MC100LVEP111
2.5V / 3.3V 2:1:10
Differential ECL/PECL/HSTL
Clock Driver
Description
The MC100LVEP111 is a low skew 2:1:10 differential driver, designed
with clock distribution in mind, accepting two clock sources into an input
multiplexer. The PECL input signals can be either differential or
single−ended (if the V
BB
output is used). HSTL inputs can be used when
the LVEP111 is operating under PECL conditions.
The LVEP111 specifically guarantees low output−to−output skew.
Optimal design, layout, and processing minimize skew within a device and
from device to device.
To ensure tightest skew, both sides of differential outputs identically
terminate into 50
W
even if only one output is being used. If an output
pair is unused, both outputs may be left open (unterminated) without
affecting skew.
The MC100LVEP111, as with most other ECL devices, can be
operated from a positive V
CC
supply in PECL mode. This allows the
LVEP111 to be used for high performance clock distribution in +3.3 V or
+2.5 V systems. Single−ended CLK input operation is limited to a V
CC
≥
3.0 V in PECL mode, or V
EE
v
−3.0 V in NECL mode when using VBB
(See Figure 11). Full operating range is available when using an external
voltage reference (See Figure 10). Designers can take advantage of the
LVEP111’s performance to distribute low skew clocks across the
backplane or the board.
Features
www.onsemi.com
MARKING
DIAGRAMS*
MC100
LVEP111
AWLYYWWG
LQFP−32
FA SUFFIX
CASE 873A
32
1
1
1
32
QFN32
MN SUFFIX
CASE 488AM
A
WL
YY
WW
G or
G
MC100
LVEP111
AWLYYWW
G
•
•
•
•
•
•
•
•
•
85 ps Typical Device−to−Device Skew
20 ps Typical Output−to−Output Skew
Jitter Less than 1 ps RMS
Additive RMS Phase Jitter: 60 fs @ 156.25 MHz, Typ.
Maximum Frequency > 3 GHz Typical
V
BB
Output
430 ps Typical Propagation Delay
The 100 Series Contains Temperature Compensation
PECL and HSTL Mode Operating Range: V
CC
= 2.375 V to 3.8 V
with V
EE
= 0 V
= Assembly Location
= Wafer Lot
= Year
= Work Week
= Pb−Free Package
*For additional marking information, refer to
Application Note AND8002/D.
ORDERING INFORMATION
See detailed ordering and shipping information in the package
dimensions section on page 11 of this data sheet.
•
NECL Mode Operating Range: V
CC
= 0 V
with V
EE
= −2.375 V to −3.8 V
•
Open Input Default State
•
LVDS Input Compatible
•
Fully Compatible with MC100EP111
•
These are Pb−Free Devices
©
Semiconductor Components Industries, LLC, 2015
1
August, 2015 − Rev. 23
Publication Order Number:
MC100LVEP111/D
MC100LVEP111
Q3
Q3
Q4
Q4
Q5
Q5
Q6
Q6
Table 1. PIN DESCRIPTION
PIN
FUNCTION
ECL/PECL/HSTL CLK Input
ECL/PECL/HSTL CLK Input
ECL/PECL Outputs
ECL/PECL Active Clock Select Input
Reference Voltage Output
Positive Supply
Negative Supply
The exposed pad (EP) on the package
bottom must be attached to a heat−sink-
ing conduit. The exposed pad may only
be electrically connected to V
EE
.
* Pins will default LOW when left open.
** Pins will default to 2/3V
CC
when left open.
24
V
CC
Q2
Q2
Q1
Q1
Q0
Q0
V
CC
25
26
27
28
23
22
21
20
19
18
17
16
15
14
13
V
CC
Q7
Q7
Q8
Q8
Q9
Q9
V
CC
CLK0*, CLK0**
CLK1*, CLK1**
Q0:9, Q0:9
CLK_SEL*
V
BB
V
CC
12
11
10
9
V
EE
EP
MC100LVEP111
29
30
31
32
1
2
3
4
5
6
7
8
CLK_SEL
CLK0
CLK0
CLK1
V
CC
V
BB
CLK1
V
EE
Table 2. FUNCTION TABLE
CLK_SEL
L
H
Active Input
CLK0, CLK0
CLK1, CLK1
Warning: All V
CC
and V
EE
pins must be externally connected
to Power Supply to guarantee proper operation.
