UDZ3V6B-UDZ15B
SURFACE MOUNT PRECISION ZENER DIODE
Features
Small, Surface Mount Package
Ideally suited for Automated Assembly Processes
Very Sharp Breakdown Characteristics
Very Tight Tolerance on Zener Breakdown Voltage
Totally Lead-Free & Fully RoHS Compliant (Notes 1 & 2)
Halogen and Antimony Free. “Green” Device (Note 3)
Mechanical Data
Case: SOD323
Case Material: UL Flammability Classification Rating 94V-0
Moisture Sensitivity: Level 1 per J-STD-020D
Terminal Connections: Cathode Band
Terminals: Finish – Matte Tin Annealed over Alloy 42
Leadframe. Solderable per MIL-STD-202, Method 208
Weight: 0.004 grams (Approximate)
Top View
Ordering Information
(Note 4)
Device
(Type Number)-7*
(Type Number)-13* (Note 5)
Notes:
Packaging
SOD323
SOD323
Shipping
3,000/Tape & Reel
10,000/Tape & Reel
* For (Type Number), please see the Electrical Characteristics Table. Example: 6.2V Zener = UDZ6V2B-7.
1. No purposely added lead. Fully EU Directive 2002/95/EC (RoHS) & 2011/65/EU (RoHS 2) compliant.
2. See http://www.diodes.com/quality/lead_free.html for more information about Diodes Incorporated’s definitions of Halogen- and Antimony-free, "Green"
and Lead-free.
3. Halogen- and Antimony-free "Green” products are defined as those which contain <900ppm bromine, <900ppm chlorine (<1500ppm total Br + Cl) and
<1000ppm antimony compounds.
4. For packaging details, go to our website at http://www.diodes.com/products/packages.html
5. Devices are readily available on 13” reels for select voltages only. For other voltages, devices can be made available on 13” reels upon request. Please
Contact your Diodes Inc. sales representative for additional details.
Marking Information
XX
XX = Product Type Marking Code for
SAT (Shanghai Assembly/Test Site)
(See Electrical Characteristics Table)
XX
XX = Product Type Marking Code for
CAT (Chengdu Assembly/Test Site)
(See Electrical Characteristics Table)
UDZ3V6B-UDZ15B
Document number: DS30290 Rev. 16 - 2
1 of 6
www.diodes.com
July 2016
© Diodes Incorporated
UDZ3V6B-UDZ15B
Thermal Characteristics
Characteristic
Power Dissipation (Note 6)
Thermal Resistance Junction to Ambient Air (Note 6)
Operating and Storage Temperature Range
Symbol
P
D
R
θJA
T
J,
T
STG
Value
200
625
-65 to +150
Unit
mW
°C/W
°C
Electrical Characteristics
Type
Number
UDZ3V6B
(Note 9)
UDZ3V9B
(Note 9)
UDZ4V3B
(Note 9)
UDZ4V7B
(Note 9)
UDZ5V1B
(Note 9)
UDZ5V6B
UDZ6V2B
UDZ6V8B
UDZ7V5B
(Note 9)
UDZ8V2B
UDZ9V1B
UDZ10B
UDZ11B
UDZ12B
UDZ13B
UDZ15B
Notes:
6.
7.
8.
9.
(@T
A
= +25°C, unless otherwise specified.)
Zener Voltage Range
(Note 7)
Maximum Zener Impedance
(Note 8)
I
ZT
mA
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
Z
ZT
@ I
ZT
Ω
100
100
100
100
80
60
60
40
30
30
30
30
30
30
37
42
1,000
1,000
1,000
800
500
200
100
60
60
60
60
60
60
80
80
80
Z
ZK
@ I
ZK
I
ZK
mA
1.0
1.0
1.0
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
Maximum Reverse Current
(Note 7)
I
R
uA
10
5
5
2
2
1
1
0.5
0.5
0.5
0.5
0.1
0.1
0.1
0.1
0.1
V
R
V
1.0
1.0
1.0
1.0
1.5
2.5
3.0
3.5
4.0
5.0
6.0
7.0
8.0
9.0
10.0
11.0
Marking
Code
V
ZT
Min (V)
3.600
3.890
4.170
4.550
4.980
5.490
6.060
6.650
7.280
8.020
8.850
9.770
10.760
11.740
12.910
14.340
@
I
ZT
Max (V)
3.845
4.160
4.430
4.750
5.200
5.730
6.330
6.930
7.600
8.360
9.230
10.210
11.220
12.240
13.490
14.980
B7
B8
B9
BA
BB
BC
BD
BE
BF
BG
BH
BI
BJ
BK
BL
BM
Part mounted on FR-4 PC board with recommended pad layout, which can be found on our website at http://www.diodes.com/package-outlines.html.
