74AC541, 74ACT541 — Octal Buffer/Line Driver with 3-STATE Outputs
January 2008
74AC541, 74ACT541
Octal Buffer/Line Driver with 3-STATE Outputs
Features
■
I
CC
and I
OZ
reduced by 50%
■
3-STATE outputs
■
Inputs and outputs opposite side of package, allowing
General Description
The 74AC541 and 74ACT541 are octal buffer/line
drivers designed to be employed as memory and
address drivers, clock drivers and bus oriented transmitter/
receivers.
These devices are similar in function to the 74AC244
and 74ACTC244 while providing flow-through architec-
ture (inputs on opposite side from outputs). This pinout
arrangement makes these devices especially useful as
an output port for microprocessors, allowing ease of
layout and greater PC board density.
easier interface to microprocessors
■
Output source/sink 24mA
■
74AC541 is a non-inverting option of the 74AC540
■
74ACT541 has TTL-compatible inputs
Ordering Information
Order Number
74AC541SC
74AC541SJ
74AC541MTC
74AC541PC
74ACT541SC
74ACT541MTC
Package
Number
M20B
M20D
MTC20
N20A
M20B
MTC20
Package Description
20-Lead Small Outline Integrated Circuit (SOIC), JEDEC MS-013, 0.300" Wide
20-Lead Small Outline Package (SOP), EIAJ TYPE II, 5.3mm Wide
20-Lead Thin Shrink Small Outline Package (TSSOP), JEDEC MO-153, 4.4mm
