SCN
CONNECTOR
2.5mm pitch/Board-in Crimp style connectors
This 2.5mm pitch multi-circuit
board-in connector meets the needs for
high-density mounting on printed circuit
boards efficiently and economically.
The connector can be used for VCRs, car
stereo systems, audio products, and many
other consumer-oriented electronic
products.
• Housing lances
• Secure mounting on printed circuit boards
• Two types of contacts
2.5
min
6.5
(Note 2)
1.6
2
10.1
Note: 1. The above figure is the figure viewed from soldering side.
2. Applicable PC board thickness: Type A 1.6mm
Type B 1.6mm and 1.2mm.
3. Tolerances are non-cumulative:
±
0.05mm
Type A: 1.0
±
0.05mm dia.
Type B: 2 to 6 circuits/1.0
±
0.05mm dia.
7 circuits and more/Hole dimensions differ from the above values. Contact JST for details.
4. Hole dimensions differ according to the kind of PC board and piercing method. The dimensions above should serve as a guideline. Contact JST for details.
JS
T
Specifications –––––––––––––––––––
• Current rating: 3A AC, DC (AWG #22)
• Voltage rating: 250V AC, DC
• Temperature range: -25˚C to +85˚C
(including temperature rise in applying
electrical current)
• Insulation resistance: 1,000M
Ω
min.
• Withstanding voltage: 800V AC/minute
• Applicable wire: AWG #28 to #22
• Applicable PC board thickness: 1.2mm, 1.6mm
*
In using the products, refer to "Handling Precaution for Terminal
and Connector" described on our website (Technical documents
of Product information page).
*
Contact JST for details.
*
RoHS2 compliance.
Standards ––––––––––––––––––––––
0
Recognized E60389
3.9
2.5
± 0.05
2
min
2.25
1
SCN CONNECTOR
Contact
Type A
1.1
2
9.8
Model No.
SCN-001T-P1.0
SCN-001T-1.0K
Type
A
B
Applicable wire
mm
2
AWG #
0.08∼0.33
28∼22
Insulation O.D.
Material Q’ty / reel
(mm)
Phosphor bronze
0.9∼1.7
Brass
11,000
Material and Finish
Tin-plated (reflow treatment)
Type B
RoHS2 compliance
Note: 1. Contact JST if you require shielded wires, thin wires or other special
wires.
2. Contact JST for brass products.
Crimping
machine Crimp applicator
MKS-L
*MKS-SC
Contact
1.15
1.8
9.5
Applicator
Dies
MK/SCN-001-10
SC/SCN-001-10
Crimp applicator with dies
APLMK SCN001-10
APLSC SCN001-10
SCN-001T-P1.0
AP-K2N
SCN-001T-1.0K
Note: *Strip-crimp applicator
Housing
Circuits
2
3
3.9
Model No.
2P-SCN
3P-SCN
4P-SCN
5P-SCN
6P-SCN
7P-SCN
8P-SCN
9P-SCN
10P-SCN
11P-SCN
12P-SCN
13P-SCN
14P-SCN
15P-SCN
16P-SCN
A
Dimensions (mm)
B
6.5
9.0
11.5
14.0
16.5
19.0
21.5
24.0
26.5
29.0
31.5
34.0
36.5
39.0
41.5
Q'ty / bag
1,000
1,000
1,000
1,000
1,000
1,000
1,000
1,000
1,000
1,000
1,000
1,000
1,000
1,000
1,000
2.5
5.0
7.5
10.0
12.5
15.0
17.5
20.0
22.5
25.0
27.5
30.0
32.5
35.0
37.5
4
5
6
7
8
16
15
14
1
6.5
9
10
11
12
13
2.5
A
B
3.7
14
15
16
Material
and Finish
PA 66, UL94V-0, ivory
RoHS2 compliance
<For reference>
As the color identification,
the following alphabet shall be put in the underlined part.
For availability, delivery and minimum order quantity, contact JST.
ex.
2P-SCN-oo-
(blank)…ivory
K…black R…red Y…yellow
2
