NOTES:
1. MATERIALS:
HOUSING:
'BLANK'=NYLON 6/6, UL94V-2, COLOR: NATURAL
"210" =NYLON 6/6, UL94V-0, COLOR: NATURAL
"400"=NYLON 6/6, UL94V-0, COLOR: BLACK
TERMINALS:
"BLANK" = BRASS
"PB" = PHOSPHER BRONZE
2. TERMINAL PLATING:
"BLANK" = REFLOWED MATTE TIN 000035/(0.00090) MIN.
OVER COPPER .000020/(0.00050) MIN. (BRASS) (PREPLATE)
OR REFLOWED MATTE TIN .000035/(0.00090) MIN. (PHOSHOR BRONZE) (PREPLATE)
(FINISH IS BRIGHT IN APPEARANCE, THICKNESS AS APPLIED PRIOR TO REFLOW)
"S"=.000100/(0.00254) MIN. BRIGHT TIN OVER
.000050/(0.00127) MIN NICKEL
"GS2"=.000015/(0.00038) MIN. SELECT GOLD AND
.000100/(0.00254) MIN. SELECT MATTE TIN
OVER .000050/(0.00127) MIN. NICKEL OVERALL
"GS"=.000030/(0.00076) MIN. SELECT GOLD AND
.000100/(0.00254) MIN. SELECT MATTE TIN
OVER .000050/(0.00127) MIN. NICKEL OVERALL
3. PRODUCT SPECIFICATION: PS-5556-001
4. PACKAGING: "BLANK"= BULK PACKED,
"TA"=TRAY PACK PER PK-5566-001, "TR"=TRAY PACK PER PK-5566
5. PART MATES WITH MINI-FIT JR. RECEPTACLE NO. 5557.
6. PART IS NOT DESIGNED FOR CURRENT SHARING.
7. PARTS ARE NOT DESIGNED TO BE MATED OR UN-MATED
WHILE CIRCUITS ARE LIVE.
8 ANTI-SHINGLING RIB MAY OR MAY NOT APPEAR ON
HOUSINGS.
9. PART CONFORMS TO CLASS "B" REQUIREMENTS OF
COSMETIC SPECIFICATION PS-45499-002.
10.TEXT ON PART IS FOR REFERENCE ONLY. TEXT AND TEXT LOCATION MAY VARY
DEPENDING ON PART NUMBER AND/OR TOOL.
LEGEND
H
G
F
E
.13
±
.01
3.4
±
0.2
(OPTION : SEE LEGEND )
8
.02
±
.01
0.4
±
0.2
.06
±
.01
1.4
±
0.2
.12
±
.01
3.1
±
0.2
BASE NUMBER
CIRCUIT SIZE
.50
±
.01
12.8
±
0.3
D
ASS'Y TYPE
A : WITHOUT DRAIN HOLES
B : WITH DRAIN HOLES
TERMINAL MATERIAL
D
SEE NOTE 1
TERMINAL PLATING
SEE NOTE 2
.073
1.85
C
.22
5.5
.14
±
.02
3.5
±
0.5
HOUSING MATERIAL
SEE NOTE 1
COLOR OR PACKAGING
C
.17TYP
4.2
.11
2.7
B
.04/1.0
.1654
±
.004TYP
4.200
±
0.10
B
BL : BLACK
RE : RED
GR : GRAY
GRE : GREEN
YE : YELLOW
BU : BLUE
V : VIOLET
OR : ORANGE
TA : TRAY PACKAGING SEE NOTE 4
TR : TRAY PACKAGING SEE NOTE 4
B
QUALITY THIS DRAWING CONTAINS INFORMATION THAT IS PROPRIETARY TO MOLEX ELECTRONIC TECHNOLOGIES, LLC AND SHOULD NOT BE USED WITHOUT WRITTEN PERMISSION
DIMENSION UNITS
SCALE
SYMBOLS
⌀
.055
±
.002
1.40
±
0.05
2016/08/26
2016/09/20
2016/09/23
GENERAL TOLERANCES
(UNLESS SPECIFIED)
.217
±
.004
5.50
±
0.10
=
=
=
0
UPDATE NOTE 2
IN/MM
DRWN BY
DATE
4:1
1989/04/03
DATE
0
0
0
0
0
0
0
MM
INCH
±
±
0.005
±
0.01
±
±
4 PLACES
3 PLACES
±
±
±
0.13
±
0.25
±
H.HIRAMOTO
CHK'D BY
107869
CSLAFTER
JBELL
FSMITH
A
RECOMMENDED HOLE LAYOUT FOR
.070/(1.78) MAX. THICK P.C. BOARD
VIEWED FROM COMPONENT SIDE
MINI FIT JR VERTICAL
HEADER ASSEMBLIES WITHOUT PEGS
=
=
=
=
2 PLACES
1 PLACES
0 PLACES
M.FUKUSHIMA
APPR BY
DATE
1994/04/20
PRODUCT CUSTOMER DRAWING
2012/05/04
SERIES
MATERIAL NUMBER
CUSTOMER
A
FSMITH
DRAWING SIZE
EC NO:
DRWN:
CHK'D:
APPR:
ANGULAR TOL
±
0.5
DRAFT WHERE APPLICABLE
MUST REMAIN
WITHIN DIMENSIONS
THIRD ANGLE PROJECTION
5566
DOCUMENT NUMBER
SEE TABLE
GENERAL MARKET
DOC TYPE
DOC PART
SHEET NUMBER
RELEASE STATUS
FORMAT: Eng-lega-master-tb-prod-C
REVISION: C
DATE: 2016/02/04
RELEASE DATE
C
=
M
5
REV
C
3
SD-5566-002
PSD
000
1 OF 5
1
