelfuse.com
Environmental Compliance
Download Datasheet Parametric Compare View All

DSA70C200HB Online Shopping

Suppliers Part Number Price MOQ In stock
DSA70C200HB - - View Buy Now

DSA70C200HB Overview

Rectifier Diode, Schottky, 1 Phase, 1 Element, 35A, 200V V(RRM), Silicon, TO-247AD, ROHS COMPLIANT, PLASTIC PACKAGE-3

DSA70C200HB Parametric

Parameter NameAttribute value
Is it Rohs certified?conform to
MakerLittelfuse
package instructionR-PSFM-T3
Reach Compliance Codecompliant
Is SamacsysN
Other featuresHIGH RELIABILITY, FREEWHEELING DIODE, LOW NOISE
applicationSOFT RECOVERY
Shell connectionCATHODE
ConfigurationCOMMON CATHODE, 2 ELEMENTS
Diode component materialsSILICON
Diode typeRECTIFIER DIODE
Maximum forward voltage (VF)0.79 V
JEDEC-95 codeTO-247AD
JESD-30 codeR-PSFM-T3
Maximum non-repetitive peak forward current420 A
Number of components1
Phase1
Number of terminals3
Maximum operating temperature150 °C
Minimum operating temperature-55 °C
Maximum output current35 A
Package body materialPLASTIC/EPOXY
Package shapeRECTANGULAR
Package formFLANGE MOUNT
Peak Reflow Temperature (Celsius)NOT SPECIFIED
Certification statusNot Qualified
Maximum repetitive peak reverse voltage200 V
surface mountNO
technologySCHOTTKY
Terminal formTHROUGH-HOLE
Terminal locationSINGLE
Maximum time at peak reflow temperatureNOT SPECIFIED
Base Number Matches1
DSA70C200HB
preliminary
Schottky Diode Gen ²
V
RRM
I
FAV
V
F
=
= 2x
=
200 V
35 A
0.79 V
High Performance Schottky Diode
Low Loss and Soft Recovery
Common Cathode
Part number
DSA70C200HB
Backside: cathode
1
2
3
Features / Advantages:
Very low Vf
Extremely low switching losses
Low Irm values
Improved thermal behaviour
High reliability circuit operation
Low voltage peaks for reduced
protection circuits
Low noise switching
Applications:
Rectifiers in switch mode power
supplies (SMPS)
Free wheeling diode in low voltage
converters
Package:
TO-247
Industry standard outline
RoHS compliant
Epoxy meets UL 94V-0
IXYS reserves the right to change limits, conditions and dimensions.
Data according to IEC 60747and per semiconductor unless otherwise specified
20131031b
© 2013 IXYS all rights reserved
