FDD3682
March 2015
FDD3682
N-Channel PowerTrench
®
MOSFET
100V, 32A, 36mΩ
Features
• r
DS(ON)
= 32mΩ (Typ.), V
GS
= 10V, I
D
= 32A
• Q
g
(tot) = 18.5nC (Typ.), V
GS
= 10V
• Low Miller Charge
• Low Q
RR
Body Diode
• UIS Capability (Single Pulse and Repetitive Pulse)
• Qualified to AEC Q101
Formerly developmental type 82755
Applications
• DC/DC converters and Off-Line UPS
• Distributed Power Architectures and VRMs
• Primary Switch for 24V and 48V Systems
• High Voltage Synchronous Rectifier
• Direct Injection / Diesel Injection System
• 42V Automotive Load Control
• Electronic Valve Train System
DRAIN
(FLANGE)
GATE
SOURCE
D
G
TO-252AA
FDD SERIES
S
MOSFET Maximum Ratings
T
C
= 25°C unless otherwise noted
Symbol
V
DSS
V
GS
Drain to Source Voltage
Gate to Source Voltage
Drain Current
Continuous (T
C
= 25
o
C, V
GS
= 10V)
I
D
Continuous (T
C
= 100 C, V
GS
= 10V)
Continuous (T
amb
= 25
o
C, V
GS
= 10V, R
θJA
= 52
o
C/W)
Pulsed
E
AS
P
D
T
J
, T
STG
Single Pulse Avalanche Energy (Note 1)
Power dissipation
Derate above 25
o
C
o
Parameter
Ratings
100
±20
32
23
5.5
Figure 4
55
95
0.63
-55 to 175
Units
V
V
A
A
A
A
mJ
W
W/
o
C
o
C
Operating and Storage Temperature
Thermal Characteristics
R
θJC
R
θJA
R
θJA
Thermal Resistance Junction to Case TO-252
Thermal Resistance Junction to Ambient TO-252
Thermal Resistance Junction to Ambient TO-252, 1in
2
copper pad area
1.58
100
52
o
C/W
o
C/W
o
C/W
This product has been designed to meet the extreme test conditions and environment demanded by the automotive industry. For a
copy of the requirements, see AEC Q101 at: http://www.aecouncil.com/
Reliability data can be found at: http://www.fairchildsemi.com/products/discrete/reliability/index.html.
All Fairchild Semiconductor products are manufactured, assembled and tested under ISO9000 and QS9000 quality systems
