TinyLogic ULP-A Buffer
with Three-State Output
NC7SP125
The NC7SP125 is a single non−inverting 3−state buffer in tiny
footprint packages. The device is designed to operate for V
CC =
0.9 V
to 3.6 V.
Features
www.onsemi.com
MARKING
DIAGRAMS
SIP6 1.45X1.0
MicroPak
CASE 127EB
Pin 1
CC
KK
XY
Z
= Specific Device Code
= 2−Digit Lot Run Traceability Code
= 2−Digit Date Code
= Assembly Plant Code
CCKK
XYZ
•
•
•
•
•
•
•
Designed for 0.9 V to 3.6 V V
CC
Operation
3.0 ns t
PD
at 3.3 V (Typ)
Inputs/Outputs Over−Voltage Tolerant up to 3.6 V
I
OFF
Supports Partial Power Down Protection
Source/Sink 2.6 mA at 3.3 V
Available in SC−88A and MicroPak™ Packages
These Devices are Pb−Free, Halogen Free/BFR Free and are RoHS
Compliant
OE 1
A 2
4
SC−88A
Y
GND
3
MicroPak
6 V
CC
5 NC
4 Y
OE
1
5
V
CC
A 2
GND 3
SC−88A
CASE 419A−02
XXXMG
G
Figure 1. Pinout Diagrams
(Top Views)
XXX = Specific Device Code
M
= Date Code
G
= Pb−Free Package
OE
A
EN
ORDERING INFORMATION
Y
See detailed ordering, marking and shipping information on
