05083
PSMDA05C-4
thru
PSMDA24C-4
STANDARD CAPACITANCE TVS ARRAY
APPLICATIONS
✔
RS-232 & RS-423 Data Lines
✔
Cellular Phones
✔
Audio/Video Inputs
✔
Portable Electronics
✔
Wireless Network Systems
IEC COMPATIBILITY
(EN61000-4)
✔
61000-4-2 (ESD): Air - 15kV, Contact - 8kV
✔
61000-4-4 (EFT): 40A - 5/50ns
✔
61000-4-5 (Surge): 24A, 8/20µs - Level 2(Line-Gnd) & Level 3(Line-Line)
SO-8
FEATURES
✔
500 Watts Peak Pulse Power per Line (tp=8/20µs)
✔
Bidirectional Configurations
✔
Monolithic Design
✔
Available in Voltage Types Ranging From: 5V to 24V
✔
Protects Up to Four (4) Lines
✔
ESD Protection > 40 kilovolts
✔
RoHS Compliant
MECHANICAL CHARACTERISTICS
✔
Molded JEDEC SO-8
✔
Weight 70 milligrams (Approximate)
✔
Available in Lead-Free Pure-Tin Plating(Annealed)
✔
Solder Reflow Temperature:
Pure-Tin - Sn, 100: 260-270°C
✔
Consult Factory for Leaded Device Availability
✔
Flammability Rating UL 94V-0
✔
12mm Tape and Reel Per EIA Standard 481
✔
Marking: Marking Code, Logo, Date Code & Pin One Defined By Dot on Top of Package
PIN CONFIGURATION
8
7
6
5
1
2
3
4
05083.R4 3/07
1
www.protekdevices.com
PSMDA05C-4
thru
PSMDA24C-4
DEVICE CHARACTERISTICS
MAXIMUM RATINGS
@ 25°C Unless Otherwise Specified
PARAMETER
Peak Pulse Power (t
p
= 8/20µs) - See Figure 1
Operating Temperature
Storage Temperature
SYMBOL
P
PP
T
L
T
STG
VALUE
500
-55 to 150
-55 to 150
UNITS
Watts
°C
°C
ELECTRICAL CHARACTERISTICS PER LINE
PART
NUMBER
(See Note 1)
DEVICE
MARKING
CODE
RATED
STAND-OFF
VOLTAGE
MINIMUM
BREAKDOWN
VOLTAGE
@ 25°C Unless Otherwise Specified
MAXIMUM
CLAMPING
VOLTAGE
(See Fig. 2)
@ I
P
= 1A
V
C
VOLTS
9.8
19.0
24.0
43.0
MAXIMUM
CLAMPING
VOLTAGE
(See Fig. 2)
MAXIMUM
LEAKAGE
CURRENT
MAXIMUM
CAPACITANCE
PER LINE
@ V
WM
VOLTS
PSMDA05C-4
PSMDA12C-4
PSMDA15C-4
PSMDA24C-4
TEB
TED
TEF
TEH
5.0
12.0
15.0
24.0
@ 1mA
V
(BR)
VOLTS
6.0
13.3
16.7
26.7
@8/20µs
V
C
@ I
PP
19V @30A
29V @ 20A
32V @ 18A
45V @ 13A
@V
WM
I
D
µA
100
1
1
1
@0V, 1 MHz
C
pF
350
150
120
100
Note 1:
Test individual pins 8 or 5 to pins 1, 2, 3, or 4. Pins 6 and 7 are open.
05083.R4 3/07
2
www.protekdevices.com
PSMDA05C-4
thru
PSMDA24C-4
SO-8 PACKAGE OUTLINE & DIMENSIONS
PACKAGE OUTLINE
-A-
SO-8
8
5
-B - P
0.010 (0.25 MM) M B M
4 PL
+
PACKAGE DIMENSIONS
DIM
A
B
C
D
F
G
J
K
P
R
NOTES
1.
2.
3.
4.
5.
6.
- T - = Seating Plane and Datum Surface.
Dimensions “A” and “B” are Datum.
Dimensions “A” and “B” do not include mold protrusion.
Maximum mold protrusion is 0.015” (0.380 mm) per side.
Dimensioning and tolerances per ANSI Y14.5M, 1982.
Dimensions are exclusive of mold flash and metal burrs.
1
4
MILLIMETERS
MIN
MAX
4.80
3.80
1.35
0.35
0.40
1.27 BSC
0.18
0.10
5.80
0.25
INCHES
MIN
MAX
G
D
C
R x 45°
0° - 10°
K
0.010 (0.25 MM) M T B S A S
8 PL
-T-
+
J
F
0.196
5.00
0.189
0.150
0.157
4.00
1.75
0.054
0.068
0.49
0.014
0.019
0.049
1.250
0.016
1.27 BSC 0.05 BSC 0.05 BSC
0.25
0.007
0.009
0.004
0.008
0.25
6.20
0.229
0.244
0.019
0.50
0.010
MOUNTING PAD
0.050 ± 0.005
0.030 ± 0.005
TAPE & REEL/BULK ORDERING NOMENCLATURE
1. Surface mount product is taped and reeled in accordance with EIA-481.
2. Suffix-T7 = 7 Inch Reel - 1,000 pieces per 12mm tape,
i.e. PSMDA05C-4-T7.
3. Suffix-T13 = 13 Inch Reel - 2,500 pieces per 12mm tape,
i.e., PSMDA05C-4-T13.
4. Suffix - LF = Lead-Free, Pure-Tin Plating, i.e., PSMDA05C-4-LF-T7.
5. No Suffix = Product Shipped in Tubes of 98 pcs per Tube.
0.160 ± 0.005
0.245 MIN
0.045 ± 0.005
Outline & Dimensions: Rev 1 - 11/01, 06009
COPYRIGHT © ProTek Devices 2007
SPECIFICATIONS: ProTek reserves the right to change the electrical and or mechanical characteristics described herein without notice (except JEDEC).
DESIGN CHANGES: ProTek reserves the right to discontinue product lines without notice, and that the final judgement concerning selection and specifications is
the buyer’s and that in furnishing engineering and technical assistance, ProTek assumes no responsibility with respect to the selection or specifications of such
products.
ProTek Devices
2929 South Fair Lane, Tempe, AZ 85282
Tel: 602-431-8101 Fax: 602-431-2288
E-Mail: sales@protekdevices.com
Web Site: www.protekdevices.com
www.protekdevices.com
05083.R4 3/07
4
