74AUP2G3404
BUFFER AND INVERTER
Description
The Advanced Ultra Low Power (AUP) CMOS logic family is designed
for low power and extended battery life in portable applications.
The 74AUP2G3404 has one buffer and one inverter. Both gates have
push-pull outputs designed for operation over a power supply range
of 0.8V to 3.6V. The device is fully specified for partial power down
applications using I
OFF
. The I
OFF
circuitry disables the output
preventing damaging current backflow when the device is powered
down.
Pin Assignments
NEW INFORMATION
ADVANCED PRODUCT
ADVANCEDPRODUCT
NEW INFORMATION
Features
•
•
•
•
•
•
Advanced Ultra Low Power (AUP) CMOS
Supply Voltage Range from 0.8V to 3.6V
± 4mA Output Drive at 3.0V
Low Static power consumption
I
CC
< 0.9µA
Low Dynamic Power Consumption
C
PD
= 6pF Typical at 3.6V
Schmitt Trigger Action at All Inputs Make the Circuit Tolerant for
Slower Input Rise and Fall Time. The hysteresis is typically
250mV at V
CC
= 3.0V
•
I
OFF
Supports Partial-Power-Down Mode Operation
ESD Protection per JESD 22
Exceeds 200-V Machine Model (A115)
Exceeds 2000-V Human Body Model (A114-)
Exceeds 1000-V Charged Device Model (C101)
•
•
Latch-Up Exceeds 100mA per JESD 78, Class I
Leadless packages per JESD30E
DFN1410 denoted as X2-DFN1410-6
DFN1010 denoted as X2-DFN1010-6
DFN0910 denoted as X2-DFN0910-6
•
•
Totally Lead-Free & Fully RoHS Compliant (Notes 1 & 2)
Halogen and Antimony Free. “Green” Device (Note 3)
Applications
•
•
Suited for battery and low power needs
Wide array of products such as:
PCs, networking, Notebooks, Netbooks, PDAs
Tablet Computers, E-Readers
Computer Peripherals, Hard Drives, CD/DVD ROM
TV, DVD, DVR, Set Top Box
Cell Phones, Personal Navigation / GPS
MP3 players ,Cameras, Video Recorders
Notes:
1. No purposely added lead. Fully EU Directive 2002/95/EC (RoHS) & 2011/65/EU (RoHS 2) compliant.
2. See http://www.diodes.com/quality/lead_free.html for more information about Diodes Incorporated’s definitions of Halogen- and Antimony-free,
"Green" and Lead-free.
3. Halogen- and Antimony-free "Green” products are defined as those which contain <900ppm bromine, <900ppm chlorine (<1500ppm total Br + Cl)
and <1000ppm antimony compounds.
Click for Ordering Information
74AUP2G3404
Document number: DS36096 Rev. 4 - 2
1 of 12
www.diodes.com
December 2013
© Diodes Incorporated
74AUP2G3404
Absolute Maximum Ratings
(Note 4) (@T
A
= +25°C, unless otherwise specified.)
Symbol
ESD HBM
ESD CDM
Description
Human Body Model ESD Protection
Charged Device Model ESD Protection
Machine Model ESD Protection
Supply Voltage Range
Input Voltage Range
Voltage applied to output in high or low state
Input Clamp Current V
I
< 0
Output Clamp Current (V
O
< 0 )
Continuous Output Current (V
O
= 0 to V
CC
)
Continuous Current Through V
CC
Continuous Current Through GND
Operating Junction Temperature
Storage Temperature
Rating
2
1
200
-0.5 to 4.6
-0.5 to 4.6
-0.5 to V
CC
+0.5
50
-50
±20
50
-50
-40 to +150
-65 to +150
Unit
KV
KV
V
V
V
V
mA
mA
mA
mA
mA
°C
°C
NEW INFORMATION
ADVANCED PRODUCT
ADVANCEDPRODUCT
NEW INFORMATION
ESD MM
V
CC
V
I
V
O
I
IK
I
OK
I
O
I
CC
I
GND
T
J
T
STG
Note:
4. Stresses beyond the absolute maximum may result in immediate failure or reduced reliability. These are stress values and device
operation should be within recommend values.
Recommended Operating Conditions
(Note 5) (@T
A
= +25°C, unless otherwise specified.)
