Datasheet
General Purpose CMOS Logic IC
Single 2-Input AND Gate
BU4S81G2
General Description
The BU4S81G2 is a 2-input single AND gate with buffered
output. Buffered output improves the characteristics of
propagation delay from gate input to output. Also, buffered
output suppress the fluctuating delay time which caused
by output load capacitance.
Key Specifications
Supply Voltage Range:
Input Voltage Range:
Operating Temperature Range:
+3V to +16V
V
SS
to V
DD
-40°C to +85°C
Features
Low power consumption
High noise immunity
Wide operating supply voltage range
High input impedance
High fan out
Input can be directly driven 2 L-TTL inputs or 1 LS-TTL
Buffered output
Packages
SSOP5
W(Typ) x D(Typ) x H(Max)
2.90mm x 2.80mm x 1.25mm
SSOP5
Pin Configurations
(Top View)
VDD
5
Y
4
Pin Descriptions
Pin No.
1
2
3
4
5
Symbol
A
B
VSS
Y
VDD
I/O
I
I
-
O
-
Function
Input
Input
Ground
Output
Power supply
1
A
2
B
3
VSS
Truth Table
INPUT
A
L
L
H
H
B
L
H
L
H
OUTPUT
Y
L
L
L
H
〇Product
structure : Silicon monolithic integrated circuit
.
www.rohm.com
© 2014 ROHM Co., Ltd. All rights reserved.
TSZ22111 • 14 • 001
〇This
product has no designed protection against radioactive rays
1/12
TSZ02201-0RDR0GZ00200-1-2
30.Sep.2015 Rev.002
BU4S81G2
Absolute Maximum Ratings
(T
A
=25°C)
Parameter
Supply Voltage
Input Voltage
Input Current
Operating Temperature
Storage Temperature
Maximum Junction Temperature
Power Dissipation
Symbol
V
DD
V
IN
I
IN
T
opr
T
stg
T
Jmax
P
D
Rating
-0.3 to +18.0
(V
SS
-0.3) to (V
DD
+0.3)
±10
-40 to +85
-55 to +150
+150
0.67
(Note 1)
Unit
V
V
mA
°C
°C
°C
W
(Note 1) Derate by 5.4mW/°C when operating above T
A
=25°C (when mounted on ROHM’s standard board).
Caution:
Operating the IC over the absolute maximum ratings may damage the IC. The damage can either be a short circuit between pins or an open circuit
between pins and the internal circuitry. Therefore, it is important to consider circuit protection measures, such as adding a fuse, in case the IC is operated over
the absolute maximum ratings.
Recommended Operating Conditions
(T
A
=-40°C to +85°C)
Parameter
Supply Voltage
Input Voltage
Symbol
V
DD
V
IN
Rating
+3.0 to +16.0
V
SS
to V
DD
Unit
V
V
www.rohm.com
© 2014 ROHM Co., Ltd. All rights reserved.
TSZ22111 • 15 • 001
2/12
TSZ02201-0RDR0GZ00200-1-2
30.Sep.2015 Rev.002
BU4S81G2
Electrical Characteristics
(Unless otherwise specified, V
SS
=0V, T
A
=25°C)
Parameter
Symbol
Limits
Min
3.5
Input “H” Voltage
V
IH
7.0
11.0
-
Input “L” Voltage
Input “H” Current
Input “L” Current
DC Characteristics
Output “H” Voltage
V
IL
I
IH
I
IL
V
OH
-
-
-
-
4.95
9.95
14.95
-
Output “L” Voltage
V
OL
-
-
-0.51
Output “H” Current
I
OH
-2.1
-1.3
-3.4
0.51
Output “L” Current
I
OL
1.3
3.4
-
Quiescent Supply Current
I
DD
-
-
Typ
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
Limits
Min
-
Output Rising Time
Switching Characteristics
t
TLH
-
-
-
Output Falling Time
t
THL
-
-
-
“L” to ”H”
Propagation Delay Time
t
PLH
-
-
-
“H” to ”L”
Propagation Delay Time
Input Capacitance
t
PHL
C
IN
-
-
-
Typ
70
35
30
70
35
30
90
45
30
90
45
30
5
Max
-
-
-
-
-
-
-
-
-
-
-
-
-
pF
ns
ns
ns
ns
Max
-
-
-
1.5
3.0
4.0
0.3
-0.3
-
-
-
0.05
0.05
0.05
-
-
-
-
-
-
-
0.25
0.5
1.0
μA
mA
mA
V
V
μA
μA
V
V
Unit
Conditions
V
DD
[V]
5
10
15
5
10
15
15
15
5
10
15
5
10
15
5
5
10
15
5
10
15
5
10
15
Conditions
V
DD
[V]
5
10
15
5
10
15
5
10
15
5
10
15
-
-
-
C
L
=50pF
10
C
L
=50pF
9
C
L
=50pF
8
C
L
=50pF
7
Figure
No.
