(13) Other applications that are not considered general-purpose
applications
When designing your equipment even for general-purpose applications, you are kindly requested to take into consideration securing pro-
tection circuit/device or providing backup circuits in your equipment.
20170227 / uhv_fhv_en.fm
(3/5)
C A P A C I T O R S
Ultra high voltage ceramic capacitors
With metal terminals
For high voltage power supplies/lasers
Product compatible with RoHS directive
Overview of FHV series
FEATURES
A lineup with a rated voltage of Edc：15 to 50kV
High capacitance and excellent temperature characteristics
Excellent voltage-capacitance characteristics
Low-loss and low distortion factor
Metal screw terminals for easy mounting
Uses high-reliability mold resin
APPLICATION
High-voltage power circuits (for medical devices, lithography, industrial analyzers)
OPERATING TEMPERATURE RANGE, PRODUCT WEIGHT
Temperature range
Part No.
Sub part No.
Operating
temperature
(°C)
–30 to +85
–30 to +85
–30 to +85
–30 to +85
–30 to +85
–30 to +85
–30 to +85
–30 to +85
–30 to +85
–30 to +85
–30 to +85
–30 to +85
–30 to +85
Storage
temperature
(°C)
–30 to +85
–30 to +85
–30 to +85
–30 to +85
–30 to +85
–30 to +85
–30 to +85
–30 to +85
–30 to +85
–30 to +85
–30 to +85
–30 to +85
–30 to +85
Individual weight
FHV-153AN
FHV-1AN
FHV-2AN
FHV-3AN
FHV-4AN
FHV-5AN
FHV-6AN
FHV-7AN
FHV-8AN
FHV-9AN
FHV-10AN
FHV-11AN
FHV-12AN
60750YS702K4CDA
60729YS172K4DDA
60739YS302K4DDA
60750YS522K4DDA
60729YS122K4FDA
60739YS212K4FDA
60750YS352K4FDA
60729YS851K4GDA
60739YS152K4GDA
60750YS262K4GDA
60729YS701K4HDA
60739YS132K4HDA
60750YS212K4HDA
(g)
153
75
116
174
92
144
219
108
174
267
123
195
308
RoHS Directive Compliant Product: See the following for more details.https://product.tdk.com/info/en/environment/rohs/index.html
Please be sure to request delivery specifications that provide further details on the features and specifications of the products for proper and safe use.
Please note that the contents may change without any prior notice due to reasons such as upgrading.
20170227 / uhv_fhv_en.fm
(4/5)
C A P A C I T O R S
FHV series
SHAPE & DIMENSIONS
ISO M5 female
thread
MARKINGS
FHV-5AN
212K
DC30kV
TDK
1234
Part No.
Nominal capacitance and tolerance code
Rated voltage
Manufacturer’s name (TDK or TDK logo mark)
Lot No.
ø15±0.5
øD±1
T±2
L±1
Part No.
FHV-153AN
FHV-1AN
FHV-2AN
FHV-3AN
FHV-4AN
FHV-5AN
FHV-6AN
FHV-7AN
FHV-8AN
FHV-9AN
FHV-10AN
FHV-11AN
FHV-12AN
Sub part No.
60750YS702K4CDA
60729YS172K4DDA
60739YS302K4DDA
60750YS522K4DDA
60729YS122K4FDA
60739YS212K4FDA
60750YS352K4FDA
60729YS851K4GDA
60739YS152K4GDA
60750YS262K4GDA
60729YS701K4HDA
60739YS132K4HDA
60750YS212K4HDA
øD
(mm)
60
38
48
60
38
48
60
38
48
60
38
48
60
T
(mm)
17
19
19
19
22
22
22
26
26
26
29
29
29
L
(mm)
21
23
23
23
26
26
26
30
30
30
33
33
33
Please be sure to request delivery specifications that provide further details on the features and specifications of the products for proper and safe use.
Please note that the contents may change without any prior notice due to reasons such as upgrading.
20170227 / uhv_fhv_en.fm
(5/5)
C A P A C I T O R S
FHV series
ELECTRICAL CHARACTERISTICS
CHARACTERISTICS SPECIFICATION TABLES
Class 2 (Temperature stable)
Temperature characteristics: Y5S(–30 to +85°C, ±22%)
Part No.
Sub part No.
Rated voltage
Capacitance
Withstanding
voltage
[1min, in oil]
(kV)
22.5
30
30
30
45
45
45
60
60
60
75
75
75
Dissipation
factor (tan)
(%) max.
0.2
0.2
0.2
0.2
0.2
0.2
0.2
0.2
0.2
0.2
0.2
0.2
0.2
Insulation
resistance
(M) min.
100000
100000
100000
100000
100000
100000
100000
100000
100000
100000
100000
100000
100000
AC corona
starting voltage
[3PC
]
(kVAC) min.
7.5
10
10
10
15
15
15
20
20
20
25
25
25
FHV-153AN
FHV-1AN
FHV-2AN
FHV-3AN
FHV-4AN
FHV-5AN
FHV-6AN
FHV-7AN
FHV-8AN
FHV-9AN
FHV-10AN
FHV-11AN
FHV-12AN
60750YS702K4CDA
60729YS172K4DDA
60739YS302K4DDA
60750YS522K4DDA
60729YS122K4FDA
60739YS212K4FDA
60750YS352K4FDA
60729YS851K4GDA
60739YS152K4GDA
60750YS262K4GDA
60729YS701K4HDA
60739YS132K4HDA
60750YS212K4HDA
(kV)
15
20
20
20
30
30
30
40
40
40
50
50
50
(pF)
7,000±10%
1,700±10%
3,000±10%
5,200±10%
1,200±10%
2,100±10%
3,500±10%
850±10%
1,500±10%
2,600±10%
700±10%
1,300±10%
2,100±10%
PC：Pico coulomb.
CAPACITANCE VS. TEMPERATURE CHARACTERISTICS
CAPACITANCE VS. DC BIAS CHARACTERISTICS
50
10
30
Y5S
0
Capacitance change rate(%)
Capacitance change rate(%)
10
–10
–10
–20
–30
–30
–50
–50
0
50
Temperature(°C)
100
–40
100%=Rated voltage
0
50
100
Rated voltage(%)
150
Please be sure to request delivery specifications that provide further details on the features and specifications of the products for proper and safe use.
Please note that the contents may change without any prior notice due to reasons such as upgrading.
