DT1446-04V
4 CHANNEL LOW CAPACITANCE TVS DIODE ARRAY
Product Summary
V
BR (min)
6V
I
PP (max)
4.7A
C
T (typ)
0.55pF
Features
•
•
•
•
•
IEC 61000-4-2 (ESD): Air – ±19kV, Contact – ±16kV
Low Channel Input Capacitance of 0.55pF Typical
ESD Protection for four I/Os and one V
CC
Totally Lead-Free & Fully RoHS Compliant (Notes 1 & 2)
Halogen and Antimony Free. “Green” Device (Note 3)
Description
ADVANCE INFORMATION
NEW PRODUCT
The DT1446-04V is a high performance device suitable for protecting
four high speed I/Os and one V
CC
. These devices are assembled in
SOT563 package. They have high ESD surge capability and low
capacitance.
Mechanical Data
•
•
•
•
•
Case: SOT563
Case Material: Molded Plastic, “Green” Molding Compound.
UL Flammability Classification Rating 94V-0
Moisture Sensitivity: Level 1 per J-STD-020
Terminals: Matte Tin Finish annealed over Copper leadframe
(Lead Free Plating) Solderable per MIL-STD-202, Method208
e3
Weight: 0.003 grams (approximate)
Applications
•
Typically Used for High Speed Ports such as USB 2.0,
IEEE1394, HDMI, Laptop and Personal Computers,
Flat Panel Displays, Video Graphics Displays, SIM Ports
SOT563
Top View
Bottom View
Device Schematic
Ordering Information
(Note 4)
Product
DT1446-04V-7
Notes:
Compliance
Standard
Marking
BE4
Reel Size (inches)
7
Tape Width (mm)
8
Quantity per Reel
3,000/Tape & Reel
1. No purposely added lead. Fully EU Directive 2002/95/EC (RoHS) & 2011/65/EU (RoHS 2) compliant.
2. See http://www.diodes.com/quality/lead_free.html for more information about Diodes Incorporated’s definitions of Halogen- and Antimony-free, "Green"
and Lead-free.
3. Halogen- and Antimony-free "Green” products are defined as those which contain <900ppm bromine, <900ppm chlorine (<1500ppm total Br + Cl) and
<1000ppm antimony compounds.
4. For packaging details, go to our website at http://www.diodes.com/products/packages.html.
Marking Information
BE4 = Product Type Marking Code
YM = Date Code Marking
Y = Year (ex: A = 2013)
M = Month (ex: 9 = September)
Date Code Key
Year
Code
Month
Code
Jan
1
2013
A
Feb
2
Mar
3
2014
B
Apr
4
May
5
2015
C
Jun
6
Jul
7
2016
D
Aug
8
Sep
9
2017
E
Oct
O
Nov
N
2018
F
Dec
D
DT1446-04V
Document number: DS36609 Rev. 3 – 2
1 of 5
www.diodes.com
July 2014
© Diodes Incorporated
DT1446-04V
Maximum Ratings
(@T
A
= +25°C, unless otherwise specified.)
Characteristic
Peak Pulse Current ,per IEC 61000-4-5
Operating Voltage (DC)
ESD Protection – Contact Discharge
Symbol
I
PP_I/O
V
DC
V
ESD_I/O
V
ESD_
V
CC
V
ESD_I/O
V
ESD_
V
CC
Value
4.7
6
±16
±30
±19
±30
Unit
A
V
kV
kV
kV
kV
Conditions
I/O to V
SS
, 8/20µs
V
CC
to V
SS
I/O to V
SS
, per IEC 61000-4-2
Vcc to V
SS
, per IEC 61000-4-2
I/O to V
SS
, per IEC 61000-4-2
V
CC
to V
SS
, per IEC 61000-4-2
ADVANCE INFORMATION
NEW PRODUCT
ESD Protection – Air Discharge, per IEC 61000-4-2
Thermal Characteristics
Characteristic
Power Dissipation Typical (Note 5)
Thermal Resistance, Junction to Ambient Typical (Note 5)
Operating and Storage Temperature Range
Symbol
P
D
Rθ
JA
T
J
, T
STG
Value
380
327
-55 to +150
Unit
mW
°C/W
°C
Electrical Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic
