NOTES:
1) MATERIAL:
"BLANK" = NYLON 6/6, UNFILLED UL94V-2, COLOR: NATURAL.
"BL" = NYLON 6/6, UNFILLED UL94V-2, COLOR: BLACK.
"BU" = NYLON 6/6, UNFILLED UL94V-2, COLOR: BLUE.
"RE"= NYLON 6/6, UNFILLED UL94V-2, COLOR: RED.
"YE"= NYLON 6/6, UNFILLED UL94V-2, COLOR: YELLOW
"GRE"= NYLON 6/6, UNFILLED UL94V-2, COLOR: GREEN.
"210" = NYLON 6/6, UNFILLED UL94V-0, COLOR: NATURAL.
"400" = NYLON 6/6, UNFILLED UL94V-0, COLOR: BLACK.
2) FINISH: NOT APPLICABLE
3) PRODUCT SPECIFICATION: PS-5556-001
4) PACKAGING: BULK PACKED PER PK-5557-002
5) PART MATES WITH MOLEX PLUG #5559 AND HEADERS #5566, #5569.
6) PART TO BE USED WITH MOLEX FEMALE TERMINAL #5556.
7) PART IS NOT DESIGNED FOR CURRENT SHARING.
8) CONNECTORS ARE NOT TO BE MATED OR UNMATED WHILE CIRCUITS ARE LIVE.
9) WIRES ARE TO BE DRESSED IN SUCH A MANNER TO ALLOW THE TERMINALS
TO FLOAT FREELY IN THE POCKET.
10) PART CONFORMS TO CLASS "B" REQUIREMENTS OF COSMETIC SPECIFICATION
PS-45499-002 WITH THE EXCEPTION OF DISCOLORATION, FLASH AND SINK MEET
CLASS "C" REQUIREMENTS.
11
TO BE MEASURED AT SURFACE
Z
12
TEXT ON PART IS FOR REFERENCE ONLY. TEXT AND TEXT LOCATION MAY VARY
DEPENDING ON PART NUMBER AND/OR TOOL.
H
G
F
E
.21
±
.03
5.4
±
0.8
.46
11.6
.42
10.6
E
.33
8.5
D
.42
10.7
D
.77
19.6
.25
6.3
Z
C
.12
3.0
4-24 CKT
2 CKT ONLY
.098
2.50
B
.38
9.6
2.031/(51.60)
1.866/(47.40)
1.701/(43.20)
1.535/(39.00)
1.370/(34.80)
1.205/(30.60)
1.039/(26.40)
0.874/(22.20)
0.709/(18.00)
0.543/(13.80
0.378/(9.60)
0.213/(5.40)
A
1.819/(46.20)
1.654/(42.00)
1.488/(37.80)
1.323/(33.60)
1.157/(29.40)
0.992/(25.20)
0.827/(21.00
0.661/(16.80)
0.496/(12.60)
0.331/(8.40)
0.165/(4.20)
B
C
B
SYMBOLS
=
0
=
0
THIS DRAWING CONTAINS INFORMATION THAT IS PROPRIETARY TO MOLEX ELECTRONIC TECHNOLOGIES, LLC AND SHOULD NOT BE USED WITHOUT WRITTEN PERMISSION
DIMENSION UNITS
SCALE
CURRENT REV DESC: UPDATE NOTE 4
.165
4.20
.106
2.70
.165
TYP
4.20
B
±
.016
±
0.40
IN/MM
MM
4:1
INCH
±
±
GENERAL TOLERANCES
(UNLESS SPECIFIED)
=
0
EC NO:
600128
.04
1.0
=
0
=
0
=
0
=
0
=
0
4 PLACES
±
3 PLACES
±
2 PLACES
±
1 PLACE
±
0.01
0.25
0.38
±
0.015
±
±
±
0.5 °
A
A
DOCUMENT STATUS
12
±
.016
11
±
0.40
0 PLACES
±
ANGULAR TOL
DRWN:
AZAHIROVIC
CHK'D:
JBELL
APPR:
FSMITH
INITIAL REVISION:
DRWN:
S.MOCHIZUKI
APPR:
FSMITH
THIRD ANGLE PROJECTION
DRAWING
2018/04/11
2018/06/01
2018/06/03
1990/02/22
2011/02/21
SERIES
MINIFIT JR
RECEPTACLE HOUSING DUAL ROW 2-24 CKT
PRODUCT CUSTOMER DRAWING
DOCUMENT NUMBER
DOC TYPE
DOC PART
REVISION
A
SD-5557-003
MATERIAL NUMBER
CUSTOMER
PSD
000
J18
P1
RELEASE DATE
11
2018/06/03
10
20:30:51
9
8
7
6
C
=
0
DRAFT WHERE APPLICABLE
MUST REMAIN
WITHIN DIMENSIONS
SHEET NUMBER
C-SIZE
4
5557
3
SEE CHART
GENERAL MARKET
1 OF 2
5
2
1
