DDTA

(R1≠R2 SERIES)

PNP PRE-BIASED SMALL SIGNAL SURFACE MOUNT TRANSISTOR

Features

•

Epitaxial Planar Die Construction

Complementary NPN Types Available (DDTC)

Built-In Biasing Resistors, R1≠R2

Lead Free/RoHS Compliant (Note 1)

"Green" Device (Note 2 & 3)

SOT-323

Dim

B C

Min

0.25

1.15

2.00

0.30

1.20

1.80

0.0

0.90

0.25

0.10

0°

Max

0.40

1.35

2.20

0.40

1.40

2.20

0.10

1.00

0.40

0.18

8°

NEW PRODUCT

Mechanical Data

•

Case: SOT-323

Case Material: Molded Plastic, "Green" Molding

Compound, Note 3. UL Flammability Classification

Rating 94V-0

Moisture Sensitivity: Level 1 per J-STD-020C

Terminal Connections: See Diagram

Terminals: Solderable per MIL-STD-202, Method 208

Lead Free Plating (Matte Tin Finish annealed over

Alloy 42 leadframe).

Marking Information: See Page 4

Type Code: See Table Below

Ordering Information: See Page 4

Weight: 0.006 grams (approximate)

P/N

Type Code

(NOM) (NOM)

1KΩ

10KΩ

DDTA113ZUA

P02

2.2KΩ

10KΩ

DDTA123YUA

P05

2.2KΩ

47KΩ

DDTA123JUA

P06

4.7KΩ

10KΩ

DDTA143XUA

P09

4.7KΩ

22KΩ

DDTA143FUA

P10

DDTA143ZUA

P11

4.7KΩ

47KΩ

DDTA114YUA

P14

10KΩ

47KΩ

DDTA114WUA

P15

10KΩ

4.7KΩ

DDTA124XUA

P18

22KΩ

47KΩ

DDTA144VUA

P21

47KΩ

10KΩ

DDTA144WUA

P22

47KΩ

22KΩ

0.65 Nominal

OUT

•

All Dimensions in mm

IN B

C OUT

GND(+)

GND (+)

Schematic and Pin Configuration

Equivalent Inverter Circuit

Maximum Ratings

Supply Voltage, (3) to (2)

Input Voltage, (1) to (2)

= 25°C unless otherwise specified

Symbol

DDTA113ZUA

DDTA123YUA

DDTA123JUA

DDTA143XUA

DDTA143FUA

DDTA143ZUA

DDTA114YUA

DDTA114WUA

DDTA124XUA

DDTA144VUA

DDTA144WUA

DDTA113ZUA

DDTA123YUA

DDTA123JUA

DDTA143XUA

DDTA143FUA

DDTA143ZUA

DDTA114YUA

DDTA114WUA

DDTA124XUA

DDTA144VUA

DDTA144WUA

Value

-50

+5 to -10

+5 to -12

+7 to -20

+6 to -30

+5 to -30

+6 to -40

+10 to -30

+10 to -40

+15 to -40

+10 to -40

-100

-70

-100

-50

-30

Unit

Characteristic

Output Current

Notes:

1. No purposefully added lead.

2. Diodes Inc.'s "Green" policy can be found on our website at http://www.diodes.com/products/lead_free/index.php.

3. Product manufactured with Date Code 0627 (week 27, 2006) and newer are built with Green Molding Compound. Product manufactured prior

to Date Code 0627 are built with Non-Green Molding Compound and may contain Halogens or Sb2O3 Fire Retardants.

DS30326 Rev. 7 - 2

1 of 4

www.diodes.com

DDTA (R1≠R2 SERIES) UA
