Ceramic Chip Capacitors
Table of Contents
How to Order -
AVX Part Number Explanation...........
2-3
C0G (NP0) Dielectric
General Specifications .................................................................
4
Specifications and Test Methods.................................................
5
Capacitance Range ..................................................................
6-7
MLCC Low Profile
General Specifications / Capacitance Range............................
54
Automotive MLCC
General Specifications .........................................................
55-56
Capacitance Range..............................................................
57-59
U Dielectric
RF/Microwave C0G (NP0) Capaciators (RoHS)
General Information and Capacitance Range ....................
8-10
RF/Microwave C0G (NP0) Capaciators (Sn/Pb)
General Information and Capacitance Range ..................
11-12
RF/Microwave C0G (NP0) Capaciators (RoHS)
AEC-Q200 Qualified..........................................................
13-14
Designer Kits ..............................................................................
15
APS for COTS+ Applications
General Specifications ...............................................................
60
Capacitance Range..............................................................
61-63
MLCC with FLEXITERM
®
General Description....................................................................
64
Specifications and Test Methods.........................................
65-66
Capacitance Range..............................................................
67-68
X8R/X8L Dielectric
General Specifications .........................................................
16-17
Specifications and Test Methods...............................................
18
FLEXISAFE MLC Chips
General Specifications and Capacitance Range.......................
69
Capacitor Array
Capacitor Array (IPC) ...........................................................
70-73
Automotive Capacitor Array (IPC)..............................................
74
Part and Pad Layout Dimensions ..............................................
75
X7R Dielectric
General Specifications ...............................................................
19
Specifications and Test Methods...............................................
20
Capacitance Range..............................................................
21-22
X7S Dielectric
General Specifications ...............................................................
23
Specifications and Test Methods...............................................
24
Capacitance Range....................................................................
25
Low Inductance Capacitors
Introduction
...................................................................76-77
LICC (Low Inductance Chip Capacitors)
..........................78-81
IDC (InterDigitated Capacitors) ............................................
82-85
LGA (Low Inductance Capacitors)
...................................86-88
High Temperature MLCCs
AT Series 200ºC & 250ºC Rated MLCCs
..........................89-94
X5R Dielectric
General Specifications ...............................................................
26
Specifications and Test Methods...............................................
27
Capacitance Range..............................................................
28-29
Y5V Dielectric
General Specifications ...............................................................
30
Specifications and Test Methods...............................................
31
Capacitance Range....................................................................
32
High Voltage MLC Chips
600V to 5000V Applications
............................................95-99
Tin/Lead Termination “B” - 600V to 5000V Applications
...100-101
FLEXITERM
®
- 600V to 5000V Applications
..................102-106
600V to 3000V Automotive Applications – AEC-Q200
...107-108
MIL-PRF-55681/Chips
CDR01 thru CDR06 .........................................................
109-110
CDR31 thru CDR35 .........................................................
111-114
MLCC Gold Termination (AU Series)
General Specifications ...............................................................
33
Capacitance Range..............................................................
34-39
MLCC Medical
MQ Series ........................................................................
115-123
MM Series........................................................................
124-128
MLCC Tin/Lead Termination (LD Series)
C0G (NP0) General Specifications.............................................
40
Specifications and Test Methods ............................
41
Capacitance Range ...........................................
42-43
X8R
General Specifications.............................................
44
Specifications and Test Methods ............................
45
Capacitance Range .................................................
46
X7R
General Specifications.............................................
47
Specifications and Test Methods ............................
48
Capacitance Range ...........................................
49-50
X5R
General Specifications.............................................
51
Specifications and Test Methods ............................
52
Capacitance Range .................................................
53
Packaging of Chip Components
.....................................
129
Embossed Carrier Configuration - 8 & 12mm Tape
...
130
Paper Carrier Configuration - 8 & 12mm Tape
............
131
Basic Capacitor Formulas
................................................
132
General Description
...................................................
133-137
Surface Mounting Guide
...........................................
138-142
How to Order
Part Number Explanation
Commercial Surface Mount Chips
EXAMPLE: 08055A101JAT2A
0805
Size
(L" x W")
0101*
0201
0402
0603
0805
1206
1210
1812
1825
2220
2225
*EIA 01005
5
Voltage
4 = 4V
6 = 6.3V
Z = 10V
Y = 16V
3 = 25V
D = 35V
5 = 50V
1 = 100V
2 = 200V
7 = 500V
A
Dielectric
A = NP0(C0G)
C = X7R
D = X5R
F = X8R
G = Y5V
U = U Series
W = X6S
Z = X7S
101
Capacitance
2 Sig. Fig +
No. of Zeros
Examples:
100 = 10 pF
101 = 100 pF
102 = 1000 pF
223 = 22000 pF
224 = 220000 pF
105 = 1μF
106 = 10μF
107 = 100μF
For values below
10 pF, use “R”
in place of
Decimal point, e.g.,
9.1 pF = 9R1.
