BAT54SLT1G,
SBAT54SLT1G
Dual Series Schottky
Barrier Diodes
These Schottky barrier diodes are designed for high speed switching
applications, circuit protection, and voltage clamping. Extremely low
forward voltage reduces conduction loss. Miniature surface mount
package is excellent for hand held and portable applications where
space is limited.
Features
http://onsemi.com
Extremely Fast Switching Speed
Low Forward Voltage
−
0.35 V (Typ) @ I
F
= 10 mAdc
AEC Qualified and PPAP Capable
S Prefix for Automotive and Other Applications Requiring Unique
Site and Control Change Requirements
These Devices are Pb−Free, Halogen Free/BFR Free and are RoHS
Compliant*
MAXIMUM RATINGS
(T
A
= 25C unless otherwise noted)
Rating
Reverse Voltage
Forward Power Dissipation
@ T
A
= 25C
Derate above 25C
Forward Current (DC)
Non−Repetitive Peak Forward Current
t
p
< 10 msec
Square pulse = 1 sec
Repetitive Peak Forward Current
Pulse Wave = 1 sec,
Duty Cycle = 66%
Junction Temperature
Storage Temperature Range
Symbol
V
R
P
F
Value
30
225
1.8
200 Max
600
1.0
300
−55
to 150
−55
to +150
Unit
V
mW
mW/C
mA
mA
A
mA
30 VOLT
DUAL HOT−CARRIER
DETECTOR AND SWITCHING
DIODES
SOT−23
CASE 318
STYLE 11
1
ANODE
2
CATHODE
3
CATHODE/ANODE
MARKING DIAGRAM
I
F
I
FSM
LD3M
G
G
1
LD3
M
G
= Device Code
= Date Code*
= Pb−Free Package
I
FRM
T
J
T
stg
C
C
(Note: Microdot may be in either location)
*Date Code orientation and/or overbar may
vary depending upon manufacturing location.
Stresses exceeding Maximum Ratings may damage the device. Maximum
Ratings are stress ratings only. Functional operation above the Recommended
Operating Conditions is not implied. Extended exposure to stresses above the
Recommended Operating Conditions may affect device reliability.
ORDERING INFORMATION
Device
BAT54SLT1G
SBAT54SLT1G
Package
SOT−23
(Pb−Free)
SOT−23
(Pb−Free)
Shipping
†
3,000 / Tape & Reel
3,000 / Tape & Reel
†For information on tape and reel specifications,
including part orientation and tape sizes, please
refer to our Tape and Reel Packaging Specifications
Brochure, BRD8011/D.
*For additional information on our Pb−Free strategy and soldering details, please
download the ON Semiconductor Soldering and Mounting Techniques
Reference Manual, SOLDERRM/D.
Semiconductor Components Industries, LLC, 2011
November, 2011
−
Rev. 15
1
Publication Order Number:
BAT54SLT1/D
BAT54SLT1G, SBAT54SLT1G
PACKAGE DIMENSIONS
SOT−23 (TO−236)
CASE 318−08
ISSUE AP
D
SEE VIEW C
3
NOTES:
1. DIMENSIONING AND TOLERANCING PER ANSI Y14.5M, 1982.
2. CONTROLLING DIMENSION: INCH.
3. MAXIMUM LEAD THICKNESS INCLUDES LEAD FINISH
THICKNESS. MINIMUM LEAD THICKNESS IS THE MINIMUM
THICKNESS OF BASE MATERIAL.
4. DIMENSIONS D AND E DO NOT INCLUDE MOLD FLASH,
PROTRUSIONS, OR GATE BURRS.
DIM
A
A1
b
c
D
E
e
L
L1
H
E
q
MIN
0.89
0.01
0.37
0.09
2.80
1.20
1.78
0.10
0.35
2.10
0
MILLIMETERS
NOM
MAX
1.00
1.11
0.06
0.10
0.44
0.50
0.13
0.18
2.90
3.04
1.30
1.40
1.90
2.04
0.20
0.30
0.54
0.69
2.40
2.64
−−−
10
MIN
0.035
0.001
0.015
0.003
0.110
0.047
0.070
0.004
0.014
0.083
0
INCHES
NOM
0.040
0.002
0.018
0.005
0.114
0.051
0.075
0.008
0.021
0.094
−−−
MAX
0.044
0.004
0.020
0.007
0.120
0.055
0.081
0.012
0.029
0.104
10
E
1
2
HE
c
e
b
q
0.25
A
A1
L
L1
VIEW C
STYLE 11:
PIN 1. ANODE
2. CATHODE
3. CATHODE−ANODE
SOLDERING FOOTPRINT*
0.95
0.037
0.95
0.037
2.0
0.079
0.9
0.035
SCALE 10:1
0.8
0.031
mm
inches
*For additional information on our Pb−Free strategy and soldering
details, please download the ON Semiconductor Soldering and
Mounting Techniques Reference Manual, SOLDERRM/D.
