RKJXK
ThumbPointer
TM
（Stick Controller）
RKJXV
Compact size, standard type. Also available with lever return
mechanism
■
Typical Specifications
（Potentiometer）
Items
Rated power
Maximum operating voltage
Operating angle
RKJXK
0.0125W
RKJXV
50V AC, 5V DC
60°
±6°
8mN m max.
・
（Not lever return type）
6±4mN m
・
（Lever return type）
100,000 cycles
23°max. in each
direction ※
Operating force
14±10mN m
・
Operating life
2,000,000 cycles
Note
※ If the lever is tilted more than 23°from the vertical position,
operating feel irregularities or return mechanism errors may occur.
Therefore, please do not tilt more than 23°
.
Multi Control
Devices
■
Typical Specifications
（Center-push）
Items
Ratings（max.）
Operating force
Travel
Operating life
RKJXK
RKJXV
Variable
Resistor Type
50mA 12V DC
5.2±2.6N
0.5 mm
−0.4
100,000 cycles
＋0.5
7.4±3N
0.4 mm
−0.3
500,000 cycles
＋0.5
Switch
Type
Product Line
Product No.
RKJXK122400Y
RKJXK122000D
RKJXK1210002
RKJXV1224005
RKJXV1220001
Without
With
With
Without
1,420
1,420
4
Lever return
mechanism
With
Center-push
With
Total resistance Resistance
（kΩ）
taper
Minimum order unit（pcs.） Drawing
No.
Japan
Export
1
500
1,000
2
Without
10
B
（0B）
3
Packing Specifications
Tray
Product No.
RKJXK
RKJXV
Number of packages
（pcs.）
1 case / Japan
1 case / export packing
500
1,000
Export package
measurements（mm）
373×540×225
1,420
1,420
544×364×
178
Refer to P.454 for soldering conditions.
449
Multi Control Devices
List of Varieties
Type
Series
Variable resistor type
RKJXK
RKJXV
RKJXY
RKJXU
Dimensions
（typical value）
（mm）
W
D
H
20.7
25.4
12.9
17.8
21.3
1
1.2
Single-shaft
19.6
18.1
4.9
18.6
24.3
5.2
Number ofoperating shafts
Shaft material
Directional resolution
Directional operating feeling
（tactile feeling）
Lever return mechanism
Center-push switch
Encoder
Operating temperature range
Operating
life
Directional operation
Center-push
100,000 cycles
100,000 cycles
ー
With / Without
With / Without
Metal
Resin
Continuous
Without
With
Without
Without
−
10℃ to ＋70℃
2,000,000 cycles
500,000 cycles
ー
1,000,000 cycles
ー
ー
2,000,000 cycles
ー
ー
Variable
Resistor Type
Multi Control
Devices
Automotive use
Life cycle (availability)
Insulation resistance
Electrical
performance
Voltage proof
Slider noise
Directional
operating force
Mechanical
performance
Push operating force
Lever return precision
Actuator
strength
Environmental
performance
Push / pull
directions
Operating
direction
100MΩ min. 250V DC
250V AC for 1 minute
ー
ー
300mV p-p max. by JIS method
ー
ー
Switch
Type
8mN m max. Without Lever return mechanism
・
6±4mN m With Lever return mechanism
・
5.2±2.6N
14±
10mN½m
7.4±3N
±5°
0.43±0.25N
ー
0.75±0.3N
ー
±0.1mm
50N min.（Push/Pull）
0.3N½m
98N min.（Push）50N min.（Pull） 100N min.（Push）49N min.（Pull）100N min.（Push）30N min.（Pull）
,
,
,
ー
−30℃ 96h
80℃ 96h
60℃, 90 to 95％RH 96h
449
452
453
50N
Cold
Dry heat
Damp heat
Page
Variable Resistor Type Multi Control Devices Soldering Conditions ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ 454
Variable Resistor Type Multi Control Devices Cautions ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ 454
445
Variable Resistor Type / Soldering Conditions
Reference for Manual Soldering
Series
RKJXK, RKJXV
Tip temperature
350℃max.
Soldering time
3s max.
No. of solders
1 time
Reference for Dip Soldering
Series
RKJXK
RKJXV
Preheating
Heating time
Soldering surface temperature
90 to 100℃
90 to 100℃
45s max.
60s max.
Dip soldering
Soldering temperature Soldering time
260℃
260℃
5s
5s
No. of solders
1 time
1 time
Variable Resistor Type / Cautions
Multi Control
Devices
Variable
Resistor Type
Switch
Type
〔Circuit Used for Analog Stick Controller〕
We recommend you use the variable resistor in a voltage
divider type as shown in Fig. A.
Fig.A.Voltage divider type
V
3
3
2
〔Impedance on the Output Side〕
1
3
2
A/D
3
3
2
V
1
3
2
A/D
A/D
Since this pot is designed to use with its output is
connected directly to A /D port. lmpedance is considered
to be mega ohm level. Then contact resistance in the pot
is higher. Please refer to Flg-1. So when you use it in the
circuit like Flg-2.Please make sure that impedance should be
over than 1M-ohm.
[Fig.1]
[Fig.2]
1
1
1
1
p
p
ppp
p
Terminal
Solder
p
〔Dew Condensation〕
Avoid using the product when condensation or drops of water might occur
inside the product. Otherwise, insulation deterioration or shorting may occur.
〔Soldering〕
Solder
PC board
Do not employ wiring designs and soldering methods as illustrated in the schematic drawing. Molten
solder flowing over the upper surface of PC board can cause imperfect contacts. Solder all metal
inserted fixing including terminals & metal lugs into a substrate.
〔Stress Being Applied to the Terminals〕
Always be careful not to apply excessive stress on the terminals. Design appropriate soldering conditions.
〔Handling of Variable Resistors Equipped with Switches〕
Exercise care when packing or storing. Packaging or storing while load is applied to the shaft may
cause a malfunction in performance.
〔Storage〕
① Store the products as delivered, at a normal temperature and humidity, without direct sunshine and
corrosive gas ambient. Use them at an earliest possible timing, not later than six months upon receipt.
② After breaking the seal, keep the products in a plastic bag to shut out ambient air, store them in the same
environment as above, and use them up as soon as possible.
③ Do not stack too many switches.
The above operation notes are quoted from the
“Precaution and Guideline of Potentiometer for Electrical Devices”, a technical report issued by the Japan
Electronics and Information Technology Industries Association EIAJ RCR-2191A
（in March 2002）
.
For details, refer to the original technical report.
454