V
IN
=V
DD
-
V
OH
=4.6V
V
OH
=2.5V
V
OH
=9.5V
V
OH
=13.5V
V
OL
=0.4V
V
OL
=0.5V
V
OL
=1.5V
V
IN
=V
SS
6
V
IN
=V
DD
5
|I
OUT
|<1μA
V
IN
=V
SS
II
OUT
|<1μA
V
IN
=V
DD
V
OUT
=4.5V
V
OUT
=9.0V
V
OUT
=13.5V
V
OUT
=0.5V
V
OUT
=1.0V
V
OUT
=1.5V
V
IH
=15V
V
IL
=0V
Figure
No.
2
3
4
2
3
4
-
-
2
3
4
2
3
4
Parameter
Symbol
Unit
www.rohm.com
© 2014 ROHM Co., Ltd. All rights reserved.
TSZ22111 • 15 • 001
3/12
TSZ02201-0RDR0GZ00200-1-2
30.Sep.2015 Rev.002
BU4S81G2
Test Circuits
1.V
IH
2.V
IL
V
DD
V
DD
V
IH
I
OUT
+
V V
OUT
V
IL
+
I
OUT
V V
OUT
3.V
OH
V
DD
4.V
OL
V
DD
V
IN
I
OUT
V V
OH
+
V
IN
I
OUT
V V
OL
+
5.I
OH
V
DD
6.I
OL
V
DD
V
IN
+
A I
OH
V
OH
V
IN
+
A I
OL
V
OL
7 . t
TLH
, t
THL
, t
PLH
, t
PHL
V
DD
INPUT
10%
20 ns
90%
50%
20 ns
OUTPUT
INPUT
C
L
=50pF
OUTPUT
t
PLH
90%
50%
10 %
t
PHL
TLH
THL
Description of Symbols
t
PHL
: Time from 50% of the fall edge of input waveform to 50% of
the fall edge of output waveform
t
PLH
: Time from 50% of the rise edge of input waveform to 50% of
the rise edge of output waveform
t
THL
: Time from 90% to 10% of fall edge of output waveform
t
TLH
: Time from 10% to 90% of rise edge of output waveform
t
t
www.rohm.com
© 2014 ROHM Co., Ltd. All rights reserved.
TSZ22111 • 15 • 001
4/12
TSZ02201-0RDR0GZ00200-1-2
30.Sep.2015 Rev.002
BU4S81G2
Typical Performance Curves
4
6
5
3
Output Voltage [V]
Output Voltage [V]
4
85°C
25°C
-40°C
85°C
25°C
-40°C
2
3
2
1
1
0
0
1
2
Input Voltage [V]
3
0
0
1
2
3
Input Voltage [V]
4
5
Figure 1. Output Voltage vs Input Voltage
（V
DD
=3V / V
SS
=0V）
Figure 2. Output Voltage vs Input Voltage
（V
DD
=5V / V
SS
=0V）
12
10
20
15
Output Voltage [V]
8
85°C
25°C
-40°C
Output Voltage [V]
6
4
2
0
0
2
4
6
Input Voltage [V]
8
10
10
85°C
25°C
-40°C
5
0
0
5
10
Input Voltage [V]
15
Figure 3. Output Voltage vs Input Voltage
（V
DD
=10V / V
SS
=0V）
Figure 4. Output Voltage vs Input Voltage
（V
DD
=15V / V
SS
=0V）
www.rohm.com
© 2014 ROHM Co., Ltd. All rights reserved.
TSZ22111 • 15 • 001
5/12
TSZ02201-0RDR0GZ00200-1-2
30.Sep.2015 Rev.002
