DTA114TKA: DescriptionSmall Signal Bipolar Transistor, 0.1A I(C), 50V V(BR)CEO, 1-Element, PNP, Silicon, SOT-23, 3 PIN; CategoryThe transistor; File Size339KB，2 Pages; ManufacturerMicro Commercial Components (MCC)

Download Datasheet Parametric Compare View All

DTA114TKA Overview

Small Signal Bipolar Transistor, 0.1A I(C), 50V V(BR)CEO, 1-Element, PNP, Silicon, SOT-23, 3 PIN

DTA114TKA Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Maker	Micro Commercial Components (MCC)
Parts packaging code	SOT-23
package instruction	SMALL OUTLINE, R-PDSO-G3
Contacts	3
Reach Compliance Code	compliant
ECCN code	EAR99
Is Samacsys	N
Other features	BUILT-IN BIAS RESISTOR
Maximum collector current (IC)	0.1 A
Collector-emitter maximum voltage	50 V
Configuration	SINGLE WITH BUILT-IN RESISTOR
Minimum DC current gain (hFE)	100
JESD-30 code	R-PDSO-G3
JESD-609 code	e0
Number of components	1
Number of terminals	3
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Peak Reflow Temperature (Celsius)	240
Polarity/channel type	PNP
Certification status	Not Qualified
surface mount	YES
Terminal surface	TIN LEAD
Terminal form	GULL WING
Terminal location	DUAL
Maximum time at peak reflow temperature	30
transistor applications	SWITCHING
Transistor component materials	SILICON
Nominal transition frequency (fT)	250 MHz
Base Number Matches	1

Preview

Download Datasheet

View All

MCC

Features

•

omponents

20736 Marilla

Street Chatsworth

!"#

$ % !"#

DTA114TKA

Built-in bias resistors enable the configuration of an inverter circuit

without connecting external input resistors (see equivalent circuit)

The bias resistors consist of thin-film resistors with complete

isolation to allow negative biasing of the input. They also have the

advantage of almost completely eliminating parasitic effects

Only the on/off conditions need to be set for operation, making

device design easy

PNP Digital Transistor

Absolute Maximum Ratings

Parameter

Collector-Base Voltage

Collector-Emitter Voltage

Emitter-Base voltage

Collector Current-Continuous

Collector Dissipation

Junction Temperature Range

Storage Temperature Range

SOT-23-3L

Base

Emitter

Collector

Symbol

CBO

CEO

EBO

STG

Value

-50

-5

-100

200

-55~150

Unit

℃

Electrical Characteristics

Sym

(BR)CBO

(BR)CEO

(BR)EBO

CBO

EBO

CE(sat)

DIMENSIONS

Parameter

Collector-Base Breakdown Voltage

=-50uA, I

=0)

Collector-Emitter Breakdown Voltage

=-1mA, I

=0)

Emitter-Base Breakdown Voltage

=-50uA, I

=0)

Collector Cut-off Current

=-50V, I

=0)

Emitter Cut-off Current

=-4V, I

=0)

DC Current Gain

=-5V, I

=-1mA)

Collector-Emitter Saturation Voltage

=-10mA, I

=-1mA)

Input Resistor

Transition Frequency

=-10V, I

=-5mA, f=100MHz)

Min

-50

-5

---

100

---

Typ

---

250

---

250

Max

---

-0.5

600

-0.3

---

Unit

---

KΩ

MHz

DIM

MIN

.113

.108

.061

.036

.073

.0016

.044

.006

.013

INCHES

MAX

.117

.112

.065

.038

.077

.0039

.049

.007

.015

Suggested Solder

Pad Layout

.031

.800

MIN

2.87

2.75

1.55

.925

1.85

.04

1.12

.14

.34

MAX

2.97

2.85

1.65

.975

1.95

.100

1.25

.17

.37

NOTE

.035

.900

.087

2.200

inches

.037

.950

.037

.950

www.mccsemi.com

Revision: 1

2005/06/29
