74AC244, 74ACT244 — Octal Buffer/Line Driver with 3-STATE Outputs
January 2008
74AC244, 74ACT244
Octal Buffer/Line Driver with 3-STATE Outputs
Features
■
I
CC
and I
OZ
reduced by 50%
■
3-STATE outputs drive bus lines or buffer memory
General Description
The AC/ACT244 is an octal buffer and line driver
designed to be employed as a memory address driver,
clock driver and bus-oriented transmitter/receiver which
provides improved PC board density.
address registers
■
Outputs source/sink 24mA
■
ACT244 has TTL-compatible inputs
Ordering Information
Order Number
74AC244SC
74AC244SJ
74AC244MTC
74AC244PC
74ACT244SC
74ACT244SJ
74ACT244MSA
74ACT244MTC
74ACT244PC
Package
Number
M20B
M20D
MTC20
N20A
M20B
M20D
MSA20
MTC20
N20A
Package Description
20-Lead Small Outline Integrated Circuit (SOIC), JEDEC MS-013, 0.300" Wide
20-Lead Small Outline Package (SOP), EIAJ TYPE II, 5.3mm Wide
20-Lead Thin Shrink Small Outline Package (TSSOP), JEDEC MO-153, 4.4mm
