GBU6005 - GBU610
6.0A GLASS PASSIVATED BRIDGE RECTIFIER
Features
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
Glass Passivated Die Construction
High Case Dielectric Strength of 1500 VRMS
Low Reverse Leakage Current
Surge Overload Rating to 175A Peak
Ideal for Printed Circuit Board Applications
UL Listed Under Recognized Component
Index, File Number E94661
Lead Free Finish, RoHS Compliant (Note 4)
L
D
E
F
J
G
P
H
N
A
B
K
C
M
GBU
Dim
A
B
C
D
E
F
G
H
J
K
L
M
N
P
Min
21.8
3.5
7.4
1.65
2.25
1.95
1.02
4.83
17.5
18.3
3.30
0.46
0.76
Max
22.3
4.1
7.9
2.16
2.75
2.35
1.27
5.33
18.0
18.8
3.56
0.56
1.0
Mechanical Data
Case: GBU
Case Material: Molded Plastic. UL Flammability
Classification Rating 94V-0
Terminals: Plated Leads. Solderable per MIL-STD-202,
Method 208
e
3
Lead Free Plating (Tin Finish)
Polarity: Marked on Body
Mounting: Through Hole for #6 Screw
Mounting Torque: 5.0 Inch-pounds Maximum
Ordering Information: See Last Page
Marking: Date Code and Type Number
Weight: 6.6 grams (approximate)
-
~
~
+
3.2 X 45°
All Dimensions in mm
@ T
A
= 25°C unless otherwise specified
Maximum Ratings and Electrical Characteristics
Single phase, 60Hz, resistive or inductive load.
For capacitive load, derate current by 20%.
Characteristic
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
RMS Reverse Voltage
Average Forward Rectified Current (Note 1) @ T
C
= 100°C
Non-Repetitive Peak Forward Surge Current 8.3ms
single half sine-wave superimposed on rated load
Forward Voltage (per element)
Peak Reverse Current
at Rated DC Blocking Voltage
I
2
t Rating for Fusing (t < 8.3ms) (Note 2)
Typical Total Capacitance per Element (Note 3)
Typical Thermal Resistance Junction to Case (Note 1)
Operating and Storage Temperature Range
Notes:
1.
2.
3.
4.
Symbol
V
RRM
V
RWM
V
R
V
R(RMS)
I
(AV)
I
FSM
V
FM
I
R
I
2
t
C
T
R
qJC
T
j,
T
STG
GBU
6005
50
35
GBU
601
100
70
GBU
602
200
140
GBU
604
400
280
6.0
175
1.0
5.0
500
127
100
2.2
-55 to +150
GBU
606
600
420
GBU
608
800
560
GBU
610
1000
700
Unit
V
V
A
A
V
mA
A
2
s
pF
°C/W
°C
@ I
F
= 3.0A
@ T
C
= 25°C
@ T
C
= 125°C
Unit mounted on 50mm x 50mm x 1.6mm copper plate heatsink.
Non-repetitive, for t > 1.0ms and < 8.3ms.
Measured at 1.0MHz and applied reverse voltage of 4.0V DC.
RoHS revision 13.2.2003. Glass and High Temperature Solder Exemptions Applied, see
EU Directive Annex Notes 5 and 7.
DS21226 Rev. 7 - 2
1 of 3
www.diodes.com
GBU6005-GBU610
ã
Diodes Incorporated
I
(AV)
, AVERAGE FORWARD RECTIFIED CURRENT (A)
6
With heatsink
5
I
F
, INSTANTANEOUS FORWARD CURRENT (A)
100
T
j
= 25
°
C
4
10
3
Without heatsink
2
1.0
1
Resistive or
Inductive load
0
0
25
50
75
100
125
150
T
C
, CASE TEMPERATURE (
°
C)
Fig. 1 Forward Current Derating Curve
0.1
0.0
0.2
0.6
1.0
1.4
1.8
V
F
, INSTANTANEOUS FORWARD VOLTAGE (V)
Fig. 2 Typical Forward Characteristics, per element
I
FSM
, PEAK FORWARD SURGE CURRENT (A)
180
Single half-sine-wave
100
160
T
j
= 25
°
C
f = 1.0MHz
120
C
T
, TOTAL CAPACITANCE (pF)
1
10
100
10
80
40
0
NUMBER OF CYCLES AT 60 Hz
Fig. 3 Maximum Non-Repetitive Surge Current
1
1
100
10
V
R
, REVERSE VOLTAGE (V)
Fig. 4 Typical Total Capacitance, per element
Ordering Information
Device
GBU6005
GBU601
GBU602
GBU604
GBU606
GBU608
GBU610
Notes:
(Note 5)
Packaging
GBU
GBU
GBU
GBU
GBU
GBU
GBU
Shipping
20/Tube
20/Tube
20/Tube
20/Tube
20/Tube
20/Tube
20/Tube
5. For packaging details, visit our website at http://www.diodes.com/datasheets/ap02008.pdf
DS21226 Rev. 7 - 2
2 of 3
www.diodes.com
GBU6005-GBU610
