C. Samsung Reliablility Test and Judgement Condition
Judgement
Capacitance
Tan
δ
(DF)
Insulation
Resistance
Appearance
Withstanding
Voltage
Temperature
Characteristics
Adhesive Strength
of Termination
Bending Strength
Solderability
Within specified tolerance
0.1 max.
Test condition
120㎐ ±20% / 0.5±0.1Vrms
*A capacitor prior to measuring the capacitance is heat
treated at 150℃+0/-10℃ for 1hour and maintained in
ambient air for 24±2 hours.
Rated Voltage 60~120 sec
10,000Mohm or 100Mohm×㎌
Whichever is smaller
No abnormal exterior appearance
Microscope (×10)
250% of the rated voltage
No dielectric breakdown or
mechanical breakdown
X5R
(From -55℃ to 85℃, Capacitance change should be within ±15%)
No peeling shall be occur on the
500g·f, for 10±1 sec.
terminal electrode
Capacitance change :
within ±12.5%
Bending to the limit (1㎜)
with 1.0mm/sec.
More than 75% of terminal surface
SnAg3.0Cu0.5 solder
is to be soldered newly
245±5℃, 3±0.3sec.
(preheating : 80~120℃ for 10~30sec.)
Resistance to
Soldering Heat
Vibration Test
Capacitance change :
Tan
δ,
IR : initial spec.
Capacitance change :
Tan
δ,
IR : initial spec.
within ±7.5%
within ± 5%
Solder pot : 270±5℃, 10±1sec.
Amplitude : 1.5mm
From 10㎐ to 55㎐ (return : 1min.)
2hours × 3 direction (x, y, z)
With rated voltage
40±2℃, 90~95%RH, 500+12/-0hrs
Moisture
Resistance
High Temperature
Resistance
Temperature
Cycling
Capacitance change :
within ±12.5%
0.2 max
Tan
δ
:
IR :
500Mohm or 12.5Mohm ×
㎌
Whichever is smaller
Capacitance change :
within ±12.5%
Tan
δ
:
0.2 max
IR :
1,000Mohm or 25Mohm ×
㎌
Whichever is smaller
Capacitance change :
within ±7.5%
Tan
δ,
IR : initial spec.
With 100% of the rated voltage
Max. operating temperature
1,000+48/-0hrs
1 cycle condition
Min. operating temperature
Max. operating temperature
→
5 cycle test
→
→
25℃
25℃
※
The reliability test condition can be replaced by the corresponding accelerated test condition.
D. Recommended Soldering method :
Reflow ( Reflow Peak Temperature : 260±5℃, 30sec. )
Product specifications included in the specifications are effective as of March 1, 2013.
Please be advised that they are standard product specifications for reference only.
We may change, modify or discontinue the product specifications without notice at any time.
So, you need to approve the product specifications before placing an order.
Should you have any question regarding the product specifications,
please contact our sales personnel or application engineers.
● Derating
100%
Voltage Derating Ratio
- Disclaimer & Limitation of Use
X5R
[
Derated Voltage
]
80%
60%
40%
This product ,which guarantees High Temperature Reliability
and
with 100% of rated voltage at the maximum temperature,
Test
Application -
is recommended to be used in the circuit with derated voltage
compared to the rated voltage of the capacitor for long lifetime.
The products listed in this Specification sheet are
NOT
designed
voltage(V
DC
) applied to this product
Max. voltage(V
Max
) and DC
and manufactured for any use
shown in the table below are recommended to be used
and applications set forth below.
under the following conditions for long lifetime, respectively.
[Recommendations for long lifetime]
·V
Max
≤ (Derated
products specifications or information
deviating from
Voltage on the left graph)
·
property
×
(Derated Voltage on the left graph)
provided in this Spec sheet may cause serious
V
DC
≤ 70%
damages or personal injury.
0%
.
※
=
20%
Please note that any misuse
of the products
We
0
will
10
NOT
be liable
50 60 70 80 90
resulting from any misuse of the products, specifically
for any damages
100
20 30 40
including using
Temperature of MLCC (℃)
the products for high reliability applications as listed below.
* Temperature of MLCC : Surface temperature of MLCC in the circuit.
[Types
you have any questions
capacitor]
this 'Limitation of Use and Application', you should first contact
If
of voltage applied to the
regarding
our sales personnel or application engineers.
Any other applications with the same as or similar complexity or reliability to the applications
set forth above.
● Disclaimer & Limitation of Use and Application
The products listed in this Specification sheet are
NOT
designed and manufactured for any use
and applications set forth below.
Please note that any misuse of the products deviating from products specifications or information
provided in this Spec sheet may cause serious property damages or personal injury.
We will
NOT
be liable for any damages resulting from any misuse of the products, specifically
including using the products for high reliability applications as listed below.
If you have any questions regarding this 'Limitation of Use and Application', you should first contact
our sales personnel or application engineers.
①
②
③
④
⑤
⑥
Aerospace/Aviation equipment
Automotive or Transportation equipment (vehicles, trains, ships, etc)
Medical equipment
Military equipment
Disaster prevention/crime prevention equipment
Any other applications with the same as or similar complexity or reliability to the applications
set forth above.
①
②
③
④
⑤
⑥
Aerospace/Aviation equipment
Automotive or Transportation equipment (vehicles
,
trains
,
ships
,
etc)
Medical equipment
Military equipment
Disaster prevention/crime prevention equipment
Mobile and portable
