5.0SMDJ16CA

Description
极性:Bidirectional 峰值脉冲电流(10/1000us):196.2A 箝位电压:26V 击穿电压(最小值):17.8V 反向关断电压(典型值):16V
CategoryDiscrete semiconductor    TVS diode
File Size2MB,8 Pages
ManufacturerLeiditech
Websitehttp://www.leiditech.com
Download Datasheet Parametric Compare View All

5.0SMDJ16CA Overview

极性:Bidirectional 峰值脉冲电流(10/1000us):196.2A 箝位电压:26V 击穿电压(最小值):17.8V 反向关断电压(典型值):16V

5.0SMDJ16CA Parametric

Parameter NameAttribute value
polarityBidirectional
Peak pulse current (10/1000us)196.2A
clamping voltage26V
Breakdown voltage (minimum value)17.8V
Reverse shutdown voltage (typ)16V
TVS
Surface Mount – 5000W >
5.0SMDJ Series
Description
The 5.0SMDJ series is designed specifically
to protect sensitive electronic equipment
from voltage transients induced by lightning
and other transient voltage events.
Features
5000W peak pulsepower capability at 10 x 1000μs waveform, repetition rate (duty cycle):
0.01%
Glass Passivated chip junction
For surface mounted applications to optimize board space
Low profile package
Built-in strain relief
Low incremental surge resistance
Excellent clamping capability
Plastic package has UL flammability classification 94V-O
Fast response time: typically less than 1.0ps from 0 Volts to BV min
Typical IR less than 5uA above 22V
High temperature soldering: 260°C/40 seconds at terminals
IEC-61000-4-2 ESD 15KV(Air),8KV(Contact)
ESD protection of data lines in accordance with IEC 61000-4-2(IEC801-2)
EFT protection of data lines in accordance with IEC61000-4-4(IEC801-4)
AEC - Q101 qualified.
Applications
TVS devices are ideal for the protection of I/O Interfaces, V
CC
bus and other
vulnerable circuits used in Telecom, Computer, Industrial and Consumer electronic
applications.
Rev
:
01.06.2014
1
/
8
www.leiditech.com

5.0SMDJ16CA Related Products

5.0SMDJ16CA 5.0SMDJ36CA 5.0SMDJ20CA 5.0SMDJ33CA 5.0SMDJ24CA
Description 极性:Bidirectional 峰值脉冲电流(10/1000us):196.2A 箝位电压:26V 击穿电压(最小值):17.8V 反向关断电压(典型值):16V 极性:Bidirectional 峰值脉冲电流(10/1000us):87.8A 箝位电压:58.1V 击穿电压(最小值):40V 反向关断电压(典型值):36V 极性:Bidirectional 峰值脉冲电流(10/1000us):157.4A 箝位电压:32.4V 击穿电压(最小值):22.2V 反向关断电压(典型值):20V 极性:Bidirectional 峰值脉冲电流(10/1000us):95.7A 箝位电压:53.3V 击穿电压(最小值):36.7V 反向关断电压(典型值):33V Polarity: Bidirectional Peak pulse current (10/1000us): 131.1A Clamping voltage: 38.9V Breakdown voltage (minimum): 26.7V Reverse shutdown voltage (typ.): 24V
polarity Bidirectional Bidirectional Bidirectional Bidirectional Bidirectional
Peak pulse current (10/1000us) 196.2A 87.8A 157.4A 95.7A 131.1A
clamping voltage 26V 58.1V 32.4V 53.3V 38.9V
Breakdown voltage (minimum value) 17.8V 40V 22.2V 36.7V 26.7V
Reverse shutdown voltage (typ) 16V 36V 20V 33V 24V
