Plastic Film Capacitors
Stacked Metallized PPS Film
Chip Capacitor
Type :
ECHU(X)
Stacked metallized PPS film as dielectric with simple
mold-less construction
Features
●
Small in size (Minimum size 1.6 mm
×
0.8
●
85 °C, 85 %RH, W.V.
×
1.0 for 500 hours
●
For reflow soldering
●
RoHS directive compliant
mm)
Recommended applications
●
Time-constant
●
Filtering
●
Oscillation and
●
Audio circuit
resonance
Explanation of part number
1
2
3
4
5
6
7
8
9
10
11
12
E
C
H
U
Rated voltage
Capacitance
Cap. Tol.
X
Suffix
Suffix
Product code
Dielectric &
construction
1C 16 V.DC
1H 50 V.DC
G
J
±2 %
±5 %
Code Tape width Reel diameter
½
Tape width 8 mm
and diameter
8 mm
f180
mm
5
f330
mm reel is
9 12 mm
f330
mm
prepared
Specifications
Category temp. range
(Including temperature-rise on unit surface)
Rated voltage
Capacitance range
Capacitance tolerance
Dissipation factor (tan
d)
Withstand voltage
Insulation resistance (IR)
Soldering conditions
– 55 °C to +125 °C
16 V.DC, 50 V.DC
(50 V.DC : 0.12 μF or more : Derating or rated voltage by 1.25 % / °C at more than 105 °C)
16 V.DC
0.00010 μF to 0.10 μF (E12)
50 V.DC
0.00010 μF to 0.22 μF (E12)
±2 %(G), ±5 %(J)
tan
d
<
0.6 % (20 °C, 1 kHz)
Between terminals : Rated volt. (V.DC)×150 %, 60 s
16 V.DC : IR
>
3000 MΩ (20 °C, 10 V.DC, 60 s)
50 V.DC : IR
>
3000 MΩ (20 °C, 50 V.DC, 60 s)
Reflow soldering : 260 °C max. and 95 sec max. at more than 220 °C (Temp. at capacitor surface)
½
Please consult us for flow soldering
½
In case of applying voltage in alternating current (50 Hz or 60 Hz sine wave) to a capacitor with DC rated voltage,
please refer to the page of “Permissible voltage (R.M.S) in alternating current corresponding to DC rated voltage”.
Construction
Dimensions
(±0.3)
½ ½ ½
(±0.15)
½ ½
W±0.2
H±0.2
(±0.15)
½ ½
Size code
K1
J1
J2
H1
H2
H3
G1
G2
G3
E1
E2
D1
D3
D4
Unit : mm
L
W
H
e
g
1.6 0.8 0.7 0.35
>
0.4
2.0 1.25 0.9 0.45
>
0.6
2.0 1.25 1.1 0.45
>
0.6
3.2 1.6 0.9 0.65
>
1.0
3.2 1.6 1.1 0.65
>
1.0
3.2 1.6 1.5 0.65
>
1.0
3.2 2.5 1.1 0.65
>
1.0
3.2 2.5 1.5 0.65
>
1.0
3.2 2.5 2.1 0.65
>
1.0
4.8 3.3 1.5 0.80
>
2.0
4.8 3.3 2.1 0.80
>
2.0
6.0 4.1 1.9 0.80
>
2.0
6.0 4.1 2.5 0.80
>
2.0
6.0 4.1 2.8 0.80
>
2.0
L±0.2
Element
(Stacked)
Outer electrode
e±0.30
e±0.30
g
(±0.25)
½
(±0.25)
½
(±0.20)
½ ½
(±0.20)
½ ½
½
To be applied only for size code J1, J2
½½
To be applied only for size code K1
½½½
To be applied only for size code E1, E2, D1, D3, D4
Design and specifications are each subject to change without notice. Ask factory for the current technical specifications before purchase and/or use.
Should a safety concern arise regarding this product, please be sure to contact us immediately.
02 Sep. 2017
Plastic Film Capacitors
Taping specification for automatic mounting
Refer to the page of taping specifications
Rating · Dimensions · Quantity
●
Capacitance
tolerance : ±2 %(G), ±5 %(J)
Rated voltage 16 V.DC
Dimensions (mm) Size
Part No.
