FGA20N120FTD — 1200 V, 20 A Field Stop Trench IGBT
November 2013
FGA20N120FTD
1200 V, 20 A Field Stop Trench IGBT
Features
• Field Stop Trench Technology
• High Speed Switching
• Low Saturation Voltage: V
CE(sat)
= 1.6 V @ I
C
= 20 A
• High Input Impedance
• RoHS Compliant
General Description
Using advanced field stop trench technology, Fairchild’s 1200V
trench IGBTs offer superior conduction and switching perfor-
mances for soft switching applications. The device can operate
in parallel configuration with exceptional avalanche ruggedness.
This device is designed for induction heating and microwave
oven.
Applications
• Induction Heating, Microvewave Oven
C
G
TO-3P
G C E
E
Absolute Maximum Ratings
Symbol
V
CES
V
GES
I
C
I
CM (1)
I
F
P
D
T
J
T
stg
T
L
Description
Collector to Emitter Voltage
Gate to Emitter Voltage
Continuous Collector Current
Continuous Collector Current
Pulsed Collector Current
Diode Continuous Forward Current
Diode Continuous Forward Current
Maximum Power Dissipation
Maximum Power Dissipation
Operating Junction Temperature
Storage Temperature Range
Maximum Lead Temp. for soldering
Purposes, 1/8” from case for 5 seconds
@ T
C
= 25
o
C
@ T
C
= 100
o
C
@ T
C
= 25
o
C
@ T
C
= 100
o
C
@ T
C
= 25 C
@ T
C
= 100
o
C
o
Ratings
1200
25
40
20
60
20
10
298
119
-55 to +150
-55 to +150
300
Unit
V
V
A
A
A
A
A
W
W
o
o
C
C
o
C
Notes:
1: Repetitive rating, Pulse width limited by max. junction temperature
[font=微软雅黑][size=4]{:1_94:}[b] To meet market demand, STMicroelectronics has made positive progress in launching a new factory and expanding STM8 production capacity, and is expected to start mass shi...