J*
Tolerance
A
Failure
T
Terminations
2
Packaging
Available
2 = 7" Reel
4 = 13" Reel
U = 4mm TR
(01005)
A**
Special
Code
A = Std
K = 30K (0603 2mm pitch)
22K (0805/1206
<0.030"/ 0.76mm)
H = 18K (0603/0805/1206
<0.037” / 0.94mm)
J = 15K (0805/1206
<0.050” / 1.27mm)
1 = 12K (0805/1206
<0.055 / 1.4mm)
**Non std options upon
approval from the factory
Contact Factory for
Special Voltages
F
*
E
V
= 63V
= 75V
= 150V
= 250V
9 = 300V
X = 350V
8 = 400V
B = ±.10 pF
T = Plated Ni
Rate
C = ±.25 pF
and Sn
A = N/A
D = ±.50 pF 4 = Automotive 7 = Gold Plated
F = ±1%
U = Conductive
(≥ 10 pF)
Expoxy for
G = ±2%
Hybrid
(≥ 10 pF)
Applications
J = ±5%
Z = FLEXITERM
®
K = ±10%
*X
= FLEXITERM
®
M = ±20%
with 5% min
Z = +80%,
lead (X7R &
-20%
X8R only)
P = +100%,
-0%
Contact
Contact
Factory For
Multiples
Factory For
1 = Pd/Ag Term
* B, C & D tolerance for ≤10 pF values.
Standard Tape and Reel material (Paper/Embossed) depends upon chip size and thickness.
See individual part tables for tape material type for each capacitance value.
NOTE: Contact factory for availability of Termination and Tolerance Options for Specific Part Numbers.
For Tin/Lead Terminations, please refer to LD Series
High Voltage MLC Chips
EXAMPLE: 1808AA271KA11A
1808
A
A
271
K
A
T
2
A
AVX
Style
0805
1206
1210
1808
1812
1825
2220
2225
3640
Voltage
Temperature Capacitance Capacitance
Failure
Packaging/
Termination
C
=
600V/630V
Coefficient
Code
Tolerance
Rate
Marking
1= Pd/Ag
(2 significant digits
C0G: J = ±5%
2 = 7" Reel
A
=
1000V
A = C0G
A=Not
T = Plated Ni
+ no. of zeros)
K = ±10% Applicable
4 = 13" Reel
S
=
1500V
C = X7R
and Sn
Examples:
M = ±20%
G
=
2000V
B = 5% Min Pb
10 pF = 100 X7R: K = ±10%
W
=
2500V
Z = FLEXITERM
®
100 pF = 101
M = ±20%
H
=
3000V
*X
= FLEXITERM
®
1,000 pF = 102
Z = +80%,
J
=
4000V
with 5% min
22,000 pF = 223
-20%
K
=
5000V
lead (X7R only)
220,000 pF = 224
1 μF = 105
*
Special
Code
A = Standard
NOTE: Contact factory for availability of Termination and Tolerance Options for Specific Part Numbers.
For Tin/Lead Terminations, please refer to LD Series
Not RoHS Compliant
For RoHS compliant products,
please select correct termination style.
2
REV 1
How to Order
Part Number Explanation
Capacitor Array
EXAMPLE: W2A43C103MAT2A
W
2
A
4
3
Voltage
Z = 10V
Y = 16V
3 = 25V
5 = 50V
1 = 100V
C
103
M
A
T
2A
Packaging &
Quantity
Code
2A = 7" Reel
(4000)
4A = 13" Reel
(10000)
2F = 7" Reel
(1000)
Style
Case Array Number
Size
of Caps
W = RoHS
1 = 0405
L = SnPb
2 = 0508
3 = 0612
Dielectric Capacitance
A = NP0
Code (In pF)
C = X7R 2 Sig Digits +
Number of
D = X5R
Zeros
Capacitance
Failure
Termination
Tolerance
Rate
Code
J = ±5% A = Commercial T = Plated Ni and Sn
K = ±10% 4 = Automotive Z = FLEXITERM
®
M = ±20%
*B
= 5% min lead
*X
= FLEXITERM
®
with 5% min lead
NOTE: Contact factory for availability of Termination and Tolerance Options for Specific Part Numbers.
Low Inductance Capacitors (LICC)
EXAMPLE: 0612ZD105MAT2A
0612
Size
0306
0508
0612
*LD16
*LD17
*LD18
Z
Voltage
6 = 6.3V
Z = 10V
Y = 16V
3 = 25V
5 = 50V
D
Dielectric
C = X7R
D = X5R
105
Capacitance
Code (In pF)
2 Sig. Digits +
Number of Zeros
M
Capacitance
Tolerance
K = ±10%
M = ±20%
A
T
2
Packaging
Available
2 = 7" Reel
4 = 13" Reel
A
Thickness
See Page 81
for Codes
Failure Rate Terminations
A = N/A
T = Plated Ni
and Sn
*B
= 5% min
lead
NOTE: Contact factory for availability of Termination and Tolerance Options for Specific Part Numbers.
