SHEET 1 OF 1
21.00
[.827 in]
15.50
[.610 in]
7.00
.05
[.276
.002
in]
9.60
[.378 in]
RECOMMENDED P.C.B. PANEL MOUNTING
PANEL THICKNESS
0.75-1.25
1.25-2.00
2.00-3.00
X
19.2
19.4
19.6
4.60
[.181 in]
6.2
[.24 in]
6.90
[.272 in]
OFF
OPEN
NONE
N/A
ON
1-1a
2.00
[.079 in]
15.3
[.602 in]
18.90
[.744 in]
2.70
[.106 in]
7.0
[.276 in]
1a
NOTES:
1. ALL DIMENSIONS IN MM [INCH]
2. GENERAL TOLERANCE: X.X= 0.4
X.XX= 0.25
3. TERM. NOS. FOR REF. ONLY
4. RATING: 4(1)A 250VAC, 10A 125VAC, 6A 250VAC
5. MATERIAL: BODY & ROCKER, NYLON 6/6 UL94 V-2
6. DENOTES CRITICAL PARAMETER.
1.50
[.059 in]
4.76
[.187 in]
1.00
[.039 in]
4.50
[.177 in]
1a
1
2.20
[.087 in]
1
.80
[.031 in]
4.00
[.157 in]
6.50
[.256 in]
POSITION
1
POSITION
3
ACTUATOR
COLOR BLACK
HOUSING
COLOR BLACK
X
SWITCH FUNCTION
POS. 1
POS. 2
POS. 3
1
1a
CIRCUIT: SPST
B
A
REV
22536
10498
PCR NO
UPDATED DIMENSIONS
NEW RELEASE
DESCRIPTION
10/7/16
1/17/00
DATE
MJR
MM
BY
SCALE
DATE
DR
DWG
REV
TITLE
R6ABLKBLKFF
2:1
1/17/2000
MM
M060302
B
