SEE NOTE 11
.209
5.30
CIRCUIT #1 IDENTIFIER
ITEM
NUMBER
.326
8.28
NUMBER
OF
CIRCUIT
DIM.
"A"
DIM.
"B"
MATERIAL
"B"
M
.180
4.57
43645-0200
43645-0300
43645-0400
43645-0500
43645-0600
43645-0700
43645-0800
43645-0900
43645-1000
43645-1100
43645-1200
02
03
04
05
06
07
08
09
10
11
12
SEE DETAIL
.118/(3.00)
.236/(6.00)
43645
.388/(9.85)
L
43645
.551
14.00
.455
REF
11.56
.506/(12.85)
.354/(9.00)
.624/(15.85) .472/(12.00)
.742/(18.85) .591/(15.00)
.860/(21.85) .709/(18.00)
.978/(24.85) .827/(21.00)
L
K
.200
5.09
.080
2.03
.076
1.93
.152
3.86
CIRCUIT #1 IDENTIFIER
1.096/(27.85)
.945/(24.00)
1.215/(30.85) 1.063/(27.00)
1.333/(33.85) 1.181/(30.00)
1.451/(36.85) 1.299/(33.00)
"A"
K
CIRCUIT #1
A
J
.118
3.00
.076
1.93
J
H
.118
TYP
3.00
.075
1.92
"B"
"A"
A
FIRST CIRCUIT
IDENTIFIER RIB
(ALL CIRCUIT SIZES)
H
(2 CIRCUIT HOUSING)
G
G
(3-12 CIRCUIT HOUSING)
RECEPTACLE #43645-****
F
.691
(17.56)
HEADER #43650-****
.030
REF
0.76
TERMINAL INSERTION
DEPTH
F
TERMINAL STOPS
TERMINAL LOCKING TABS MUST BE FULLY
SEATED TO HOUSING BEFORE MATING WITH
OTHER HALF OF THE CONNECTOR SYSTEM.
B
E
E
MATED MICRO-FIT CONNECTOR
NOTES:
1. HOUSING MATERIAL:
B
TERMINAL 43030-****
D
"A" - UNFILLED POLYESTER, RATED U.L. 94V-0, COLOR IS BLACK.
2.
3.
4.
5.
6.
7.
8.
9.
10.
"B" - UNFILLED NYLON, RATED U.L. 94V-0, HALOGEN-FREE, COLOR IS BLACK.
FINISH : N/A
PRODUCT SPECIFICATION : PS-43650
PACKAGING SPECIFICATION: PK-43645-001
THIS RECEPTACLE ACCEPTS MOLEX MICRO FIT FEMALE CRIMP TERMINALS SERIES 43030 OR 46235,
SEE SECTION "A"-"A" FOR TERMINAL ORIENTATION IN HOUSING.
FOR OVERMOLDING PARAMETERS SEE APPLICATION SPECIFICATION 430250000-AS.
THIS RECEPTACLE MATES WITH MOLEX PCB HEADER 43650 SERIES AND
MOLEX PLUG 43640 SERIES (WIRE TO WIRE APPLICATIONS).
SOME HOUSINGS MAY HAVE A SMALL GATE BLEMISH NEAR THE GATE LOCATION THAT DOES NOT AFFECT FUNCTIONALITY.
MOLEX RECOMMENDS THE USE OF MICRO-FIT TEST PLUG, SERIES 44242-**** WHENEVER CONTINUITY TESTING IS PERFORMED.
TEST PLUGS MUST NOT BE USED TO MAKE OR BREAK UNDER LOAD. MOLEX DOES NOT RECOMMEND USING
STANDARD MATING COMPONENTS FOR HARNESS TESTING PURPOSES.
THIS RIB IS DISCONTINUOUS ON CIRCUIT SIZES 7 THROUGH 12
PART CONFORMS TO CLASS 'B' REQUIREMENTS OF COSMETIC SPECIFICATION PS-45499-002.
TEXT ON PART IS FOR REFERENCE ONLY. TEXT AND TEXT LOCATION MAY VARY DEPENDING ON PART NUMBER AND/OR TOOL.
SECTION "B"-"B"
SECTION "A"-"A"
SHOWN WITH TERMINAL INSTALLED
D
C
SYMBOLS
=
0
=
0
=
0
=
0
=
0
=
0
=
0
=
0
=
0
THIS DRAWING CONTAINS INFORMATION THAT IS PROPRIETARY TO MOLEX ELECTRONIC TECHNOLOGIES, LLC AND SHOULD NOT BE USED WITHOUT WRITTEN PERMISSION
C
DIMENSION UNITS
SCALE
IN/MM
MM
4:1
INCH
±
±
CURRENT REV DESC: INITIAL RELEASE
GENERAL TOLERANCES
(UNLESS SPECIFIED)
SEE NOTE 11
4 PLACES
±
3 PLACES
±
2 PLACES
±
1 PLACE
±
B
0.01
11.
12.
13.
0.25
0.35
±
0.014
±
±
±
0.5 °
0 PLACES
±
ANGULAR TOL
DRWN:
AZAHIROVIC
CHK'D: SSOUSEK
APPR:
FSMITH
INITIAL REVISION:
DRWN:
A.F.G
APPR: R.J.F
THIRD ANGLE PROJECTION
DRAWING
EC NO:
168740
2018/03/13
2018/06/01
2018/06/01
1995/11/15
1995/11/15
SERIES
MICRO-FIT (3.0) RECEPTACLE, SINGLE ROW
2 THRU 12 CIRCUIT
PRODUCT CUSTOMER DRAWING
DOCUMENT NUMBER
DOC TYPE
DOC PART
REVISION
B
436450000-SD
MATERIAL NUMBER
CUSTOMER
PSD
000
A
A
1
A
DOCUMENT STATUS
FORMAT: Eng-lega-master-tb-prod-D
REVISION: D
DATE: 2018/01/18
P1
RELEASE DATE
18
2018/06/01
17
21:26:13
16
15
14
13
12
THIS DRAWING REPLACES DRAWING SDA-43645-++++.
11
10
9
C
DRAFT WHERE APPLICABLE
MUST REMAIN
WITHIN DIMENSIONS
SHEET NUMBER
D-SIZE
6
5
43645
4
SEE CHART
3
GENERAL MARKET
2
1 OF 1
20
19
8