Reverse Working Voltage
Reverse Current (Note 6)
Reverse Current (Note 6)
Reverse Breakdown Voltage
Forward Clamping Voltage
Reverse Clamping Voltage (Note 7)
ESD Clamping Voltage
Dynamic Resistance
Channel Input Capacitance
Channel Input Capacitance
Variation of Channel Input
Capacitance
Variation of Channel Input
Capacitance
Notes:
Symbol
Min
—
—
—
6.0
—
—
—
—
—
—
—
—
—
—
Typ
—
—
—
—
0.8
8.5
10
12
0.2
0.3
0.55
0.65
0.03
0.05
Max
5.5
5.0
1.0
9.0
1.0
—
—
—
—
—
0.65
—
—
—
Unit
V
μA
μA
V
V
V
V
V
Ω
Ω
pF
pF
pF
pF
V
CC
to V
SS
Test Conditions
V
R
= 5V, V
CC
to V
SS
V
R
= 5V, any I/O to V
SS
I
R
= 1mA, V
CC
to V
SS
I
F
= 15mA, V
SS
to V
CC
I
PP
= 4.7A, I/O to V
SS
, 8/20µs
TLP, 20A, tp = 100 ns, V
CC
to V
SS
TLP, 20A, tp = 100 ns, I/O to V
SS
TLP, 20A, tp = 100 ns, V
CC
to V
SS
TLP, 20A, tp = 100 ns, I/O to V
SS
V
R
= 2.5V, V
CC
= 5V, f = 1MHz
V
R
= 2.5V, V
CC
= floating, f = 1MHz
V
CC
= 5V, V
SS
= 0V, I/O = 2.5V, f =1MHz,
T=25 °C , C
I/OMAX
-
C
I/OMIN
V
CC
= floating , V
SS
= 0V, I/O = 2.5V,
f =1MHz, T = +25°C , C
I/OMAX
-
C
I/OMIN
V
RWM
I
R(
V
CC to
V
SS)
I
R(IO to
V
SS)
V
BR
V
F
V
C_I/O
V
ESD_
V
CC
V
ESD_I/O
R
DIF_
V
CC
R
DIF_I/O
C
I/O to
V
SS
C
I/O to
V
SS
C
I/OMAX
-
C
I/OMIN
C
I/OMAX
-
C
I/OMIN
5. Device mounted on FR-4 PCB pad layout (2oz copper) as shown on Diodes, Inc. suggested pad layout AP02001, which can be found on our website at
http://www.diodes.com.
6. Short duration pulse test used to minimize self-heating effect.
7. Clamping voltage value is based on an 8x20µs peak pulse current (I
pp
) waveform.
DT1446-04V
Document number: DS36609 Rev. 3 – 2
2 of 5
www.diodes.com
July 2014
© Diodes Incorporated
DT1446-04V
100
PEAK PULSE DERATING IN % OF
PEAK POWER OR CURRENT
BREAKDOWN VOLTAGE,TRIGGE R
VOLTAGE(V)
9.5
9.0
8.5
8.0
7.5
7.0
BV
75
ADVANCE INFORMATION
NEW PRODUCT
50
25
6.5
6.0
VTRIG
0
0
25
50
75
100
125
150
175
200
-55
-25
5
35
65
95
125
155
T
A
,AMBIENT TEMPERATURE(°C)
Figure1. Pulse Derating Curve
T
A
, AMBIE NT TEMPERA TURE (°C)
Figure 2. BV, Trigger Voltage vs. Ambient
Temperature
CLAMPING VOLTAGE,CURRENT (V,A)
12
11
V
C,
CLAMPING VOLTAGE (V)
9
8
7
6
5
4
3
2
1
0
-40
-30
-20
-10
0
10
20
30
40
50
60
70
Ampere
Voltage
10
9
8
7
6
5
0
IEC61000-4-5
(Lighting)
1
2
3
4
5
6
7
8
CURRENT FROM I/O TO Vss(A)
Figure 5. Clamping Voltage Characteristic
t,TIME（us）
Figure 6. Waveform of Clamping Voltage,Current vs.
Time(8/20us,I/O to Vss)
DT1446-04V
Document number: DS36609 Rev. 3 – 2
3 of 5
www.diodes.com
July 2014
© Diodes Incorporated
DT1446-04V
ADVANCE INFORMATION
NEW PRODUCT
Package Outline Dimensions
Please see AP02002 at http://www.diodes.com/datasheets/ap02002.pdf for latest version.
A
B
C
D
G
K
M
SOT563
Dim Min
Max Typ
A
0.15 0.30 0.20
B
1.10 1.25 1.20
C
1.55 1.70 1.60
D
-
-
0.50
G
0.90 1.10 1.00
H
1.50 1.70 1.60
K
0.55 0.60 0.60
L
0.10 0.30 0.20
M
0.10 0.18 0.11
All Dimensions in mm
H
L
Suggested Pad Layout
Please see AP02001 at http://www.diodes.com/datasheets/ap02001.pdf for the latest version.
C2
C2
Z
G
C1
Y
X
Dimensions Value (in mm)
Z
2.2
G
1.2
X
0.375
Y
0.5
1.7
C1
0.5
C2
DT1446-04V
Document number: DS36609 Rev. 3 – 2
4 of 5
www.diodes.com
July 2014
© Diodes Incorporated