Figure 1. LQFP−32 Pinout
(Top View)
V
CC
32
V
CC
CLK_SEL
CLK0
CLK0
V
BB
CLK1
CLK1
V
EE
1
2
3
4
5
6
7
8
9
Q0
31
Q0
30
Q1
29
Q1
28
Q2
27
Q2 V
CC
26
25
24
Q3
23
Q3
22
Q4
MC100LVEP111
21
Q4
20
Q5
19
Q5
18
Q6
17
Q6
10
11
Q9
12
Q8
13
Q8
14
Q7
15
Q7
16
V
CC
Exposed Pad (EP)
V
CC
Q9
Figure 2. QFN−32 Pinout
(Top View)
www.onsemi.com
2
MC100LVEP111
Table 3. ATTRIBUTES
Characteristics
Internal Input Pulldown Resistor
Internal Input Pullup Resistor
ESD Protection
Human Body Model
Machine Model
Charged Device Model
Pb Pkgs
LQFP
QFN
Flammability Rating
Transistor Count
Meets or exceeds JEDEC Spec EIA/JESD78 IC Latchup Test
1. For additional information, refer to Application Note AND8003/D.
Oxygen Index: 28 to 34
Level 2
Level 1
Value
75 kW
37.5 kW
> 2 kV
> 100 V
> 2 kV
Pb−Free Pkgs
Level 2
Level 1
Moisture Sensitivity (Note 1)
UL 94 V−0 @ 0.125 in
602 Devices
Q
0
Q
0
Q
1
Q
1
Q
2
Q
2
Q
3
Q
3
CLK0
0
CLK0
CLK1
1
CLK1
V
BB
CLK_SEL
V
EE
Q
4
Q
4
Q
5
Q
5
Q
6
Q
6
Q
7
Q
7
Q
8
V
CC
Q
8
Q
9
Q
9
Figure 3. Logic Diagram
www.onsemi.com
3
MC100LVEP111
Table 4. MAXIMUM RATINGS
Symbol
V
CC
V
EE
V
I
I
out
I
BB
T
A
T
stg
q
JA
q
JC
q
JA
q
JC
T
sol
Parameter
PECL Mode Power Supply
NECL Mode Power Supply
PECL Mode Input Voltage
NECL Mode Input Voltage
Output Current
V
BB
Sink/Source
Operating Temperature Range
Storage Temperature Range
Thermal Resistance (Junction−to−Ambient)
Thermal Resistance (Junction−to−Case)
Thermal Resistance (Junction−to−Ambient)
Thermal Resistance (Junction−to−Case)
Wave Solder
Pb
Pb−Free (QFN−32 Only)
0 lfpm
500 lfpm
Standard Board
0 lfpm
500 lfpm
2S2P
< 3 sec @ 248°C
< 3 sec @ 260°C
LQFP−32
LQFP−32
LQFP−32
QFN−32
QFN−32
QFN−32
Condition 1
V
EE
= 0 V
V
CC
= 0 V
V
EE
= 0 V
V
CC
= 0 V
Continuous
Surge
V
I
≤
V
CC
V
I
≥
V
EE
Condition 2
Rating
6
−6
6
−6
50
100
±
0.5
−40 to +85
−65 to +150
80
55
12 to 17
31
27
12
265
265
Unit
V
V
V
V
mA
mA
mA
°C
°C
°C/W
°C/W
°C/W
°C/W
°C/W
°C/W
°C
Stresses exceeding those listed in the Maximum Ratings table may damage the device. If any of these limits are exceeded, device functionality
should not be assumed, damage may occur and reliability may be affected.
