The 60R Series radial leaded device is designed to provide
overcurrent protection for (≤60V) applications where space
is not a concern and resettable protection
is preferred.
Features
• Cured, flame retardant
epoxy polymer insulating
material meets UL 94V-0
requirements
Applications
60R010X & 60R017X
E183209
N/A
• Fast time–to-trip
• RoHS compliant, Lead-
Free and Halogen-Free*
Agency Approvals
AGENCY
AGENCY FILE
NUMBER
E183209
R50119318
• USB hubs, ports
and peripherals
• IEEE1394 ports
• Computers & peripherals
• Motor protection
• General electronics
• Automotive applications
• Industrial controls
• Transformers
Electrical Characteristics
I
hold
(A)
0.10
0.17
0.20
0.25
0.30
0.40
0.50
0.65
0.75
0.90
1.10
1.35
1.60
1.85
2.50
3.00
3.75
I
trip
(A)
0.20
0.34
0.40
0.50
0.60
0.80
1.00
1.30
1.50
1.80
2.20
2.70
3.20
3.70
5.00
6.00
7
.50
V
max
(Vdc)
60
60
60
60
60
60
60
60
60
60
60
60
60
60
60
60
60
I
max
(A)
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
40
P
d
typ.
(W)
0.38
0.48
0.41
0.45
0.49
0.56
0.77
0.88
0.92
0.99
1.50
1.70
1.90
2.10
2.50
2.80
3.20
Maximum Time
To Trip
Current
(A)
0.50
0.85
1.00
1.25
1.50
2.00
2.50
3.25
3.75
4.50
5.50
6.75
8.00
9.25
12.50
15.00
18.75
Time
(Sec.)
4.00
3.00
2.20
2.50
3.00
3.80
4.00
5.30
6.30
7
.20
8.20
9.60
11.40
12.60
15.60
19.80
24.00
Resistance
R
min
(Ω)
2.500
3.300
1.830
1.250
0.880
0.550
0.500
0.310
0.250
0.200
0.150
0.120
0.090
0.080
0.050
0.040
0.030
R
1max
(Ω)
7
.500
8.000
4.400
3.000
2.100
1.290
1.170
0.720
0.600
0.470
0.380
0.300
0.220
0.190
0.130
0.100
0.080
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
X
Part Number
Agency
Approvals
60R010X
60R017X
60R020X
60R025X
60R030X
60R040X
60R050X
60R065X
60R075X
60R090X
60R110X
60R135X
60R160X
60R185X
60R250X
60R300X
60R375X
I
hold
= Hold current: maximum current device will pass without tripping in 20°C still air.
I
trip
= Trip current: minimum current at which the device will trip in 20°C still air.
V
max
= Maximum voltage device can withstand without damage at rated current (I max)
I
max
= Maximum fault current device can withstand without damage at rated voltage (V
max
)
P
d
= Power dissipated from device when in the tripped state at 20°C still air.
R
min
= Minimum resistance of device in initial (un-soldered) state.
R
typ
= Typical resistance of device in initial (un-soldered) state.
R
1max
= Maximum resistance of device at 20°C measured one hour after tripping or reflow
soldering of 260°C for 20 sec.
Caution:
Operation beyond the specified rating may result in damage and possible arcing
and flame.
* Effective January 1, 2010, all 60R PTC products will be manufactured Halogen Free (HF). Existing Non-Halogen Free 60R PTC products may continue to be sold, until supplies are depleted.
