AQG12205 datasheet, PDF - EEWORLD Datasheet

EEWORLDEEWORLD

Datasheet

Datasheet> All Categories > LED optoelectronic/LED> photoelectric> AQG12205

Preview

AQG12205: CategoryLED optoelectronic/LED photoelectric; File Size265KB，2 Pages; ManufacturerPanasonic; Websitehttp://www.panasonic.co.jp/semicon/e-index.html; Environmental Compliance

Download Datasheet Parametric View All

AQG12205 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	AQG12205	-	-	View	Buy Now

AQG12205 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
package instruction	ROHS COMPLIANT PACKAGE-4
Reach Compliance Code	compliant
Other features	UL RECOGNIZED, VDE APPROVED
Configuration	SINGLE
control voltage	1 V
input type	DC
Maximum insulation voltage	3000 V
Number of components	1
Maximum on-state current	1 A
Maximum operating temperature	80 °C
Minimum operating temperature	-30 °C
Optoelectronic device types	TRIGGER OUTPUT SSR
Output circuit type	Triac
total height	13.5 mm
total length	24.5 mm
Base Number Matches	1

Preview

Download Datasheet

View All

2017/8/7

AQG12205 | AQG 可控硅输出光电耦合器 | 松下电器机电（中½）有限公司控制机器 | Panasonic

品番

型号

详细

※产品实际尺寸以实物为

准。

特长

截至2017年08月07日

为了改善本产品，会有在未事先通知的情况下变更本产品的规格及设计的情况。

订货产品号

型号

½状

端子½状

过零功½

类型

负½½电压

最大允许负½½电流

漏电流

浪涌导通电流

额定操½电压

输入电阻

动½电压

复½电压

动½时间

AQG12205

SIL4pin

PCB, Thruhole

No

AC output

75264V AC

1A

1.5mA

8A

5V DC

0.3kOhm

4V

1V

1ms

1/2

https://device.panasonic.cn/ac/c/search_num/index.jsp?c=detail_print&part_no=AQG12205

用板基刷印的关开，½性本成极终求½

器合耦电光出输硅控可

产品名称

器合耦电光出输硅控可

AQG12205

AC output,1A

AQG

1A/2A

SSD

AQG12205 | AQG

容内

线热服客

目项

4009209200

受理时间：9:1517:15(11:30½13:00、本公司休息日除外)

细详格规
