VL
CONNECTOR
0
L
JS
T
a
6.2mm pitch/Disconnectable Crimp style connectors
(Combined use for both wire-to-board and wire-to-wire connections)
Specifications–––––––––––––––––––
• Current rating: 20 A AC, DC (Refer to the table below.)
• Voltage rating: 600 V AC, DC
• Temperature range: -25˚C to +90˚C
(including temperature rise in applying
electrical current)
• Contact resistance: Initial value/ 7 mΩ max.
After environmental tests/ 10 mΩ max.
• Insulation resistance: 1,000 MΩ min.
• Withstanding voltage: 2,000 VAC/minute
• Applicable wire: AWG #22 to #12
• Applicable PC board thickness: 1.6 mm
* Refer to "General Instruction and Notice when using
Terminals and Connectors" at the end of this catalog.
* Contact JST for details.
* Compliant with RoHS.
Note: The current rating differs depending on the number of circuits and the wire
size used in each connector. The table below lists the current rating as a
function of the number of circuits and the wire size.
Current unit: A
Circuits
＃12
＃14
Wire size(AWG)
＃16
＃18
＃20
＃22
This VL connector is designed for wire-to-
wire and wire-to-board 6.2 mm pitch
connector corresponding to large current.
Secondary retainer, which prevents from
insufficient insertion of contact and coming
off contact, may use and large current
circuit can be connected certainly and
safety.
• Housing lances for contact retention
• Secondary retainer
• Suited for large current
• Two kinds of connections
2
3
4
6
8
12
20
17
16
15
14
13
15
14
13
12
11
10
10
9
9
8
7
7
8
8
7
7
6
6
6
6
6
5
5
4
4
4
4
3
3
3
Note: Do not branch in parallel current which exceeds the rated current (e.g. more
than 17A in the case of 3 circuits with AWG #12). If branched in parallel, current
imbalance or other problems may develop. If it is absolutely necessary to branch
such a large current in parallel, design the circuits without causing any imbalance
and provide an extra margin for each circuit.
Standards ––––––––––––––––––––––
1
2
（13.2）
0
Recognized E60389
Certified LR20812
R9351103
PC board layout and Assembly layout
（19.3）
<2, 3, 4 (Single-row) circuits>
<4, 6, 8, 12 circuits>
（29.2）
φ2.1
±0.05
Inner-housing lock
6.84
min
（15.6）
3.4
min
4 circuits
(Single-row)
：φ1.8
±0.05
2, 3 circuits
：φ2.1
±0.05
A
±0.1
6.2
±0.05
3.6
min
A
±0.1
6.2
±0.05
3.6
min
Inner-housing lock
（21.7）
8.28
±0.05
Outer-housing lock
（29.2）
Outer-housing lock
Note: 1. The above figure is the figure viewed from soldering side.
2. Tolerances are non-cumulative: ±0.05 mm for all centers.
3. Hole dimensions differ according to the type of PC board and piercing method. The dimensions above should serve as a guideline. Contact JST for details.
（29.2）
（29.2）
1
VL CONNECTOR
Contact
Model No.
4.1
Applicable wire
AWG #
mm
2
0.3∼1.25
0.5∼2.0
3.5
22∼16
20∼14
12
Insulation O.D.
(mm)
1.7∼3.2
1.9∼3.4
4.1
Q'ty/
reel
2,000
2,000
2,000
16.7
3.6
2
1.7
SVF-42T-P2.0
SVF-61T-P2.0
SVF-81T-P2.0
Material and Finish
3.1
Phosphor bronze, tin-plated (reflow treatment)
RoHS compliance
Crimping
machine Crimp applicator
MKS-L
AP-K2N
−
−
MKS-L
−
−
Contact
SVF-42T-P2.0
SVF-61T-P2.0
Applicator
Dies
−
−
−
−
Crimp applicator with dies
−
−
−
−
Contact
SVF-81T-P2.0
Crimping
machine Crimp applicator
AP-K2N
MKS-L
−
−
Applicator
Dies
MK/SVF/M-81-20
−
−
Crimp applicator with dies
APLMK SVF/M81-20
−
−
MK/SVF/M-42-20 APLMK SVF/M42-20
MK/SVF/M-61-20 APLMK SVF/M61-20
Housing (Inner-housing lock)
<2 circuits>
<3 circuits>
<4 circuits>
13.4
13.4
L
JST
<6 circuits>
19.6
<8 circuits>
25.8
5
6
2
L JST
7
8
Ｌ Ｊ Ｔ
Ｓ
４
19.6
５
６
Ｌ Ｊ Ｔ
Ｓ
３
４
２
Ｌ Ｊ Ｔ
Ｓ
15.4
8.4
8.4
15.4
2.8
2.8
2.8
2.8
11
11
11
11
13
13
13
13
6.2
6.2
6.2
6.2
6.2
<12 circuits>
38.2
L JST
2.8
15.4
Circuits
2
3
Model No.
VLP-02V
VLP-03V
VLP-04V
VLP-06V
VLP-08V
VLP-12V
Material
Q'ty/bag
500
500
500
500
200
100
11
4
6
8
12
13
6.2
PA 66, UL94V-0, natural (white)
RoHS compliance
Note: Contact JST for Glow Wire compliant connectors.
2
13
11
2.8
15.4
1
3
4
1
２
３
1
２
1
1
7
8
2
３
3
9
10
4
11
5
1
12
6
2
VL CONNECTOR
Retainer
<2, 4 circuits>
11.4
<3, 6 circuits>
17.6
Circuits
2, 4
3, 6
4 (single-row) , 8
Model No.
VLS-02V
VLS-03V
VLS-08V
VLS-12V
Material
Q'ty/bag
1,000
1,000
1,000
1,000
9.4
9.4
12
5.9
5.9
Glass-filled PA 66, UL94V-0, natural (ivory)
RoHS compliance
<4 circuits (Single-row),
8 circuits>
23.8
<12 circuits>
36.2
9.4
5.9
Shrouded header
<2, 3 circuits>
B
11.2
8.2
5.9
9.4
<4, 6 circuits>
B
18
15
16.4
3.6
1.8
6.2
A
1.6
4.84
2
A
6.2
3.6
16.4
1.8
8.28
1.6
<4 circuits (Single-row)>
B
11.2
8.2
<8, 12 circuits>
B
18
15
16.4
3.6
1.54
6.2
A
1.33
5
2
A
6.2
3.6
16.4
1.8
8.28
1.6
Circuits
2
3
4
4 (single-row)
6
8
12
Model No.
B02P-VL
B03P-VL
B04P-VL
B04P-VL-VN-1.8
B06P-VL
B08P-VL
B12P-VL
Material and Finish
Dimensions (mm)
A
B
6.2
12.4
6.2
18.6
12.4
18.6
31.0
13.4
19.6
13.4
26.2
19.6
26.2
38.6
Q’ty/
box
100
100
100
100
50
50
35
Post: Copper-alloy, tin-plated (reflow treatment)
Wafer: PA 66, UL94V-0, natural (white)
4
RoHS compliance
Note: Contact JST for Glow Wire compliant connectors.