Short duration pulse test used to minimize self-heating effect.
The Zener impedances (Z
ZT
, Z
ZK
) are measured by superimposing a minute alternating current on the regulated current (I
Z
).
AEC-Q101 qualified.
UDZ3V6B-UDZ15B
Document number: DS30290 Rev. 16 - 2
2 of 6
www.diodes.com
July 2016
© Diodes Incorporated
UDZ3V6B-UDZ15B
I
F
, INSTANTANEOUS FORWARD CURRENT (mA)
250
R
JA
= 625°C/W
1,000
P
D
, POWER DISSIPATION (mW)
200
Note 6
100
150
10
100
1.0
50
0.1
0
0
40
80
120
160
T
A
, AMBIENT TEMPERATURE (°C)
Fig. 1 Power Derating Curve
200
0.01
0
0.2
0.4
0.6
0.8
1.0
1.2
V
F
, INSTANTANEOUS FORWARD VOLTAGE (V)
Fig. 2 Typical Forward Characteristics
100m
100m
10m
I
Z
, ZENER CURRENT (A)
I
Z
, ZENER CURRENT (A)
10m
1m
1m
100n
0.0 1.0 2.0 3.0 4.0 5.0 6.0 7.0 8.0 9.0 10.0
V
Z
, ZENER VOLTAGE (V)
Fig. 3 Typical Zener Breakdown Characteristics,
UDZ3V6B - UDZ8V2B
100n
8.0
10.0
11.0
12.0
13.0
14.0
V
Z
, ZENER VOLTAGE (V)
Fig. 4 Typical Zener Breakdown Characteristics,
UDZ10B - UDZ13B
9.0
100
30
25
C
T
, TOTAL CAPACITANCE (pF)
T
A
= 25°C
I
Z
, ZENER CURRENT (mA)
10
20
15
0V Bias
1V Bias
10
2V Bias
5
0
0.1
10
12
14
16
18
20
V
Z
, ZENER VOLTAGE (V)
Fig. 5 Typical Zener Breakdown Characteristics, UDZ15B
4
6
8
10
12
14
V
Z
, NOMINAL ZENER VOLTAGE (V)
Fig. 6 Typical Total Capacitance
vs. Nominal Zener Voltage
16
UDZ3V6B-UDZ15B
Document number: DS30290 Rev. 16 - 2
3 of 6
www.diodes.com
July 2016
© Diodes Incorporated
UDZ3V6B-UDZ15B
0.12
TC of V
Z
, TEMPERATURE COEFFICIENT
OF ZENER VOLTAGE (%/°C)
0.12
TC of V
Z
, TEMPERATURE COEFFICIENT
OF ZENER VOLTAGE (%/°C)
0.10
0.08
0.06
0.04
0.02
0
-0.02
-0.04
-0.06
-0.08
6
8
10
4
V
Z
, ZENER VOLTAGE (V)
Fig. 7 Typical Temperature Coefficient of
Zener Voltage vs. Zener Voltage, UDZ6V2B-UDZ10B
2
0
0.10
0.08
0.06
0.04
0.02
0
-0.02
-0.04
-0.06
-0.08
10
16
18
20
14
V
Z
, ZENER VOLTAGE (V)
Fig. 8 Typical Temperature Coefficient of
Zener Voltage vs. Zener Voltage, UDZ10B-UDZ15B
12
UDZ3V6B-UDZ15B
Document number: DS30290 Rev. 16 - 2
4 of 6
www.diodes.com
July 2016
© Diodes Incorporated
UDZ3V6B-UDZ15B
Package Outline Dimensions
Please see http://www.diodes.com/package-outlines.html for the latest version.
SOD323
A2
A1
a
c
He
E
L
b
D
SOD323
Dim Min Max Typ
A1
--
0.10 0.05
A2
1.00 1.10 1.05
b
0.25 0.35 0.30
c
0.10 0.15 0.11
D
1.20 1.40 1.30
E
1.60 1.80 1.70
He
2.30 2.70 2.50
L
0.20 0.40 0.30
a
0º
8º
--
All Dimensions in mm
Suggested Pad Layout
Please see http://www.diodes.com/package-outlines.html for the latest version.
SOD323
X1
Y
X
Dimensions Value (in mm)
X
0.590
X1
2.700
Y
0.450