Q'ty
L
W
H code
ECHU1C101◻X5
1.6 0.8 0.7
K1
ECHU1C121◻X5
1.6 0.8 0.7
K1
ECHU1C151◻X5
1.6 0.8 0.7
K1
ECHU1C181◻X5
1.6 0.8 0.7
K1
ECHU1C221◻X5
1.6 0.8 0.7
K1
ECHU1C271◻X5
1.6 0.8 0.7
K1
ECHU1C331◻X5
1.6 0.8 0.7
K1
ECHU1C391◻X5
1.6 0.8 0.7
K1
ECHU1C471◻X5
1.6 0.8 0.7
K1
4000
ECHU1C561◻X5
1.6 0.8 0.7
K1
ECHU1C681◻X5
1.6 0.8 0.7
K1
ECHU1C821◻X5
1.6 0.8 0.7
K1
ECHU1C102◻X5
1.6 0.8 0.7
K1
ECHU1C122◻X5
1.6 0.8 0.7
K1
ECHU1C152◻X5
1.6 0.8 0.7
K1
ECHU1C182◻X5
1.6 0.8 0.7
K1
ECHU1C222◻X5
1.6 0.8 0.7
K1
ECHU1C272◻X5
1.6 0.8 0.7
K1
ECHU1C332◻X5
2.0 1.25 0.9
J1
ECHU1C392◻X5
2.0 1.25 0.9
J1
ECHU1C472◻X5
2.0 1.25 0.9
J1
ECHU1C562◻X5
2.0 1.25 0.9
J1
ECHU1C682◻X5
2.0 1.25 0.9
J1
ECHU1C822◻X5
2.0 1.25 1.1
J2
ECHU1C103◻X5
2.0 1.25 1.1
J2 3000
ECHU1C123◻X5
3.2 1.6 0.9
H1
ECHU1C153◻X5
3.2 1.6 0.9
H1
ECHU1C183◻X5
3.2 1.6 0.9
H1
ECHU1C223◻X5
3.2 1.6 0.9
H1
ECHU1C273◻X5
3.2 1.6 1.1
H2
ECHU1C333◻X5
3.2 1.6 1.1
H2
ECHU1C393◻X5
3.2 1.6 1.5
H3
ECHU1C473◻X5
3.2 1.6 1.5
H3
ECHU1C563◻X5
3.2 2.5 1.5 G2
2000
ECHU1C683◻X5
3.2 2.5 1.5 G2
ECHU1C823◻X5
3.2 2.5 2.1 G3
ECHU1C104◻X5
3.2 2.5 2.1 G3
Rated voltage 50 V.DC
Dimensions (mm) Size
Part No.
Q'ty
L
W
H code
ECHU1H101◻X5
2.0 1.25 0.9
J1
ECHU1H121◻X5
2.0 1.25 0.9
J1
ECHU1H151◻X5
2.0 1.25 0.9
J1
ECHU1H181◻X5
2.0 1.25 0.9
J1
ECHU1H221◻X5
2.0 1.25 0.9
J1
ECHU1H271◻X5
2.0 1.25 0.9
J1
ECHU1H331◻X5
2.0 1.25 0.9
J1
ECHU1H391◻X5
2.0 1.25 0.9
J1
ECHU1H471◻X5
2.0 1.25 0.9
J1
ECHU1H561◻X5
2.0 1.25 0.9
J1
ECHU1H681◻X5
2.0 1.25 0.9
J1
ECHU1H821◻X5
2.0 1.25 0.9
J1
ECHU1H102◻X5
2.0 1.25 0.9
J1 3000
ECHU1H122◻X5
2.0 1.25 0.9
J1
ECHU1H152◻X5
2.0 1.25 0.9
J1
ECHU1H182◻X5
2.0 1.25 0.9
J1
ECHU1H222◻X5
2.0 1.25 0.9
J1
ECHU1H272◻X5
2.0 1.25 0.9
J1
ECHU1H332◻X5
3.2 1.6 0.9
H1
ECHU1H392◻X5
3.2 1.6 0.9
H1
3.2 1.6 0.9
H1
ECHU1H472◻X5
ECHU1H562◻X5
3.2 1.6 0.9
H1
ECHU1H682◻X5
3.2 1.6 0.9
H1
ECHU1H822◻X5
3.2 1.6 1.1
H2
ECHU1H103◻X5
3.2 1.6 1.1
H2
ECHU1H123◻X5
3.2 2.5 1.1 G1
ECHU1H153◻X5
3.2 2.5 1.1 G1
ECHU1H183◻X5
3.2 2.5 1.5 G2
ECHU1H223◻X5
3.2 2.5 1.5 G2 2000
ECHU1H273◻X5
3.2 2.5 1.5 G2
ECHU1H333◻X5
3.2 2.5 2.1 G3
3.2 2.5 2.1 G3
ECHU1H393◻X5
ECHU1H473◻X9
4.8 3.3 1.5
E1
ECHU1H563◻X9
4.8 3.3 1.5
E1
ECHU1H683◻X9
4.8 3.3 1.5
E1
ECHU1H823◻X9
4.8 3.3 2.1
E2 3000
ECHU1H104◻X9
4.8 3.3 2.1
E2
ECHU1H124◻X9
6.0 4.1 1.9
D1
ECHU1H154◻X9
6.0 4.1 1.9
D1
ECHU1H184◻X9
6.0 4.1 2.5
D3
2000
ECHU1H224◻X9
6.0 4.1 2.8
D4
Capacitance
(μF)
0.00010
0.00012
0.00015
0.00018
0.00022
0.00027
0.00033
0.00039
0.00047
0.00056
0.00068
0.00082
0.0010
0.0012
0.0015
0.0018
0.0022
0.0027
0.0033
0.0039
0.0047
0.0056
0.0068
0.0082
0.010
0.012
0.015
0.018
0.022
0.027
0.033
0.039
0.047
0.056
0.068
0.082
0.10
0.12
0.15
0.18
0.22
½
◻
: Capacitance tolerance code
Recommended for land dimensions
Electrode
Unit : mm
Land
C
Size
code
K1
J1, J2
H1, H2, H3
G1, G2, G3
E1, E2
D1, D3, D4
A
B
Land dimensions
Reflow soldering
A
B
C
0.6
2.0
0.7
0.8
2.4
1.1
1.8
3.6
1.4
1.8
3.6
2.3
3.0
5.6
3.0
4.0
7.0
3.8
½
lt is not warrantable that you can mount the capacitor without trouble under all the mounting condition when “Recommender for Land dimensions” is adopted.
Design and specifications are each subject to change without notice. Ask factory for the current technical specifications before purchase and/or use.
Should a safety concern arise regarding this product, please be sure to contact us immediately.
02 Sep. 2017