Symbol
V
CC
V
I
V
O
Operating Voltage
Input Voltage
Output Voltage
Parameter
—
Min
0.8
0
0
—
—
—
—
—
—
—
—
—
—
—
—
—
-40
Max
3.6
3.6
V
CC
-20
-1.1
-1.7
-1.9
-3.1
-4
20
1.1
1.7
1.9
3.1
4
200
+125
Unit
V
V
V
µA
I
OH
High-Level Output Current
I
OL
Low-Level Output Current
∆t/∆V
T
A
Note:
Input transition rise or fall rate
Operating free-air temperature
V
CC
= 0.8V
V
CC
= 1.1V
V
CC
= 1.4V
V
CC
= 1.65V
V
CC
= 2.3V
V
CC
= 3.0V
V
CC
= 0.8V
V
CC
= 1.1V
V
CC
= 1.4V
V
CC
= 1.65V
V
CC
= 2.3V
V
CC
= 3.0V
V
CC
= 0.8V to 3.6V
—
mA
μA
mA
ns/V
°C
5. Unused inputs should be held at V
CC
or Ground.
74AUP2G3404
Document number: DS36096 Rev. 4 - 2
3 of 12
www.diodes.com
December 2013
© Diodes Incorporated
74AUP2G3404
Electrical Characteristics
(cont.) (@T
A
= +25°C, unless otherwise specified.)
Symbol
Parameter
—
V
IH
High-Level Input Voltage
—
—
—
—
—
—
—
I
OH
= -20μA
I
OH
= -1.1mA
I
OH
= -1.7mA
V
OH
High-Level Output Voltage
I
OH
= -1.9mA
I
OH
= -2.3mA
I
OH
= -3.1mA
I
OH
= -2.7mA
I
OH
= -4mA
I
OL
= 20μA
I
OL
= 1.1mA
I
OL
= 1.7mA
V
OL
Low-Level Input Voltage
I
OL
= 1.9mA
I
OL
= 2.3mA
I
OL
= 3.1mA
I
OL
= 2.7mA
I
OL
= 4mA
I
I
I
OFF
∆I
OFF
I
CC
∆I
CC
Input Current
Power Down Leakage Current
Delta Power Down Leakage
Current
Supply Current
Additional Supply Current
A or B Input, V
I
= GND to 3.6V
V
I
or V
O
= 0V to 3.6V
V
I
or V
O
= 0V to 3.6V
V
I
= GND or V
CC
, I
O
= 0
Input at V
CC
–0.6V Other input at
V
CC
or GND
Test Conditions
V
CC
0.8V to 1.65V
1.65V to 1.95V
2.3V to 2.7V
3.0V to 3.6V
0.8V to 1.65V
1.65V to 1.95V
2.3V to 2.7V
3.0V to 3.6V
0.8V to 3.6V
1.1V
1.4V
1.65V
2.3V
3V
0.8V to 3.6V
1.1V
1.4V
1.65V
2.3V
3V
0V to 3.6V
0V
0V to 0.2V
0.8V to 3.6V
3.3V
T
A
= -40 to 125°C
Min
0.80 X V
CC
0.70 X V
CC
1.6
2.0
—
—
—
—
V
CC
– 0.11
0.6 X V
CC
0.93
1.17
1.77
1.67
2.40
2.30
—
—
—
—
—
—
—
—
—
—
—
—
—
Max
—
—
—
—
0.25 X V
CC
0.30 X V
CC
0.7
0.9
—
—
—
—
—
—
—
—
0.11
0.33 X V
CC
0.41
0.39
0.36
0.50
0.36
0.50
± 0.75
± 1.0
± 2.5
1.4
75
μA
μA
μA
μA
μA
V
V
V
Unit
V
NEW INFORMATION
ADVANCED PRODUCT
ADVANCEDPRODUCT
NEW INFORMATION
V
IL
Low-Level Input Voltage
Operating and Package Characteristics
T
A
= +25°C
Parameter
Test
Conditions
V
CC
0.8V
1.2V ± 0.1V
1.5V ± 0.1V
1.8V ± 0.15V
2.5V ± 0.2V
3.3V ± 0.3V
0V or 3.3V
0V
Typ
5.1
5.2
5.2
5.5
5.7
6.0
2.0
3.5
Unit
C
pd
Power dissipation capacitance
f = 1MHz
No Load
pF
C
I
C
O
Input Capacitance
Output Capacitance
V
i
= V
CC
or GND
V
O
= V
CC
or GND
pF
pF
74AUP2G3404
Document number: DS36096 Rev. 4 - 2
5 of 12
www.diodes.com
December 2013
© Diodes Incorporated
