I N D U C T O R S
Inductors for decoupling circuits
Multilayer ferrite
MLZ series
Cl
Br
RoHS
REACH
SVHC-Free
Halogen
Free
Pb
Lead
Free
MLZ1005 type
FEATURES
The MLZ series include inductors for decoupling circuits that have top-class DC superimposition characteristics and low DC resistance.
They are compatible with wide frequency band noise, from low to high frequency.
W type products are the new standard type products that have both large current and low resistance.
Operating temperature range: –55 to +125°C (including self-temperature rise)
APPLICATION
Smart phones, tablet terminals, note PCs, various modules such as camera modules, DSCs, video games, portable memory audio
devices, navigation systems, PNDs, WLANs, SSDs
Application guides:
Smart phones/tablets
PART NUMBER CONSTRUCTION
MLZ
Series name
1005
L×W×H dimensions
1.0×0.5×0.5 mm
M
Product
internal code
R47
Inductance
(µH)
W
Characteristic type
T
Packaging style
000
Internal code
CHARACTERISTICS SPECIFICATION TABLE
Type
L
L measuring conditions
Frequency
Current
DC resistance
Isat
1
Itemp
2
Part No.
(µH)
Tolerance (MHz)
(mA)
( )±30%
(mA)
(mA)
0.47
±20%
2
0.1
0.20
120
500
MLZ1005MR47WT000
0.68
±20%
2
0.1
0.30
110
450
MLZ1005MR68WT000
Large
1.00
±20%
2
0.1
0.35
100
450
MLZ1005M1R0WT000
current
1.50
±20%
2
0.1
0.50
80
350
MLZ1005M1R5WT000
2.20
±20%
2
0.1
0.55
60
350
MLZ1005M2R2WT000
1
Current assumed when inductance ratio has decreased by 50% max..
2
Current assumed when temperature has risen to 20°C max. (reference value). Operating temperature environment at this time: 105°C max.
Measurement equipment
Measurement item
Product No.
L
4294A+16034G
DC resistance
Type-7561
＊
Equivalent measurement equipment may be used.
Manufacturer
Keysight Technologies
Yokogawa
Please be sure to request delivery specifications that provide further details on the features and specifications of the products for proper and safe use.
Please note that the contents may change without any prior notice due to reasons such as upgrading.
(1/5)
20181207
inductor_commercial_decoupling_mlz1005_en.fm
I N D U C T O R S
REMINDERS FOR USING THESE PRODUCTS
Before using these products, be sure to request the delivery specifications.
SAFETY REMINDERS
Please pay sufficient attention to the warnings for safe designing when using this products.
REMINDERS
The storage period is less than 12 months. Be sure to follow the storage conditions (temperature: 5 to 40°C, humidity: 10 to 75% RH or
less).
If the storage period elapses, the soldering of the terminal electrodes may deteriorate.
Do not use or store in locations where there are conditions such as gas corrosion (salt, acid, alkali, etc.).
Before soldering, be sure to preheat components.
The preheating temperature should be set so that the temperature difference between the solder temperature and chip temperature
does not exceed 150°C.
Soldering corrections after mounting should be within the range of the conditions determined in the specifications.
If overheated, a short circuit, performance deterioration, or lifespan shortening may occur.
When embedding a printed circuit board where a chip is mounted to a set, be sure that residual stress is not given to the chip due to
the overall distortion of the printed circuit board and partial distortion such as at screw tightening portions.
Self heating (temperature increase) occurs when the power is turned ON, so the tolerance should be sufficient for the set thermal
design.
Carefully lay out the coil for the circuit board design of the non-magnetic shield type.
A malfunction may occur due to magnetic interference.
Use a wrist band to discharge static electricity in your body through the grounding wire.
Do not expose the products to magnets or magnetic fields.
Do not use for a purpose outside of the contents regulated in the delivery specifications.
The products listed on this catalog are intended for use in general electronic equipment (AV equipment, telecommunications equip-
ment, home appliances, amusement equipment, computer equipment, personal equipment, office equipment, measurement equip-
ment, industrial robots) under a normal operation and use condition.
The products are not designed or warranted to meet the requirements of the applications listed below, whose performance and/or qual-
ity require a more stringent level of safety or reliability, or whose failure, malfunction or trouble could cause serious damage to society,
person or property.
If you intend to use the products in the applications listed below or if you have special requirements exceeding the range or conditions
set forth in the each catalog, please contact us.
(1) Aerospace/aviation equipment
(2) Transportation equipment (cars, electric trains, ships, etc.)
(3) Medical equipment
(4) Power-generation control equipment
(5) Atomic energy-related equipment
(6) Seabed equipment
(7) Transportation control equipment
(8) Public information-processing equipment
(9) Military equipment
(10) Electric heating apparatus, burning equipment
(11) Disaster prevention/crime prevention equipment
(12) Safety equipment
(13) Other applications that are not considered general-purpose
applications
When designing your equipment even for general-purpose applications, you are kindly requested to take into consideration securing pro-
tection circuit/device or providing backup circuits in your equipment.
Please be sure to request delivery specifications that provide further details on the features and specifications of the products for proper and safe use.
Please note that the contents may change without any prior notice due to reasons such as upgrading.
(5/5)
20181207
inductor_commercial_decoupling_mlz1005_en.fm