www.onsemi.com
4
MC100LVEP111
Table 5. PECL DC CHARACTERISTICS
V
CC
= 2.5 V; V
EE
= 0 V (Note 2)
−40°C
Symbol
I
EE
V
OH
V
OL
V
IH
V
IL
V
IHCMR
Characteristic
Power Supply Current
Output HIGH Voltage (Note 3)
Output LOW Voltage (Note 3)
Input HIGH Voltage (Single−Ended)
(Note 4)
Input LOW Voltage (Single−Ended)
(Note 4)
Input HIGH Voltage Common Mode
Range (Differential Configuration)
(Note 5)
Input HIGH Current
Input LOW Current
CLK
CLK
0.5
−150
Min
60
1355
505
1335
505
1.2
Typ
90
1480
730
Max
120
1605
900
1620
875
2.5
Min
60
1355
505
1335
505
1.2
25°C
Typ
90
1480
730
Max
120
1605
900
1620
875
2.5
Min
60
1355
505
1275
505
1.2
85°C
Typ
90
1480
730
Max
120
1605
900
1620
875
2.5
Unit
mA
mV
mV
mV
mV
V
I
IH
I
IL
150
0.5
−150
150
0.5
−150
150
mA
mA
NOTE: Device will meet the specifications after thermal equilibrium has been established when mounted in a test socket or printed circuit
board with maintained transverse airflow greater than 500 lfpm.
2. Input and output parameters vary 1:1 with V
CC
. V
EE
can vary + 0.125 V to −1.3 V.
3. All loading with 50
W
to V
EE
.
4. Do not use V
BB
at V
CC
< 3.0 V.
5. V
IHCMR
min varies 1:1 with V
EE
, V
IHCMR
max varies 1:1 with V
CC
. The V
IHCMR
range is referenced to the most positive side of the differential
input signal.
Table 6. PECL DC CHARACTERISTICS
V
CC
= 3.3 V; V
EE
= 0 V (Note 6)
−40°C
Symbol
I
EE
V
OH
V
OL
V
IH
V
IL
V
BB
V
IHCMR
Characteristic
Power Supply Current
Output HIGH Voltage (Note 7)
Output LOW Voltage (Note 7)
Input HIGH Voltage (Single−Ended)
Input LOW Voltage (Single−Ended)
Output Reference Voltage (Note 8)
Input HIGH Voltage Common Mode
Range (Differential Configuration)
(Note 9)
Input HIGH Current
Input LOW Current
CLK
CLK
0.5
−150
Min
60
2155
1305
2135
1305
1775
1.2
1875
Typ
90
2280
1530
Max
120
2405
1700
2420
1675
1975
3.3
Min
60
2155
1305
2135
1305
1775
1.2
1875
25°C
Typ
90
2280
1530
Max
120
2405
1700
2420
1675
1975
3.3
Min
60
2155
1305
2135
1305
1775
1.2
1875
85°C
Typ
90
2280
1530
Max
120
2405
1700
2420
1675
1975
3.3
Unit
mA
mV
mV
mV
mV
mV
V
I
IH
I
IL
150
0.5
−150
150
0.5
−150
150
mA
mA
NOTE: Device will meet the specifications after thermal equilibrium has been established when mounted in a test socket or printed circuit
board with maintained transverse airflow greater than 500 lfpm.
6. Input and output parameters vary 1:1 with V
CC
. V
EE
can vary + 0.925 V to −0.5 V.
7. All loading with 50
W
to V
CC
− 2.0 V.
8. Single ended input operation is limited V
CC
≥
3.0 V in PECL mode.
9. V
IHCMR
min varies 1:1 with V
EE
, V
IHCMR
max varies 1:1 with V
CC
. The V
IHCMR
range is referenced to the most positive side of the differential
input signal.
Table 7. NECL DC CHARACTERISTICS
V
CC
= 0 V, V
EE
= −2.375 V to −3.8 V (Note 10)
−40°C
Symbol
I
EE
V
OH
V
OL
Characteristic
Power Supply Current
Output HIGH Voltage (Note 11)
Output LOW Voltage (Note 11)
Min
60
−1145
−1995
Typ
90
−1020
−1770
Max
120
−895
−1600
Min
60
−1145
−1995
25°C
Typ
90
−1020
−1770
Max
120
−895
−1600
Min
60
−1145
−1995
85°C
Typ
90
−1020
−1770
Max
120
−895
−1600
Unit
mA
mV
mV