Interdigitated Capacitors (IDC)
EXAMPLE: W3L16D225MAT3A
W
3
L
1
6
D
Dielectric
C = X7R
D = X5R
225
M
A
Failure
Rate
A = N/A
T
3
A
Thickness
Max. Thickness
mm (in.)
Style
Case
Low
Voltage
Number
Inductance
of
W = RoHS
Size
4 = 4V
L = SnPb 2 = 0508 ESL = 50pH
Terminals
6 = 6.3V
3 = 0612 ESL = 60pH 1 = 8 Terminals Z = 10V
Y = 16V
Capacitance Capacitance
Code (In pF)
Tolerance
M = ±20
2 Sig. Digits +
Number of
Zeros
Termination Packaging
T = Plated Ni Available
and Sn
1=7" Reel
*B
= 5% min 3=13" Reel
Lead
A=0.95 (0.037)
S=0.55 (0.022)
NOTE: Contact factory for availability of Termination and Tolerance Options for Specific Part Numbers.
Low Inductance Decoupling Capacitor Arrays (LICA)
EXAMPLE: LICA3T183M3FC4AA
LICA
Style
&
Size
3
T
102
M
3
F
Termination
*F
= C4 Solder
Balls- 97Pb/3Sn
H = C4 Solder
Balls–Low ESR
P = Cr-Cu-Au
N = Cr-Ni-Au
X = None
C
4
A
A
Voltage Dielectric Cap/Section Capacitance Height
5V = 9 D = X5R
(EIA Code)
Tolerance
Code
10V = Z T = T55T 102 = 1000 pF M = ±20% 6 = 0.500mm
25V = 3 S = High K 103 = 10 nF
P = GMV 3 = 0.650mm
T55T 104 = 100 nF
1 = 0.875mm
5 = 1.100mm
*
Not RoHS Compliant
7 = 1.600mm
# of
Inspection
Code
Reel Packaging
Caps/Part
Code
Face
M = 7" Reel
1 = one A = Standard
A = Bar
R = 13" Reel
6 = 2"x2" Waffle Pack 2 = two B = Established B = No Bar
Reliability
C = Dot, S55S
8 = 2"x2" Black Waffle 4 = four
Testing
Dielectrics
Pack
D = Triangle
7 = 2"x2" Waffle Pack
w/ termination
facing up
A = 2"x2" Black Waffle
Pack
NOTE: Contact factory for
w/ termination
availability of Termination and
facing up
Tolerance Options for Specific
C = 4"x4" Waffle Pack
Part Numbers.
w/ clear lid
REV 1
3
C0G (NP0) Dielectric
General Specifications
C0G (NP0) is the most popular formulation of the
“temperature-compensating,” EIA Class I ceramic materials.
Modern C0G (NP0) formulations contain neodymium, samarium
and other rare earth oxides.
C0G (NP0) ceramics offer one of the most stable capacitor
dielectrics available. Capacitance change with temperature
is 0 ±30ppm/°C which is less than ±0.3% C from -55°C to
+125°C. Capacitance drift or hysteresis for C0G (NP0) ceramics
is negligible at less than ±0.05% versus up to ±2% for films.
Typical capacitance change with life is less than ±0.1% for C0G
(NP0), one-fifth that shown by most other dielectrics. C0G (NP0)
formulations show no aging characteristics.
PART NUMBER (see page 2 for complete part number explanation)
0805
Size
5
Voltage
A
Dielectric
101
Capacitance
Code (In pF)
J
Capacitance
Tolerance
A
Failure
Rate
A = Not
Applicable
T
Terminations
T = Plated Ni
and Sn
Contact
Factory For
1 = Pd/Ag Term
2
Packaging
A
Special
Code
A = Std.
Product
(L” x W”)
6.3V = 6
10V = Z
16V = Y
25V = 3
50V = 5
100V = 1
200V = 2
500V = 7
C0G (NP0) = A
2 Sig. Digits +
Number of Zeros
B = ±.10 pF (<10pF)
C = ±.25 pF (<10pF)
D = ±.50 pF (<10pF)
F = ±1% (≥ 10 pF)
G = ±2% (≥ 10 pF)
J = ±5%
K = ±10%
U = 4mm TR
(01005)
2 = 7” Reel
4 = 13” Reel
7 = Gold Plated
NOT RoHS
COMPLIANT
NOTE: Contact factory for availability of Termination and Tolerance Options for Specific Part
Numbers. Contact factory for non-specified capacitance values.
Contact Factory
For Multiples
4
051818
Buy&Sell
京公网安备 11010802033920号
EEWORLD
