BAV70 Parametric

Parameter Name	Attribute value
Case Style	SOT-23
IF（mA）	150
Maximum recurrent peak reverse voltage	75
TRR（nS)	6.0
Maximum instantaneous forward voltage	1.25
@IF（uA）	150
Maximum reverse current	2.5
@VR	70
class	Diodes

Preview

Download Datasheet

View All

BAV70

Dual Surface Mount Switching Diode

SOT-23

Features

Fast switching speed.

High conductance.

Common cathode.

For general purpose switching appilications.

Surface mount package ideally suited

for automatic insertion.

Dimensions in inches and (millimeters)

Applications

Small signal switching

Ordering Information

Type No.

BAV70

Marking

Package Code

SOT-23

MAXIMUM RATING

@ Ta=25℃ unless otherwise specified

Parameter

Non-Repetitive Peak reverse voltage

Peak repetitive reverse voltage

Working peak reverse voltage

DC Reverse Voltage

RMS Reverse Voltage

Forward continuous Current(Max.)

Average rectified output current

Repetitive Peak Forward current

Non-repetitive forward Surge Current

@t=1.0μs

@t=1.0s

Power Dissipation

Thermal resistance,junction to ambient air

Junction temperature

Storage temperature range

Symbol

RRM

RWM

R(RMS)

FRM

Limits

100

Unit

300

150

450

FSM

2.0

1.0

350

357

150

-65-+150

θJA

stg

℃/W

℃

Revision:20170701-P1

www.lgesemi

mail:lge@lgesemi.com
