The AP2401 and AP2411 are single channel current-limited
integrated high-side power switches optimized for Universal Serial
Bus (USB) and other hot-swap applications. The family of devices
complies with USB standards and is available with both polarities of
enable input.
The devices have fast short-circuit response time for improved overall
system robustness, and have integrated output discharge function to
ensure completely controlled discharging of the output voltage
capacitor. They provide a complete protection solution for applications
subject to heavy capacitive loads and the prospect of short circuit,
and offer reverse current blocking, over-current, over-temperature
and short-circuit protection, as well as controlled rise time and
under-voltage lockout functionality. A 7ms deglitch capability on the
open-drain Flag output prevents false over-current reporting and does
not require any external components. AP2401 and AP2411 will be
latched off after 7ms deglitch.
All
devices
are
available
in
SO-8,
MSOP-8,
MSOP-8EP,
Pin Assignments
(Top View)
GND
1
IN
2
IN
3
EN
4
SO-8
(Top View)
GND
IN
IN
EN
1
2
3
4
8
7
6
5
8
NC
7
OUT
6
OUT
5
FLG
NC
OUT
OUT
FLG
MSOP-8/MSOP-8EP
Note: Latter with exposed pad
(dotted line)
(Top View)
GND
IN
IN
EN
1
2
3
4
8
NC
7
OUT
6
OUT
5
FLG
U-DFN3030-8 and U-DFN2020-6 packages.
Features
Single Channel Current-Limited Power Switch
Output Discharge Function
Output Current Latch-Off when OCP Triggered
Fast Short-Circuit Response Time: 2µs
2.5A Accurate Current Limiting
Reverse Current Blocking
70mΩ On-Resistance
Input Voltage Range: 2.7V - 5.5V
Built-In Soft-Start with 0.6ms Typical Rise Time
Over-Current and Thermal Protection
Fault Report (FLG) with Blanking Time (7ms typ)
ESD Protection: 2kV HBM, 200V MM
Active Low (AP2401) or Active High (AP2411) Enable
Ambient Temperature Range: -40°C to +85°C
SO-8, MSOP-8, MSOP-8EP, U-DFN3030-8 and U-DFN2020-6:
Available in “Green” Molding Compound (No Br, Sb)
Lead-Free Finish; RoHS Compliant (Notes 1 & 2)
Halogen and Antimony Free. “Green” Device (Note 3)
U-DFN3030-8
U-DFN2020-6
Applications
LCD TVs & Monitors
Set-Top-Boxes, Residential Gateways
Laptops, Desktops, Servers, e-Readers
Printers, Docking Stations, HUBs
UL Recognized, File Number E322375
IEC60950-1 CB Scheme Certified
Notes:
1. EU Directive 2002/95/EC (RoHS) & 2011/65/EU (RoHS 2) compliant. All applicable RoHS exemptions applied.
2. See http://www.diodes.com/quality/lead_free.html for more information about Diodes Incorporated’s definitions of Halogen- and Antimony-free, "Green"
and Lead-free.
3. Halogen- and Antimony-free "Green” products are defined as those which contain <900ppm bromine, <900ppm chlorine (<1500ppm total Br + Cl) and
4. All voltages referred to GND pin. Maximums are the lower of V
IN
+ 0.3 and 6.5V
5. UL Recognized Rating from -30°C to +70°C (Diodes qualified T
ST
from -65°C to +150°C).
Caution: Stresses greater than the 'Absolute Maximum Ratings' specified above, may cause permanent damage to the device. These are stress ratings
only; functional operation of the device at these or any other conditions exceeding those indicated in this specification is not implied. Device reliability may
be affected by exposure to absolute maximum rating conditions for extended periods of time.
Semiconductor devices are ESD sensitive and may be damaged by exposure to ESD events. Suitable ESD precautions should be taken when handling
