D20V0L1B2LP-7B datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Discrete semiconductor> TVS diode> D20V0L1B2LP-7B

D20V0L1B2LP-7B: Description反向关断电压（典型值）：20V 击穿电压（最小值）：21V 极性：Bidirectional 箝位电压：34V @ 2A 峰值脉冲电流（10/1000us）：2A (8/20us); CategoryDiscrete semiconductor TVS diode; File Size331KB，6 Pages; ManufacturerDiodes; Websitehttp://www.diodes.com/

Download Datasheet Parametric View All

D20V0L1B2LP-7B Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	D20V0L1B2LP-7B	-	-	View	Buy Now

D20V0L1B2LP-7B Overview

反向关断电压（典型值）：20V 击穿电压（最小值）：21V 极性：Bidirectional 箝位电压：34V @ 2A 峰值脉冲电流（10/1000us）：2A (8/20us)

D20V0L1B2LP-7B Parametric

Parameter Name	Attribute value
Reverse shutdown voltage (typ)	20V
Breakdown voltage (minimum value)	21V
polarity	Bidirectional
clamping voltage	34V @ 2A
Peak pulse current (10/1000us)	2A (8/20us)

Preview

Download Datasheet

View All

D20V0L1B2LP

20V BIDIRECTIONAL TVS DIODE

Product Summary

ADVANCE INFORMATION

Min

21V

Max

Typ

7pF

Features



Low Profile Package (0.53mm Max) and Ultra-Small PCB Footprint

Area (1.08 x 0.68mm Max) Suitable for Compact Portable

Electronics

Provides ESD Protection per IEC 61000-4-2 Standard:

Air ±20kV, Contact ±15kV

One Channel of ESD Protection

Low Channel Input Capacitance

Totally Lead-Free & Fully RoHS Compliant (Notes 1 & 2)

Halogen and Antimony Free. “Green” Device (Note 3)

Qualified to AEC-Q101 Standards for High Reliability

Description

This new generation TVS is designed to protect sensitive electronics

from damage due to ESD. The combination of small-size and high

ESD surge capability makes it ideal for use in portable applications

such as cellular phones, digital cameras, and MP3 players.



Applications



Cellular Handsets

Portable Electronics

Computers and Peripherals

Mechanical Data



Case: X1-DFN1006-2

Case Material: Molded Plastic, “Green” Molding Compound.

UL Flammability Classification Rating 94V-0

Moisture Sensitivity: Level 1 per J-STD-020

Terminals: NiPdAu over Copper Leadframe.

Solderable per MIL-STD-202, Method 208

Weight: 0.001 grams (Approximate)

X1-DFN1006-2

Pin 1

Pin 2

Bottom View

Device Schematic

Ordering Information

(Note 4)

Part Number

D20V0L1B2LP-7B

Notes:

Compliance

Commercial

Marking

Reel Size (inches)

Tape Width (mm)

Quantity per Reel

10,000/Tape & Reel

1. No purposely added lead. Fully EU Directive 2002/95/EC (RoHS), 2011/65/EU (RoHS 2) & 2015/863/EU (RoHS 3) compliant.

2. See https://www.diodes.com/quality/lead-free/ for more information about Diodes Incorporated’s definitions of Halogen- and Antimony-free, "Green" and

Lead-free.

3. Halogen- and Antimony-free "Green” products are defined as those which contain <900ppm bromine, <900ppm chlorine (<1500ppm total Br + Cl) and

<1000ppm antimony compounds.

4. For packaging details, go to our website at https://www.diodes.com/design/support/packaging/diodes-packaging/.

Marking Information

DB = Product Type Marking Code

Bar Denotes Pin 1

D20V0L1B2LP

Document number: DS38148 Rev. 2 - 2

1 of 6

www.diodes.com

November 2018
