High power low ohmic chip resistors
〈
Wide terminal type
〉
LTR series
●
Datasheet
Features
1)Chip Resistors for current detection : 10mΩ ~
2)High joint reliability with long side terminations.
3)Improvement of rated power enables to displace smaller size of resistors,and
it contributes space savings in your set.
4)ROHM resistors have obtained ISO9001 / ISO / TS16949 certification.
5)Corresponds to AEC-Q200.
●
Products list
Size
(mm)
(inch)
0805
Part No.
LTR10
Rated
power
(70
℃
)
(W)
0.5
Resistance
tolerance
(%)
F ( ±1% )
J ( ±5% )
F ( ±1% )
J ( ±5% )
F ( ±1% )
F ( ±1% )
J ( ±5% )
T
emperature
coefficient
(ppm /
℃
)
±150
±150
0
½
300
0
½
200
0
½
150
±100
0
½
+150
0
½
+100
±200
Resistance range
(Ω)
0.047
≦
R<0.100
0.100
≦
R<10
0.010
＜
R
＜
0.020
0.020
≦
R
＜
0.050
0.050
≦
R
＜
0.500
0.500
≦
R
≦
1.000
0.100
≦
R<0.200
0.200
≦
R<1
0.100
≦
R<1
(E24 series)
(E24 series)
(E24 series)
(E24 series)
(E24 series)
(E24 series)
(E24 series)
(E24 series)
(E24 series)
Operating
temperature
range
(
℃
)
-55
½
+155
2012
LTR18
3216
1206
1.0
-55
½
+155
LTR100
6432
2512
2.0
-55
½
+155
Design and specifications are subject to change without notice.
Carefully check the specification sheet supplied with the product before using or ordering it.
●
Part number description
L T R
Part No.
LTR
(High power
chip resistors
〈
Wide terminal
type
〉
)
1 0
Size (mm [inch])
10(2012 [0805])
18(3216 [1206])
100(6432 [2512])
EVH
Packaging specifications code
Packaging
Part No. Code specifications Quantity
/ Reel
J
Resistance
tolerance
J
Special
part code
1R0
Nominal resistance
Resistance code, 3 or 4 digits.
Resistance
tolerance Resistance
+
code
Special code
FU, FS
FL, JS
JU, JL
：
Paper tape
LTR10
EVH (4mm Pitch) 5000
Paper tape
LTR18
EZP (4mm Pitch) 5,000
Embossed
tape
LTR100
JZP
4,000
(4mm Pitch)
F (±1%)
J (±5%)
U
：
10mΩ
S
：
11mΩ
½
91mΩ
L
：
100mΩ
½
4 digits
3 digits
：
www.rohm.com
© 2016 ROHM Co., Ltd. All rights reserved.
1/4
2017.06 - Rev.F
LTR series -low ohmic-
●
Datasheet
Derating curve
When the ambient temperature exceeds 70°C, power dissipation must be adjusted according to the derating curves below.
■
LTR 10 / 18 / 100
●
Characteristics
T items
est
Guaranteed value
Resistor type
T conditions
est
20
℃
Measuring method : Measure Bottom termination
by 4 proves.
Resistance
See P.1
Variation of resistance
with temperature
Overload
See P.1
±(2.0
％＋
0.0005Ω)
Anew uniform coating of minimum of 95% of
the surface being immersed and no
soldering damage.
Measurement
：
+25/-55, +25/+125
℃
Rated voltage(current)×2.5
，
2s
Rosin-ethanol solution25% (Wweight)
Soldering condition
：
245±5
℃
Duration of immersion
：
2.0±0.5s
Solderability
Resistance to
soldering heat
Rapid change of
temperature
Damp heat, steady state
Endurance at 70
℃
Endurance
Resistance to solvent
Bend strength of
the end face plating
±(1.0
％＋
0.0005Ω)
Soldering condition
：
260±5
℃
No remarkable abnormality on the appearance. Duration of immersion
：
10±1s
±(1.0
％＋
0.0005Ω)
±(3.0
％＋
0.0005Ω)
±(3.0
％＋
0.0005Ω)
±(3.0
％＋
0.0005Ω)
±(1.0
％＋
0.0005Ω)
Without mechanical damage such as breaks.
T temp
：
-55
℃½
+125
℃
5cycle
est
40
℃，
93
％
(Relative humidity)
T time
：
1,000h
est
Rated voltage(current),70
℃
1.5h:ON
－
0.5h:OFF
T time
：
1,000h
est
155
℃
T time
：
1,000h
est
23±5
℃
, Immersion cleaning, 5±0.5min
Solvent: 2-propanol
-
Compliance Standard(s) : IEC60115-8
JISC 5201-8
www.rohm.com
© 2016 ROHM Co., Ltd. All rights reserved.
3/4
2017.06 - Rev.F
