MOSPEC
REVERSE VOLTAGE:
FORWARD CURRENT:
FEATURES
· Plastic material has Underwriters Laboratory
Flammability Classification 94V-0
· High surge overload rating of 50 Amperes peak
· Ideal for printed circuit board
· Glass passivated chip junction
DB101S THRU DB107S
50 to 1000 VOLTS
1.0 AMPERE
DB-S
MECHANICAL DATA
Case: Molded plastic, DB-S
Epoxy: UL 94V-O rate flame retardant
Terminals: Leads solderable per MIL-STD-202,
method 208 guaranteed
Mounting position: Any
Weight: 0.02ounce, 0.4gram
Dimensions in inches and (millimeters)
Maximum Ratings and Electrical Characteristics
Ratings at 25
℃
ambient temperature unless otherwise specified.
Single phase, half wave, 60H
Z
, resistive or inductive load.
For capacitive load, derate current by 20%.
Symbols
Maximum Recurrent Peak Reverse Voltage
Maximum RMS Voltage
Maximum DC Blocking Voltage
Maximum Average Forward
Rectified Current at T
A
=40℃
Peak Forward Surge Current,
8.3ms single half-sine-wave
superimposed on rated load (JEDEC method)
Maximum Forward Voltage
at 1.0A DC and 25℃
Maximum Reverse Current
at Rated DC Blocking Voltage
Typical Thermal Resistance (Note 2)
Typical Thermal Resistance (Note 2)
Operating and Storage Temperature Range
at T
A
=25℃
T
A
=125℃
V
F
I
R
C
J
R
θJA
R
θJL
T
J
,Tstg
I
FSM
(Note 2)
V
RRM
V
RMS
V
DC
I
(AV)
DB101S
DB102S
DB103S
DB104S
DB105S
DB106S
DB107S
Units
Volts
Volts
Volts
Amp
50
35
50
100
70
100
200
140
200
400
280
400
1.0
600
420
600
800
560
800
1000
700
1000
50
Amp
1.1
5.0
500
25
40
15
-55 to +150
Volts
uAmp
pF
℃/W
℃/W
℃
Typical Junction Capacitance (Note 1)
NOTES:
1- Measured at 1 MH
Z
and applied reverse voltage of 4.0 VDC.
2- Units mounted on P.C.B. with 0.5 x 0.5" (13 x 13mm) copper pads
