SM15T36CA

Description
Polarity: Bidirectional Peak pulse current (10/1000us): 30A Clamping voltage: 64.3V Breakdown voltage (minimum): 34.2V Reverse shutdown voltage (typ.): 30.8V
CategoryDiscrete semiconductor    diode
File Size101KB,10 Pages
ManufacturerSTMicroelectronics
Websitehttp://www.st.com/
Download Datasheet Parametric View All

SM15T36CA Online Shopping

Suppliers Part Number Price MOQ In stock
SM15T36CA - - View Buy Now

SM15T36CA Overview

Polarity: Bidirectional Peak pulse current (10/1000us): 30A Clamping voltage: 64.3V Breakdown voltage (minimum): 34.2V Reverse shutdown voltage (typ.): 30.8V

SM15T36CA Parametric

Parameter NameAttribute value
Brand NameSTMicroelectronics
MakerSTMicroelectronics
Parts packaging codeDO-214AB
package instructionROHS COMPLIANT, PLASTIC, SMC, 2 PIN
Contacts2
Reach Compliance Codenot_compliant
ECCN codeEAR99
Factory Lead Time10 weeks
Samacsys DescriptionTVS Diode Bi-Directional SM15T36CA 64.3V, 1500W, SMC 2-Pin
Other featuresUL RECOGNIZED
Maximum breakdown voltage37.8 V
Minimum breakdown voltage34.2 V
Breakdown voltage nominal value36 V
Maximum clamping voltage64.3 V
ConfigurationSINGLE
Minimum diode capacitance1250 pF
Diode component materialsSILICON
Diode typeTRANS VOLTAGE SUPPRESSOR DIODE
JEDEC-95 codeDO-214AB
JESD-30 codeR-PDSO-C2
JESD-609 codee3
Humidity sensitivity level1
Maximum non-repetitive peak reverse power dissipation1500 W
Number of components1
Number of terminals2
Maximum operating temperature150 °C
Minimum operating temperature-55 °C
Package body materialPLASTIC/EPOXY
Package shapeRECTANGULAR
Package formSMALL OUTLINE
Peak Reflow Temperature (Celsius)260
polarityBIDIRECTIONAL
Maximum power dissipation6.3 W
Certification statusNot Qualified
Maximum repetitive peak reverse voltage30 V
Maximum reverse current5 µA
surface mountYES
technologyAVALANCHE
Terminal surfaceMatte Tin (Sn)
Terminal formC BEND
Terminal locationDUAL
Maximum time at peak reflow temperature40
SM15T
Transil™
Features
Peak pulse power:
– 1500 W (10/1000 µs)
– 10 kW (8/20 µs)
Breakdown voltage range: from 6.8 V to 220 V
Unidirectional and bidirectional types
Low leakage current:
– 0.2 µA at 25 °C
– 1 µA at 85 °C
Operating T
j max
: 150 °C
High power capability at T
jmax
:
– 1250 W (10/1000 µs)
JEDEC registered package outline
K
Unidirectional
Bidirectional
A
SMC
(JEDEC DO-214AB)
Complies with the following standards
IEC 61000-4-2 level 4
– 15 kV (air discharge)
– 8 kV (contact discharge)
IEC 61000-4-5
– See
Table 3
for surge level
MIL STD 883G, method 3015-7: class 3B
– 25 kV HBM (human body model)
UL 497B file number: QVGQ2.E136224
Resin meets UL 94, V0
MIL-STD-750, method 2026 soldererabilty
EIA STD RS-481 and IEC 60286-3 packing
IPC 7531 footprint
Description
The SM15T Transil series has been designed to
protect sensitive equipment against electrostatic
discharges according to IEC 61000-4-2, and
MIL STD 883, method 3015, and electrical over
stress according to IEC 61000-4-4 and 5. These
devices are more generally used against surges
below 1500 W (10/1000 µs).
Planar technology makes these devices suitable
for high-end equipment and SMPS where low
leakage current and high junction temperature are
required to provide reliability and stability over
time.
SM15T are packaged in SMC (SMC footprint in
accordance with IPC 7531 standard).
TM: Transil is a trademark of STMicroelectronics
September 2009
Doc ID 3080 Rev 6
1/10
www.st.com
10
