PT-3130 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > PT-3130

Preview

PT-3130: Description3.3V / 1.55 レm / 155 Mbps InGaAs PIN-TIA Receiver; File Size92KB，2 Pages; ManufacturerOptoway; Websitehttp://www.optoway.com

Download Datasheet Compare View All

PT-3130 Overview

3.3V / 1.55 レm / 155 Mbps InGaAs PIN-TIA Receiver

Preview

Download Datasheet

View All

Optoway

3.3V / 1.55

µm

/ 155 Mbps InGaAs PIN-TIA Receiver

FEATURES

InGaAs/InP PIN Photodiode with AGC transimpedance amplifier

Differential ended output

1.55

µm

high sensitivity, 1.3

µm

high rejection

Single +3.3V operation

Speed Up to 170 Mbps

40~+85

ºC

operation temperature

PT-53130

************************************************************************************************************************************************************

PT-53130 Series

************************************************************************************************************************************************************

DESCRIPTION

PT-53130 series are designed as optical signal receivers with AGC transimpedance amplifier.

OC-3/SDH STM-1, Fast Ethernet, and Fiber Channel.

AC / ELECTRICAL AND OPTICAL CHARACTERISTICS (T

=25°C)

Symbol

Parameter

Dectection Range

Active Area

Psat

Sens

Rout

Gain@10Mbs

Differential

Bandwidth

Saturation Power

Sensitivity

Output Resistance

Operation Speed

λ=1300nm

μW

λ=1300nm

BER=10

-10

@155Mbps

120

-3

Test Conditions

Min.

1480

Typ.

1550

140

155

-33

Max.

1600

Unit

μm

V/mW

MHz

dBm

ohm

Mbps

Their wide

dynamic ranges, differential outputs are suited for datacom and telecom applications, especially SONET

Note: *: At least 30 dB isolation for wavelength 1260 nm to 1360 nm

DC / ELECTRICAL CHARACTERISTICS (T

=25°C)

Symbol Parameter

Power Supply

Supply Current (no load)

Min.

3.15

Typ.

3.3

Max.

3.45

Unit

ABSOLUTE MAXIMUM RATING (T

=25

ºC)

Symbol Parameter

opr

stg

Voltage

Operating Temperature

Storage Temperature

Value

4.5

-40~+85

Unit

ºC

*******************************************************************************************************************************************************

OPTOWAY TECHNOLOGY INC.

No.38, Kuang Fu S. Road, Hu Kou, Hsin Chu Industrial Park, Hsin Chu, Taiwan 303

Tel: 886-3-5979798

Fax:886-3-5979737

e-mail: sales@optoway.com.tw

http: // www.optoway.com.tw

4/1/2003 V2.0
