ZL
CONNECTOR
5.0mm pitch/Disconnectable Crimp style Wire-to-wire connectors
Specifications –––––––––––––––––––
• Current rating: 10A AC, DC max.
• Voltage rating: 300V AC, DC max.
• Temperature range: -25˚C to +90˚C
(including temperature rise in applying
electrical current)
• Contact resistance: Initial value/7m
max.
After environmental testing/10m
max.
• Insulation resistance:
1,000M
min.
• Withstanding voltage: 1,500V AC/minute
• Applicable wire: AWG #26 to #16
0.13 to 1.25mm
2
• Applicable panel thickness: 0.7 to 2.4mm
* Compliant with RoHS.
* Refer to "General Instruction and Notice when using
Terminals and Connectors" at the end of this catalog.
* Contact JST for details.
Note: The current rating varies depending on the number of circuits and the
wire size used in each connector.
The table below lists the current rating as a function of the number of
circuits and wire size.
Retainer
Housing lance
Box-shaped contact
Current unit: A
Circuits
#16
2
4
6
10
9
8
6
6
5
Wire size (AWG)
#18
6
5
4
4
4
3
#20
5
4
3
3
3
2
#22
4
3
3
3
3
2
#24
3
3
2
2
2
1
#26
2
2
2
2
2
1
ZL connectors are reliable, smoothly mating
wire-to-wire connectors.
• Housing lances
• Retainer
• Box-shaped contacts
• Mountable on a variety of panels
8
12
16
Standards ––––––––––––––––––––––
1
Certified LR20812
Circuits
2・ 4
6・8・12・16
A
0
Recognized E60389
Panel layout and Assembly layout
(41.8)
(including retainer)
Dimensions A (mm)
18.2
17.5
(38.2)
Shape
I
E
B
Shape
II
B
Circuits
2
4
D
C
Receptacle
housing
ZLR-02V
ZLR-04V
ZLR-06V
ZLR-08V
ZLR-12V
ZLR-16V
Panel Panel hole dimensions (mm) General tolerance
±0.13
Applicable panel
hole
thickness (mm)
A
B
C
D
E
shape
1
1
2
2
2
2
11.5
16.5
21.5
26.5
36.5
46.5
4.4
5.2
5.2
5.2
5.2
5.2
13.95
13.95
13.95
13.95
13.95
13.95
13.2
13.2
13.2
13.2
13.2
13.2
6.5
11.6
0.7
2.4
7.8
D
C
6
8
12
2.7
A
A
16
Note: 1. Punch holes in the panel according to the figures and table shown above. Burrs must be removed.
2. The strength of the panel must be considered when punching two or more holes.
3. The connector must be inserted from the same side as the hole is punched.
1
