Conductive Polymer Tantalum Solid Capacitors
Surface Mount Type
Series :
TQC
Size :
B
Features
●
High
voltage (35 V.DC max.)
●
RoHS compliance, Halogen free
Specifications
Size code
Category temperature range
Rated voltage range
Category voltage range
Rated capacitance range
Capacitance tolerance
Leakage current
Dissipation factor (tan
d)
Surge voltage (V.DC)
Endurance
B15
–55 °C to +105 °C
35 V.DC
35 V.DC
2.7 μF
16 V.DC to 35 V.DC
16 V.DC to 35 V.DC
3.9 μF to 33 μF
B2
Damp heat
(Steady State)
±20 % (120 Hz / + 20 °C)
Please see the attached characteristics list
Please see the attached characteristics list
Rated voltage
×
1.15
+105 °C, 2000 h (16TQC33MYFB : 1000 h), rated voltage applied
Capacitance change Within ±20 % of the initial value
tan
d
<
1.5 times of the initial limit
DC leakage current Within the initial limit
+60 °C, 90 % to 95 %, 500 h, No-applied voltage
Capacitance change Within +40 %, −20 % of the initial value
tan
d
<
1.5 times of the initial limit
DC leakage current
<
3 times of the initial limit
Marking
Polarity marking(+)
R.Cap. code
Dimensions (not to scale)
L
W
R. Voltage code
Lot. No.
S
S
H
W1
R. Voltage (V.DC)
Code
16
C
20
D
25
E
35
V
10
A7
15
E7
22
J7
33
N7
Unit : mm
R. Cap. (μF) 2.7 3.9 5.6 8.2
Code
L6 Q6 U6 Y6
Size code L±0.2
B15
3.5
B2
3.5
W±0.2
2.8
2.8
H±0.1
1.4
1.9
S±0.2
0.8
0.8
W1±0.1
2.2
2.2
½
Externals of figure are the reference.
Characteristics list
Rated Rated
Category Category Rated
Series voltage temp.
voltage temp. capacitance
(V.DC) (°C) (V.DC) (°C) (μF)
105
105
105
105
105
105
105
105
105
16.0
16.0
16.0
20.0
20.0
25.0
25.0
35.0
35.0
105
105
105
105
105
105
105
105
105
10
15
33
8.2
22
5.6
15
2.7
3.9
Case size (mm)
½1
Specifications
Standard
Min.
Packaging Q'ty
(pcs)
2000
2000
2000
2000
2000
2000
2000
2000
2000
L
3.5
3.5
3.5
3.5
3.5
3.5
3.5
3.5
3.5
W
2.8
2.8
2.8
2.8
2.8
2.8
2.8
2.8
2.8
H
1.9
1.9
1.9
1.9
1.9
1.9
1.9
1.4
1.9
16
TQC
20
25
35
Size Ripple
½2
LC
½4
code current ESR
Part number
tan
d
½3
(mΩ max.)
(μA)
(mAr.m.s.)
800
100
0.10
48.0
16TQC10M
1000
90
0.10
72.0
16TQC15M
1000
90
0.10
158.4
16TQC33MYFB
800
100
0.10
49.2
20TQC8R2M
B2
1100
90
0.10
132.0
20TQC22MYFB
800
100
0.10
42.0
25TQC5R6M
900
100
0.10
112.5
25TQC15MYFB
B15
800
300
0.10
47.3
35TQC2R7MYF
B2
500
400
0.10
40.9
35TQC3R9MYF
½1
Ripple current (100 kHz/ +105 °C ),
½2
ESR (100 kHz/+20 °C)
½3
tan
d
(120 Hz/+20 °C)
½4
After 5 minutes
◆
Please refer to each page in this catarog for “Reflow conditions” and “Taping specifications”.
Design and specifications are each subject to change without notice. Ask factory for the current technical specifications before purchase and/or use.
Should a safety concern arise regarding this product, please be sure to contact us immediately.
01 Nov. 2015
