This is the summary of application for BD6962FVM. BD6962FVM can drive FAN motor silently by BTL soft switching, and it
can control rotational speed by PWM signal.
Features
■
Compact package (MSOP8)
■
BTL soft switching drive
■
PWM speed control
■
Quick start function
■
Lock protection and auto restart
(without external capacitor)
■
Rotating speed pulse signal (FG) output
Application
PC, PC peripheral component
(Power supply, VGA card, case FAN etc.)
BD player, Projector etc.
Package
MSOP8
W(Typ) x D(Typ) x H(Max)
2.90mm x 4.00mm x 0.90mm
MSOP8
Absolute Maximum Ratings
Parameter
Supply Voltage
Power Dissipation
Operating Temperature
Storage Temperature
Output Voltage
Output Current
FG Signal Output Voltage
FG Signal Output Current
Junction Temperature
Symbol
V
CC
Pd
Topr
Tstg
V
OMAX
I
OMAX
V
FG
I
FG
Tjmax
Limit
15
0.58
(Note 1)
-40 to +105
-55 to +150
15
800
(Note 2)
15
10
150
Unit
V
W
°C
°C
V
mA
V
mA
°C
(Note 1) Reduce by 4.68mW/°C over 25°C. (On 70.0mm×70.0mm×1.6mm glass epoxy board)
(Note 2) This value is not to exceed Pd.
Caution:
Operating the IC over the absolute maximum ratings may damage the IC. The damage can either be a short circuit between pins or an open circuit
between pins and the internal circuitry. Therefore, it is important to consider circuit protection measures, such as adding a fuse, in case the IC is operated
over the absolute maximum ratings.
○Product
structure：Silicon monolithic integrated circuit
○This
product is not designed protection against radioactive rays
